2004 SUBARU FORESTER Service Repair Manual

Page 921 of 2870

SUBARU FORESTER 2004  Service Repair Manual ME(H4SO)-52
MECHANICAL
Timing Belt
2. AUTOMATIC BELT TENSION ADJUST-
ER
1) Visually check oil seals for leaks, and rod ends
for abnormal wear or scratches. If necessary, re-
place faulty parts.
2) Che

Page 922 of 2870

SUBARU FORESTER 2004  Service Repair Manual FUJI HEAVY INDUSTRIES LTD. G8080GE2
2004 FORESTER SERVICE MANUAL QUICK REFERENCE INDEX
ENGINE SECTION 1
This service manual has been prepared
to provide SUBARU service personnel
with the necessary inf

Page 923 of 2870

SUBARU FORESTER 2004  Service Repair Manual MECHANICAL
ME(H4SO)
Page
1. General Description ....................................................................................2
2. Compression ...................................................

Page 924 of 2870

SUBARU FORESTER 2004  Service Repair Manual ME(H4SO)-53
MECHANICAL
Cam Sprocket
16.Cam Sprocket
A: REMOVAL
1. REMOVAL
1) Remove the V-belt. <Ref. to ME(H4SO)-43, RE-
MOVAL, V-belt.>
2) Remove the crank pulley. <Ref. to ME(H4SO)-
45, REMOVAL, Cr

Page 925 of 2870

SUBARU FORESTER 2004  Service Repair Manual ME(H4SO)-54
MECHANICAL
Cam Sprocket
C: INSPECTION
1) Check the cam sprocket teeth for abnormal wear
and scratches.
2) Make sure there is no free play between cam
sprocket and key.
3) Check the cam spr

Page 926 of 2870

SUBARU FORESTER 2004  Service Repair Manual ME(H4SO)-55
MECHANICAL
Crank Sprocket
17.Crank Sprocket
A: REMOVAL
1) Remove the V-belt. <Ref. to ME(H4SO)-43, RE-
MOVAL, V-belt.>
2) Remove the crank pulley. <Ref. to ME(H4SO)-
45, REMOVAL, Crank Pul

Page 927 of 2870

SUBARU FORESTER 2004  Service Repair Manual ME(H4SO)-56
MECHANICAL
Valve Rocker Assembly
18.Valve Rocker Assembly
A: REMOVAL
1) Remove the V-belt. <Ref. to ME(H4SO)-43, RE-
MOVAL, V-belt.>
2) Remove the crank pulley. <Ref. to ME(H4SO)-
45, REMO

Page 928 of 2870

SUBARU FORESTER 2004  Service Repair Manual ME(H4SO)-57
MECHANICAL
Valve Rocker Assembly
D: ASSEMBLY
1) Install the adjusting screw and nut to valve rock-
er.
2) Arrange the valve rocker arms, springs and shaft
supports in assembly order and in
