Page 1385 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4DOTC)-30 FUEL INJECTION (FUEL SYSTEM) Crankshaft Position Sensor 5. Crankshaft Position Sensor A: REMOVAL 1) Disconnect the ground cable from battery. 2) Remove the bolt which installs the cranks

Page 1386 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4DOTC)-31 FUEL INJECTION (FUEL SYSTEM) Camshaft Position Sensor 6. Camshaft Position Sensor A: REMOVAL 1) Disconnect the ground cable from battery. 2) Disconnect the connector from camshaft posi-

Page 1387 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4DOTC)-32 FUEL INJECTION (FUEL SYSTEM) AVCS Camshaft Position Sensor 7. AVCS Camshaft Position Sensor A: REMOVAL 1) Disconnect the ground cable from battery. 2) Remove the intercooler. <Ref. to I

Page 1388 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4DOTC)-33 FUEL INJECTION (FUEL SYSTEM) Knock Sensor 8. Knock Sensor A: REMOVAL 1) Disconnect the ground cable from battery. 2) Remove the intercooler. <Ref. to IN(H4DOTC)- 10, REMOVAL, Intercooler

Page 1389 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4DOTC)-34 FUEL INJECTION (FUEL SYSTEM) Throttle Position Sensor 9. Throttle Position Sensor A: REMOVAL 1) Disconnect the ground cable from battery. 2) Remove the intercooler. <Ref. to IN(H4DOTC)-

Page 1390 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4DOTC)-35 FUEL INJECTION (FUEL SYSTEM) Mass Air Flow and Intake Air Temperature Sensor 10.Mass Air Flow and Intake Air Temperature Sensor A: REMOVAL 1) Disconnect the ground cable from battery. 2

Page 1391 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4DOTC)-36 FUEL INJECTION (FUEL SYSTEM) Manifold Absolute Pressure Sensor 11.Manifold Absolute Pressure Sensor A: REMOVAL 1) Disconnect the ground cable from battery. 2) Remove the idle air contro

Page 1392 of 2870

SUBARU FORESTER 2004 Service Repair Manual FU(H4DOTC)-37 FUEL INJECTION (FUEL SYSTEM) Idle Air Control Solenoid Valve 12.Idle Air Control Solenoid Valve A: REMOVAL 1) Disconnect the ground cable from battery. 2) Disconnect the connector from
