Page 2457 of 2870

4AT-143
AUTOMATIC TRANSMISSION
Transmission Control Device
2) Insert the range select lever, and then tighten
the bolt.
Tightening torque:
6 N
⋅m (0.6 kgf-m, 4.4 ft-lb)
3) Insert the manual plate and parking rod.
4) Insert the spring pin to manual plate.
5) Install the oil pan and control valve assembly.
Body.>
6) Turn over the transmission case to its original
position.
7) Install the pitching stopper bracket.
Tightening torque:
41 N
⋅m (4.2 kgf-m, 30.4 ft-lb)
8) Install and adjust the inhibitor switch.
4AT-51, Inhibitor Switch.>9) Insert the inhibitor switch and transmission con-
nector to the stay.
10) Install the air breather hose.
INSTALLATION, Air Breather Hose.>
11) Insert the input shaft with rotating it by hand
lightly, and then check the protrusion amount.
Normal protrusion A:
50 — 55 mm (1.97 — 2.17 in)
12) Install the torque converter clutch assembly.
er Clutch Assembly.>
13) Install the transmission assembly into the vehi-
cle.
Transmission Assembly.>
C: INSPECTION
Make sure the manual lever and detention spring
are not worn or otherwise damaged.
(A) Bolt
(B) Range select lever
(C) Manual plate
(D) Parking rod
AT-00308
AT-00306
AT-00305
(A) Transmission harness
(B) Inhibitor switch harness
AT-01351
(B)(A)
AT-00291
A
Page 2458 of 2870
4AT-144
AUTOMATIC TRANSMISSION
Transmission Control Device
Page 2459 of 2870

FUJI HEAVY INDUSTRIES LTD. G8080GE5
2004 FORESTER SERVICE MANUAL QUICK REFERENCE INDEX
TRANSMISSION SECTION
This service manual has been prepared
to provide SUBARU service personnel
with the necessary information and data
for the correct maintenance and repair
of SUBARU vehicles.
This manual includes the procedures
for maintenance, disassembling, reas-
sembling, inspection and adjustment of
components and diagnostics for guid-
ance of experienced mechanics.
Please peruse and utilize this manual
fully to ensure complete repair work for
satisfying our customers by keeping
their vehicle in optimum condition.
When replacement of parts during
repair work is needed, be sure to use
SUBARU genuine parts.
All information, illustration and specifi-
cations contained in this manual are
based on the latest product information
available at the time of publication
approval.CONTROL SYSTEM CS
AUTOMATIC TRANSMISSION 4AT
AUTOMATIC TRANSMISSION
(DIAGNOSTIC)4AT(H4SO)
AUTOMATIC TRANSMISSION
(DIAGNOSTIC)4AT(H4DOTC)
AUTOMATIC TRANSMISSION
(DIAGNOSTIC)4AT(H4DOTC 2.5)
MANUAL TRANSMISSION AND
DIFFERENTIAL5MT
CLUTCH SYSTEM CL
Page 2460 of 2870

AUTOMATIC TRANSMISSION
(DIAGNOSTIC)
4AT(H4SO)
Page
1. Basic Diagnostic Procedure ........................................................................2
2. Check List for Interview ...............................................................................4
3. General Description ....................................................................................5
4. Electrical Components Location..................................................................8
5. Transmission Control Module (TCM) I/O Signal .......................................12
6. Subaru Select Monitor...............................................................................17
7. Read Diagnostic Trouble Code (DTC) ......................................................20
8. Inspection Mode ........................................................................................22
9. Clear Memory Mode..................................................................................23
10. Power Indicator Light Display....................................................................24
11. Diagnostic Procedure for Subaru Select Monitor Communication ............32
12. List of Diagnostic Trouble Code (DTC) .....................................................35
13. Diagnostic Procedure with Diagnostic Trouble Code (DTC) .....................36
14. Diagnostic Procedure without Diagnostic Trouble Code (DTC) ................84
15. Symptom Related Diagnostic ..................................................................110
Page 2461 of 2870

4AT(H4SO)-2
AUTOMATIC TRANSMISSION (DIAGNOSTIC)
Basic Diagnostic Procedure
1. Basic Diagnostic Procedure
A: PROCEDURE
Step Check Yes No
1 CHECK PRE-INSPECTION.
1) Ask the customer when and how trouble
occurred using interview checklist.
4AT(H4SO)-4, Check List for Interview.>
2) Before performing the diagnosis, inspect
following items which might influence the AT
problems.
General inspection
INSPECTION, General Description.>
Disconnection of harness connector
Visually check the damage of harness
Oil leak
Stall speed test
Line pressure test
Pressure Test.>
Transfer clutch pressure test
38, Transfer Clutch Pressure Test.>
Time lag test
Te s t . >
Road test
Inhibitor switch
Switch.>Is the unit that might influence
AT problem normal?Go to step 2.Repair or replace
each item.
2 CHECK POWER INDICATOR LIGHT.
Turn the ignition switch to ON.Does the POWER indicator
light illuminate?Go to step 4.Go to step 3.
3 CHECK POWER INDICATOR LIGHT.
1) Turn the ignition switch to OFF.
2) Repair the POWER indicator light circuit or
power supply and ground line circuit.
Indicator Light Display.>
3) Turn the ignition switch to ON.Is the POWER indicator light
illuminate?Go to step 4.Go to step 5.
4 CHECK INDICATION OF DTC.
Calling up the DTC.
Without Subaru Select Monitor
SELECT MONITOR, OPERATION, Read
Diagnostic Trouble Code (DTC).>
With Subaru Select Monitor
SELECT MONITOR, OPERATION, Read
Diagnostic Trouble Code (DTC).>
NOTE:
If the communication function of select monitor
cannot be executed normally, check the communi-
cation circuit.
NICATION FOR INITIALIZING IMPOSSIBLE,
Diagnostic Procedure for Subaru Select Monitor
Communication.>Is the DTC displayed? Go to step 6.
NOTE:
Record all DTC.Go to step 5.
Page 2462 of 2870

4AT(H4SO)-3
AUTOMATIC TRANSMISSION (DIAGNOSTIC)
Basic Diagnostic Procedure
5 PERFORM THE GENERAL DIAGNOSTICS.
1) Inspect using “Diagnostic Procedure with-
out DTC”.
Procedure without Diagnostic Trouble Code
(DTC).>
2) Inspect using “Symptom Related Diagnostic”.
Diagnostic.>
3) Perform the clear memory mode.
Without Subaru Select Monitor
SELECT MONITOR, OPERATION, Clear
Memory Mode.>
With Subaru Select Monitor
SELECT MONITOR, OPERATION, Clear
Memory Mode.>
4) Perform the inspection mode.
4AT(H4SO)-22, Inspection Mode.>
5) Calling up the DTC.
Without Subaru Select Monitor
SELECT MONITOR, OPERATION, Read
Diagnostic Trouble Code (DTC).>
With Subaru Select Monitor
SELECT MONITOR, OPERATION, Read
Diagnostic Trouble Code (DTC).>Is the DTC displayed? Go to step 6.Complete the
diagnosis.
6 PERFORM THE DIAGNOSIS.
1) Inspect using “Diagnostics Chart with
DTC”.
cedure with Diagnostic Trouble Code (DTC).>
NOTE:
For DTC table, refer to “List of Diagnostic Trou-
ble Code (DTC)”.
of Diagnostic Trouble Code (DTC).>
2) Repair the trouble cause.
3) Perform the clear memory mode.
Without Subaru Select Monitor
SELECT MONITOR, OPERATION, Clear
Memory Mode.>
With Subaru Select Monitor
SELECT MONITOR, OPERATION, Clear
Memory Mode.>
4) Perform the inspection mode.
4AT(H4SO)-22, Inspection Mode.>
5) Calling up the DTC.
Without Subaru Select Monitor
SELECT MONITOR, OPERATION, Read
Diagnostic Trouble Code (DTC).>
With Subaru Select Monitor
SELECT MONITOR, OPERATION, Read
Diagnostic Trouble Code (DTC).>Is the DTC displayed? Inspect using “Diag-
nostics Chart with
Diagnostic Connec-
tor”.
4AT(H4SO)-36,
Diagnostic Proce-
dure with Diagnos-
tic Trouble Code
(DTC).>Complete the
diagnosis. Step Check Yes No
Page 2463 of 2870

4AT(H4SO)-4
AUTOMATIC TRANSMISSION (DIAGNOSTIC)
Check List for Interview
2. Check List for Interview
A: CHECK
Check the following items when problem has occurred.
NOTE:
Use copies of this page for interviewing customers.
Customer’s name
Date of purchase
Date of repair
Trans. model TRANSMISSION VIN
Odometer readingkm/h (miles)
Frequency❏ Continuous ❏ Intermittent ( times a day)
Weather❏ Fine ❏ Cloudy ❏ Rainy ❏ Snowy
❏ Others
()
Place❏ High ❏ Suburbs ❏ Inner city ❏ Uphill ❏ Rough road
❏ Others
()
Outdoor temperature❏ Hot ❏ Wa r m ❏ Cool ❏ Cold
Vehicle speedkm/h (MPH)
AT warning light (POWER indicator
light)❏ Continuously lit❏ Not lit
Select lever position❏ P ❏ R ❏ N ❏ D ❏ 3 ❏ 2 ❏ 1
Driving condition❏ Not affected
❏ At racing
❏ While decelerating❏ At starting
❏ While accelerating
❏ While turning (❏ RH/❏
LH)❏ While idling
❏ While cruising
POWER switch❏ ON ❏ OFF
HOLD switch❏ ON ❏ OFF
Symptoms❏ No up-shift
❏ No down-shift
❏ No kick down
❏ Vehicle does not move (❏ Any position ❏ Particular position)
❏ Lock-up malfunction
❏ Noise or vibration
❏ Shift shock or slip
❏ Select lever does not move
❏ Others
()
Page 2464 of 2870

4AT(H4SO)-5
AUTOMATIC TRANSMISSION (DIAGNOSTIC)
General Description
3. General Description
A: CAUTION
Supplemental Restraint System “Airbag”
The airbag system wiring harness is routed near
the transmission control module (TCM).
CAUTION:
All airbag system wiring harness and con-
nectors are colored yellow. Do not use an elec-
trical test equipment on these circuit.
Be careful not to damage the airbag system wir-
ing harness when performing diagnostics and ser-
vicing the TCM.
Measurement
When measuring the voltage and resistance of
ECM, TCM or each sensor, use a tapered pin with
diameter of less than 0.64 mm (0.025 in) in order to
avoid poor contact. Do not insert the pin more than
0.65 mm (0.256 in).
B: INSPECTION
1. BATTERY
Measure the battery voltage and specific gravity of
electrolyte.
Standard voltage: 12 V or more
Specific gravity: Above 1.260
2. TRANSMISSION GROUND
Make sure that the ground terminal bolt is tightened
securely.
Chassis side
Tightening torque:
13 N
⋅m (1.3 kgf-m, 9.4 ft-lb)
3. ATF LEVEL
Make sure that ATF level is in the specification.
mission Fluid.>
4. FRONT DIFFERENTIAL OIL LEVEL
Make sure that the front differential oil level is in speci-
fication.
Gear Oil.>
AT-00412
(A) Level gauge
(B) “HOT” side
(C) Upper level
(D) Lower level
(E) “COLD” side
(A) Upper level
(B) Lower level
PI-00105
COLD
LFHOT LF
(A)
(C)
(D)
(C)
(D)
(E)
(B)
AT-00317
(A)
(B)
LF
