INFINITI FX35 2007 Service Manual ENGINE COOLANT CO-11 [VQ35DE] C D E F G H I J K L M A CO Revision: 2006 July 2007 FX35/FX45 ENGINE COOLANTPFP:KQ100 InspectionNBS003JU LEVEL CHECK Check if the reservoir tank engine cool

Page 1202 of 4366

INFINITI FX35 2007 Service Manual CO-12 [VQ35DE] ENGINE COOLANT Revision: 2006 July 2007 FX35/FX45 4. Check drained engine coolant for contaminants such as rust, corrosion or discoloration. If contaminated, flush the engine cooling s

Page 1203 of 4366

INFINITI FX35 2007 Service Manual ENGINE COOLANT CO-13 [VQ35DE] C D E F G H I J K L M A CO Revision: 2006 July 2007 FX35/FX45 If necessary, refill radiator up to filler neck with engine coolant. 8. Refill reservoir tank

Page 1204 of 4366

INFINITI FX35 2007 Service Manual CO-14 [VQ35DE] RADIATOR Revision: 2006 July 2007 FX35/FX45 RADIATORPFP:21400 ComponentsNBS003JW Refer to GI-11, "Components" for symbol marks in the figure. Removal and InstallationNBS003JX REMOVAL

Page 1205 of 4366

INFINITI FX35 2007 Service Manual RADIATOR CO-15 [VQ35DE] C D E F G H I J K L M A CO Revision: 2006 July 2007 FX35/FX45 4. Remove reservoir tank and reservoir tank bracket. 5. Disconnect A/T fluid cooler hoses from radia

Page 1206 of 4366

INFINITI FX35 2007 Service Manual CO-16 [VQ35DE] RADIATOR Revision: 2006 July 2007 FX35/FX45 Pull negative-pressure valve to open it, and make sure that it close completely when released. –Make sure that there is no dirt or damage

Page 1207 of 4366

INFINITI FX35 2007 Service Manual RADIATOR (ALUMINUM TYPE) CO-17 [VQ35DE] C D E F G H I J K L M A CO Revision: 2006 July 2007 FX35/FX45 RADIATOR (ALUMINUM TYPE)PFP:21460 ComponentsNBS003K0 Disassembly and AssemblyNBS003K1

Page 1208 of 4366

INFINITI FX35 2007 Service Manual CO-18 [VQ35DE] RADIATOR (ALUMINUM TYPE) Revision: 2006 July 2007 FX35/FX45 Grip the crimped edge and bend it upwards so that the radia- tor plate pliers B slips off. CAUTION: Do not bend excessive
