AC-41
HVAC SYSTEM (AUTO A/C)(DIAGNOSTIC)
General Diagnostic Table
9. General Diagnostic Table
A: INSPECTION
Symptom Problem parts
A/C system fails to operate.Fuse
Connector (Poor contact)
Ground
Auto A/C control module
Blower fan motor
Blower fan relay
A/C Relay
Compressor (Magnet clutch)
Evaporator sensor
Fuse is blown out.Fuse
Connector (Poor contact)
Illumination cannot dim.Fuse
Connector (Poor contact)
Auto A/C control module
Blower fan does not rotate or fan speed cannot be controlled.Fuse
Connector (Poor contact)
Ground
Auto A/C control module
Blower fan motor
Blower fan relay
Unable to switch suction vents. Connector (Poor contact)
Auto A/C control module
Intake door actuator
Unable to switch blow vents. Connector (Poor contact)
Auto A/C control module
Mode door actuator
Compartment temperature does not increase. (No hot air is dis-
charged.) Connector (Poor contact)
Auto A/C control module
Air mix door actuator
In-vehicle sensor, ambient sensor, evaporator sensor and
sunload sensor
In-vehicle sensor aspirator hose
Compartment temperature does not decrease. (No cool air is
discharged.) Connector (Poor contact)
Auto A/C control module
Air mix door actuator
A/C Relay
Compressor (Magnet clutch)
Radiator fan motor
Radiator fan relay
In-vehicle sensor, ambient sensor, evaporator sensor and
sunload sensor
In-vehicle sensor aspirator hose
Compartment temperature is higher or lower than setting tem-
perature. Auto A/C control module
Air mix door actuator
In-vehicle sensor, ambient sensor, evaporator sensor and
sunload sensor
In-vehicle sensor aspirator hose
Compartment temperature does not quickly respond to setting
temperature. Air mix door actuator
In-vehicle sensor, ambient sensor, evaporator sensor and
sunload sensor
In-vehicle sensor aspirator hose
Radiator fan does not rotate during A/C operation. Radiator fan motor
Radiator fan relay
Page 98 of 2870
AC-42
HVAC SYSTEM (AUTO A/C)(DIAGNOSTIC)
General Diagnostic Table
Page 99 of 2870

FUJI HEAVY INDUSTRIES LTD. G8080GE7
2004 FORESTER SERVICE MANUAL QUICK REFERENCE INDEX
BODY SECTION
This service manual has been prepared
to provide SUBARU service personnel
with the necessary information and data
for the correct maintenance and repair
of SUBARU vehicles.
This manual includes the procedures
for maintenance, disassembling, reas-
sembling, inspection and adjustment of
components and diagnostics for guid-
ance of experienced mechanics.
Please peruse and utilize this manual
fully to ensure complete repair work for
satisfying our customers by keeping
their vehicle in optimum condition.
When replacement of parts during
repair work is needed, be sure to use
SUBARU genuine parts.
All information, illustration and specifi-
cations contained in this manual are
based on the latest product information
available at the time of publication
approval.HVAC SYSTEM
(HEATER, VENTILATOR AND A/C)AC
HVAC SYSTEM (AUTO A/C)
(DIAGNOSTIC)AC
AIRBAG SYSTEM AB
AIRBAG SYSTEM (DIAGNOSTIC) AB
SEAT BELT SYSTEM SB
LIGHTING SYSTEM LI
WIPER AND WASHER SYSTEM WW
ENTERTAINMENT ET
COMMUNICATION SYSTEM COM
GLASS/WINDOW/MIRROR GW
BODY STRUCTURE BS
INSTRUMENTATION/DRIVER INFO IDI
SEAT SE
SECURITY AND LOCK SL
SUNROOF/T-TOP/CONVERTIBLE TOP
(SUNROOF)SR
EXTERIOR/INTERIOR TRIM EI
EXTERIOR BODY PANEL EB
Page 100 of 2870
2004 FORESTER SERVICE MANUAL QUICK REFERENCE INDEX
BODY SECTION
G8080GE7
CRUISE CONTROL SYSTEM CC
