Page 1961 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4DOTC 2.5)-31 FUEL INJECTION (FUEL SYSTEM) Manifold Absolute Pressure Sensor 9. Manifold Absolute Pressure Sensor A: REMOVAL 1) Disconnect the ground cable from battery. 2) Disconnect the connect

Page 1962 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4DOTC 2.5)-32 FUEL INJECTION (FUEL SYSTEM) Fuel Injector 10.Fuel Injector A: REMOVAL 1. RH SIDE 1) Release the fuel pressure. <Ref. to FU(H4DOTC 2.5)-45, RELEASING OF FUEL PRESSURE, OPERATION, Fu

Page 1963 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4DOTC 2.5)-33 FUEL INJECTION (FUEL SYSTEM) Tumble Generator Valve Assembly 11.Tumble Generator Valve As- sembly A: REMOVAL 1) Release the fuel pressure. <Ref. to FU(H4DOTC 2.5)-45, RELEASING OF F

Page 1964 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4DOTC 2.5)-34 FUEL INJECTION (FUEL SYSTEM) Tumble Generator Valve Actuator 12.Tumble Generator Valve Ac- tuator A: REMOVAL 1. RH SIDE 1) Release the fuel pressure. <Ref. to FU(H4DOTC 2.5)-45, REL

Page 1965 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4DOTC 2.5)-35 FUEL INJECTION (FUEL SYSTEM) Wastegate Control Solenoid Valve 13.Wastegate Control Solenoid Valve A: REMOVAL 1) Disconnect the ground cable from battery. 2) Disconnect the engine ha

Page 1966 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4DOTC 2.5)-36 FUEL INJECTION (FUEL SYSTEM) Front Oxygen (A/F) Sensor 14.Front Oxygen (A/F) Sensor A: REMOVAL 1) Disconnect the ground cable from battery. 2) Disconnect the connector from the front

Page 1967 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4DOTC 2.5)-37 FUEL INJECTION (FUEL SYSTEM) Front Oxygen (A/F) Sensor B: INSTALLATION 1) Before installing front oxygen (A/F) sensor, ap- ply anti-seize compound only to the threaded por- tion of f

Page 1968 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4DOTC 2.5)-38 FUEL INJECTION (FUEL SYSTEM) Rear Oxygen Sensor 15.Rear Oxygen Sensor A: REMOVAL 1) Disconnect the ground cable from battery. 2) Lift-up the vehicle. 3) Disconnect the connector from
