Page 113 of 2870

AB-13
AIRBAG SYSTEM
Inspection Locations After a Collision
5. FRONT SUB SENSOR
If the front section of vehicle as shown in the figure
is damaged:
Check for the following, and replace damaged
parts with new ones.
Front sub sensor is cracked or deformed.
Mounting bracket is cracked or deformed.
Connector is scratched or cracked.
Airbag is deployed.
6. SIDE AIRBAG SENSOR
If the side section of vehicle as shown in the figure
is damaged:
Check for the following, and replace damaged
parts with new ones.
Side airbag sensor is cracked or deformed.
Mounting bracket is cracked or deformed.
Connector is scratched or cracked.
Side airbag is deployed. (operating side)
7. ROLL CONNECTOR
Check for the following, and replace damaged
parts with new ones.
Combination switch or steering roll connector is
cracked or deformed.
8. STEERING SHAFT
Check for the following, and replace damaged
parts with new ones.
Overall length of steering column should be with-
in specifications.
Specifications:
Overall length L
815.6
±1.5 mm (32.1±0.06 in)
If necessary, replace it with a new part.
AB-00029
AB-00030
AB-00717
L
Page 114 of 2870

AB-14
AIRBAG SYSTEM
Driver’s Airbag Module
4. Driver’s Airbag Module
A: REMOVAL
CAUTION:
Refer to “CAUTION” in General Description be-
fore handing the airbag module.
CAUTION, General Description.>
1) Position the front wheels straight ahead. (After
moving the vehicle more than 5 m (16 ft) with front
wheels positioned straight ahead, make sure that
the vehicle moves straight ahead).
2) Turn the ignition switch to OFF.
3) Disconnect the ground cable from battery, and
wait for at least 20 seconds before starting work.
4) Using the TORX
® BIT T30, remove the two
TORX® bolts on side of steering wheel.
5) Disconnect the airbag connector on the back of
airbag module, and then remove the airbag mod-
ule.
6) Refer to “CAUTION” for handling of removed air-
bag module.
scription.>
B: INSTALLATION
Install in the reverse order of removal.
CAUTION:
Do not allow harness and connectors to inter-
fere or get tangled up with other parts.
Tightening torque:
Refer to “COMPONENT” in “General Descrip-
tion”
NENT, General Description.>
C: INSPECTION
CAUTION:
Refer to “CAUTION” in General Description be-
fore handing the airbag module.
CAUTION, General Description.>
Check for the following, and replace damaged
parts with new ones.
Airbag module, harness, connector, and mounting
bracket are damaged.
AIRBAG MODULE, INSPECTION, Inspection Lo-
cations After a Collision.>
(1)
TORX® BIT T30
CC-00018
(1)
AB-00033
Page 115 of 2870

AB-15
AIRBAG SYSTEM
Passenger’s Airbag Module
5. Passenger’s Airbag Module
A: REMOVAL
CAUTION:
Refer to “CAUTION” in General Description be-
fore handing the airbag module.
CAUTION, General Description.>
1) Turn the ignition switch to OFF.
2) Disconnect the ground cable from battery, and
wait for at least 20 seconds before starting work.
3) Remove the glove box.
AL, Glove Box.>
4) Detach the airbag connector from support beam
bracket, and then disconnect the airbag connector.
5) Remove the three bolts, and then carefully re-
move the airbag module.
6) Refer to “CAUTION” for handling of removed air-
bag module.
Description.>
B: INSTALLATION
Install in the reverse order of removal.
CAUTION:
Do not allow harness and connectors to inter-
fere or get tangled up with other parts.
Tightening torque:
Refer to “COMPONENT” in “General Descrip-
tion”
NENT, General Description.>
C: INSPECTION
CAUTION:
Refer to “CAUTION” in General Description be-
fore handing the airbag module.
CAUTION, General Description.>
Check for the following, and replace damaged
parts with new ones.
Airbag module, harness, connector, and mounting
bracket are damaged.
GER’S AIRBAG MODULE, INSPECTION, Inspec-
tion Locations After a Collision.>
AB-00117
Page 116 of 2870

AB-16
AIRBAG SYSTEM
Side Airbag Module
6. Side Airbag Module
A: REMOVAL
CAUTION:
Before working on the airbag module, refer to
the “CAUTION” in General Description.
AB-3, CAUTION, General Description.>
NOTE:
Remove the passenger’s side by referring to driv-
er’s side.
1) Turn the ignition switch to OFF.
2) Disconnect the ground cable from battery, and
wait for at least 20 seconds before starting work.
3) Remove the front seat from the vehicle.
SE-6, REMOVAL, Front Seat.>
4) Remove the clip from slide rail IN (A) and re-
verse side of seat cushion assembly, and then re-
move the side airbag harness.
5) Remove the backrest cover.
ASSEMBLY, Front Seat.>
6) Remove the side airbag harness from backrest
frame assembly.7) Remove the side airbag module (A) from back-
rest frame assembly.
B: INSTALLATION
1) Ensure there are no foreign particles on side air-
bag module.
2) Install the side airbag module (A) to backrest
frame assembly.
Tightening torque:
5.9 N·m (0.59 kgf-m, 4.4 ft-lb)
AB-00474
(A)
AB-00475
AB-00476
(A)
AB-00477
(A)
Page 117 of 2870

AB-17
AIRBAG SYSTEM
Side Airbag Module
3) Install the side airbag harness to backrest frame
assembly.
NOTE:
Secure the harness to its original position of seat.
4) Install the backrest cover.
SEMBLY, Front Seat.>
5) Install the side airbag harness to slide rail IN (A).
6) Recline the seat or slide it backward and for-
ward. Check there is no contact between seat
backrest assembly, cushion cover assembly and
side airbag harness. C: INSPECTION
CAUTION:
Before working on the airbag module, refer to
the “CAUTION” in General Description.
AB-3, CAUTION, General Description.>
Perform the inspection of following items, and replace
the damaged parts with new ones.
SIDE AIRBAG MODULE, INSPECTION, Inspec-
tion Locations After a Collision.>
1) With side clash (when side airbag is deployed)
Side airbag module assembly
Backrest pad assembly
Backrest frame assembly
Backrest cover assembly
damaged by visual check>
Headrest assembly
Bushing
Slide rail OUT
Slide rail IN
Seat hinge cover
Seat lifter lever
Reclining lever
Side airbag harness and connector (body side)
2) With side clash (when side airbag is not de-
ployed)
Check the seat and airbag module visually, and
then replace them with new ones if damaged or
cracked.
Specially inspect the damage of airbag module
body, installing bracket, harness connector.
3) Without side clash (dirt and damage of cover)
Replace the corresponding part with a new one.
AB-00475
AB-00474
(A)
Page 118 of 2870

AB-18
AIRBAG SYSTEM
Airbag Control Module
7. Airbag Control Module
A: REMOVAL
CAUTION:
Do not disassemble the airbag control mod-
ule.
If the airbag control module is deformed or if
water damage is suspected, replace the airbag
control module with a new part.
Do not drop the airbag control module.
After removal, keep the airbag control mod-
ule on a dry, clean surface away from moisture,
heat, and dust.
1) Turn the ignition switch to OFF.
2) Disconnect the ground cable from battery, and
wait for at least 20 seconds before starting work.
3) Remove the console cover.
MOVAL, Console Box.>
4) Remove the center console panel.
40, REMOVAL, Instrument Panel Assembly.>
5) Disconnect the connector from airbag control
module.
6) Remove the four bolts, and then remove the air-
bag control module.
B: INSTALLATION
CAUTION:
Use new bolts (for airbag control module only)
during reassembly.
Install in the reverse order of removal.
Tightening torque:
Refer to “COMPONENT” in “General Descrip-
tion”
NENT, General Description.>
C: INSPECTION
Check for the following, and replace damaged
parts with new ones.
Control module, connector, and mounting brack-
et are damaged.
Airbag is deployed.
Side airbag is deployed.
AB-00035
Page 119 of 2870
AB-19
AIRBAG SYSTEM
Side Airbag Sensor
8. Side Airbag Sensor
A: REMOVAL
1) Turn the ignition switch to OFF.
2) Disconnect the ground cable from battery, and
wait for at least 20 seconds before starting work.
3) Remove the outer belt (FRONT).
10, FRONT OUTER BELT, REMOVAL, Front Seat
Belt.>
4) Detach the side airbag sensor, and then discon-
nect the airbag connector.
B: INSTALLATION
CAUTION:
Use new TORX® bolts T30 when reassembling.
Install in the reverse order of removal.
Tightening torque:
Refer to “COMPONENT” in “General Descrip-
tion”
NENT, General Description.>
C: INSPECTION
Check for the following, and replace damaged
parts with new parts.
Bracket connector for side airbag sensor is dam-
aged.
Side airbag is deployed.
AB-00036
Page 120 of 2870

AB-20
AIRBAG SYSTEM
Roll Connector
9. Roll Connector
A: REMOVAL
1) Turn the ignition switch to OFF.
2) Disconnect the ground cable from battery, and
wait for at least 20 seconds before starting work.
3) Remove the driver’s airbag module.
14, Driver’s Airbag Module.>
4) Remove the steering wheel.
MOVAL, Steering Wheel.>
5) Remove the steering column cover.
6) Remove the screws, and then remove the roll
connector.
B: INSTALLATION
1) Install in the reverse order of removal.
2) Before installing the steering wheel, be sure the
direction of roll connector is adjusted with steering.
C: INSPECTION
Check for the following, and replace damaged parts
with new parts.
Combination switch and roll connector are cracked
or deformed.
D: ADJUSTMENT
1) Check that the front wheels are positioned in
straight ahead direction.
2) Turn the roll connector pin (A) clockwise until it
stops.
3) Turn the roll connector pin (A) counterclockwise
approx. 2.65 turns until “▲” marks are aligned.
AB-00593
AB-00594
(A)
