SUBARU FORESTER 2004 Service Repair Manual AB-13 AIRBAG SYSTEM (DIAGNOSTIC) General Description  TEST HARNESS R ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299FE030 TEST HARNESS R Used when measuring voltage, resistance of air- bag control

Page 146 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-14 AIRBAG SYSTEM (DIAGNOSTIC) General Description  TEST HARNESS P ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA020 TEST HARNESS P Used when measuring voltage, resistance of driver’s airb

Page 147 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-15 AIRBAG SYSTEM (DIAGNOSTIC) General Description  TEST HARNESS N ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA000 TEST HARNESS N Used when measuring voltage, resistance of driver’s airb

Page 148 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-16 AIRBAG SYSTEM (DIAGNOSTIC) General Description  TEST HARNESS T ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA060 TEST HARNESS T  Used when measuring voltage, resistance of airbag system

Page 149 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-17 AIRBAG SYSTEM (DIAGNOSTIC) General Description  TEST HARNESS Q ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA040 TEST HARNESS Q Used when measuring voltage, resistance of driver’s airb

Page 150 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-18 AIRBAG SYSTEM (DIAGNOSTIC) General Description  AIRBAG RESISTOR ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299PA040 AIRBAG RESISTOR Used in replacement of airbag module which resistance va

Page 151 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-19 AIRBAG SYSTEM (DIAGNOSTIC) Electrical Components Location 4. Electrical Components Location A: LOCATION 1. LHD MODEL (a) To body harness (b) To seat belt pretensioner (LH) (c) To seat belt prete

Page 152 of 2870

SUBARU FORESTER 2004 Service Repair Manual AB-20 AIRBAG SYSTEM (DIAGNOSTIC) Electrical Components Location 2. RHD MODEL (a) To body harness (b) To seat belt pretensioner (LH) (c) To seat belt pretensioner (RH) (1) Front sub sensor (LH) (6) Pas
