Page 9 of 2870

SUBARU FORESTER 2004 Service Repair Manual AC-7 HVAC SYSTEM (HEATER, VENTILATOR AND A/C) General Description  LHD MODEL WITH MANUAL A/C (1) Evaporator cover (9) Heater core (17) Expansion valve (2) Mode main lever (10) Drain hose (18) Evapora

Page 10 of 2870

SUBARU FORESTER 2004 Service Repair Manual AC-8 HVAC SYSTEM (HEATER, VENTILATOR AND A/C) General Description  RHD MODEL WITH MANUAL A/C (1) Evaporator cover (10) Heater core (19) Expansion valve (2) Side rod (11) Drain hose (20) Evaporator (3

Page 11 of 2870

SUBARU FORESTER 2004 Service Repair Manual AC-9 HVAC SYSTEM (HEATER, VENTILATOR AND A/C) General Description 2. BLOWER MOTOR UNIT  LHD MODEL WITH AUTO A/C (1) Upper case (4) Link lever (7) Lower case (2) Air inlet select actuator (5) Filter c

Page 12 of 2870

SUBARU FORESTER 2004 Service Repair Manual AC-10 HVAC SYSTEM (HEATER, VENTILATOR AND A/C) General Description  RHD MODEL WITH AUTO A/C (1) Upper case (4) Link lever (7) Lower case (2) Air inlet select actuator (5) Filter cover (8) Blower moto

Page 13 of 2870

SUBARU FORESTER 2004 Service Repair Manual AC-11 HVAC SYSTEM (HEATER, VENTILATOR AND A/C) General Description  LHD MODEL WITH MANUAL A/C (1) Upper case (4) Link rod (7) Cover (2) Air inlet select actuator (5) Filter cover (8) Lower case (3) A

Page 14 of 2870

SUBARU FORESTER 2004 Service Repair Manual AC-12 HVAC SYSTEM (HEATER, VENTILATOR AND A/C) General Description  RHD MODEL WITH MANUAL A/C (1) Upper case (4) Air inlet select link (7) Cover (2) Air inlet select actuator (5) Filter cover (8) Low

Page 15 of 2870

SUBARU FORESTER 2004 Service Repair Manual AC-13 HVAC SYSTEM (HEATER, VENTILATOR AND A/C) General Description 3. CONTROL UNIT  AUTO A/C MODEL (1) Panel (4) Control case (front) (7) Control case (rear) (2) Control dial (5) Bulb (3) Switch (6)

Page 16 of 2870

SUBARU FORESTER 2004 Service Repair Manual AC-14 HVAC SYSTEM (HEATER, VENTILATOR AND A/C) General Description  LHD MODEL WITH MANUAL A/C (1) Panel (5) A/C switch (9) Mode control cable (2) Temperature control dial (6) Air inlet select switch
