SUBARU FORESTER 2004 Service Repair Manual SE-5 SEAT General Description B: CAUTION When removing the front seat from a side airbag loaded vehicle, follow cautions given in the airbag section. C: PREPARATION TOOL 1. GENERAL TOOL TOOL NAME REMA

Page 410 of 2870

SUBARU FORESTER 2004 Service Repair Manual SE-6 SEAT Front Seat 2. Front Seat A: REMOVAL 1) Disconnect the ground cable from battery. WARNING: The airbag system is fitted with a backup power source. If the airbag system is serviced within 20 s

Page 411 of 2870

SUBARU FORESTER 2004 Service Repair Manual SE-7 SEAT Front Seat 3) Loosen the screw, and then remove the hinge cover. 4) Remove two reclining hinge securing bolts on each side. 5) Remove the cover (A), and then loosen the nuts to remove arm re

Page 412 of 2870

SUBARU FORESTER 2004 Service Repair Manual SE-8 SEAT Front Seat 9) Remove the hog rings (A) which secure the backrest cover and backrest pad. 10) Remove the headrest bushes. NOTE: Push the headrest bushes to outside of seat from inside, and th

Page 413 of 2870

SUBARU FORESTER 2004 Service Repair Manual SE-9 SEAT Front Seat 17) Remove the hog rings (A), and then remove the seat cushion cover from seat cushion pad. 18) Open the zipper at bottom of headrest, and then remove the headrest cover from head

Page 414 of 2870

SUBARU FORESTER 2004 Service Repair Manual SE-10 SEAT Front Seat 7) Open the zipper behind backrest. 8) Remove the hog rings (A) at side of inside back- rest from backrest frame. (Side airbag equipped seat) 9) Remove the hog rings (A) which se

Page 415 of 2870

SUBARU FORESTER 2004 Service Repair Manual SE-11 SEAT Front Seat 14) Loosen the bolts and nuts to remove the seat cushion from slide rail. 15) Remove the inner belt. 16) Remove the hooks (A), and then remove the seat cushion frame.17) Remove t

Page 416 of 2870

SUBARU FORESTER 2004 Service Repair Manual SE-12 SEAT Front Seat E: INSPECTION Inspect that there is no tear and fray on backrest cover assembly. NOTE: When there is tear or fray on the door side of back- rest cover assembly, replace the backr
