INFINITI FX35 2007 Service Manual POSITIVE CRANKCASE VENTILATION EC-713
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 July 2007 FX35/FX45
PCV VALVE VENTILATION HOSE
1. Check hoses and hose connections for leaks.
2.

Page 2090 of 4366

INFINITI FX35 2007 Service Manual EC-714
[VK45DE]
IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS)
Revision: 2006 July 2007 FX35/FX45
IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS)PFP:28591
DescriptionNBS0041J
If the security indicat

Page 2091 of 4366

INFINITI FX35 2007 Service Manual ON BOARD DIAGNOSTIC (OBD) SYSTEM EC-715
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 July 2007 FX35/FX45
ON BOARD DIAGNOSTIC (OBD) SYSTEMPFP:00028
IntroductionNBS004JR
The ECM has a

ON BOARD DIAGNOSTIC (OBD) SYSTEM EC-715
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 July 2007 FX35/FX45
ON BOARD DIAGNOSTIC (OBD) SYSTEMPFP:00028
IntroductionNBS004JR
The ECM has an on board diagnostic system, which detects malfunctions related to engine sensors or actua-
tors. The ECM also records various emission-related diagnostic information including:
The above information can be checked using procedures listed in the table below.
× : Applicable —: Not applicable
*: When DTC and 1st trip DTC simultaneously appear on the display, they cannot be clearly distinguished from each other.
The malfunction indicator lamp (MIL) on the instrument panel lights up when the same malfunction is detected
in two consecutive trips (Two trip detection logic), or when the ECM enters fail-safe mode. (Refer to EC-757,
"Fail-Safe Chart" .)
Two Trip Detection LogicNBS004JS
When a malfunction is detected for the first time, 1st trip DTC and 1st trip Freeze Frame data are stored in the
ECM memory. The MIL will not light up at this stage. <1st trip>
If the same malfunction is detected again during the next drive, the DTC and Freeze Frame data are stored in
the ECM memory, and the MIL lights up. The MIL lights up at the same time when the DTC is stored. <2nd
trip> The “trip” in the “Two Trip Detection Logic” means a driving mode in which self-diagnosis is performed
during vehicle operation. Specific on board diagnostic items will cause the ECM to light up or blink the MIL,
and store DTC and Freeze Frame data, even in the 1st trip, as shown below.
× : Applicable —: Not applicable
When there is an open circuit on MIL circuit, the ECM cannot warn the driver by lighting up MIL when there is
malfunction on engine control system.
Emission-related diagnostic information Diagnostic service
Diagnostic Trouble Code (DTC) Service $03 of SAE J1979
Freeze Frame data Service $02 of SAE J1979
System Readiness Test (SRT) code Service $01 of SAE J1979
1st Trip Diagnostic Trouble Code (1st Trip DTC) Service $07 of SAE J1979
1st Trip Freeze Frame data
Test values and Test limits Service $06 of SAE J1979
Calibration ID Service $09 of SAE J1979
DTC 1st trip DTC Freeze
Frame data 1st trip Freeze
Frame data SRT code SRT status Test value
CONSULT-II ×× × × × × —
GST ×× × —×××
ECM ××*— — — ×—
Items MIL DTC 1st trip DTC
1st trip 2nd trip 1st trip
displaying 2nd trip
displaying 1st trip
displaying 2nd trip
display- ing
Blinking Lighting
up Blinking
Lighting
up
Misfire (Possible three way cata-
lyst damage) — DTC: P0300 -
P0308 is being detected ×
———— — ×—
Misfire (Possible three way cata-
lyst damage) — DTC: P0300 -
P0308 is being detected ——
×—— ×——
One trip detection diagnoses
(Refer to EC-716, "
EMISSION-
RELATED DIAGNOSTIC INFOR-
MATION ITEMS" .) —
×—— ×———
Except above — — — ×— ×× —

Page 2092 of 4366

INFINITI FX35 2007 Service Manual EC-716
[VK45DE]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Revision: 2006 July 2007 FX35/FX45
Therefore, when electrical controlled throttle and part of ECM related diagnoses are continuously detected as
NG fo

EC-716
[VK45DE]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Revision: 2006 July 2007 FX35/FX45
Therefore, when electrical controlled throttle and part of ECM related diagnoses are continuously detected as
NG for 5 trips, ECM warns the driver that engine control system malfunctions and MIL circuit is open by means
of operating fail-safe function.
The fail-safe function also operates when above diagnoses except MIL circuit are detected and demands the
driver to repair the malfunction.
Emission-related Diagnostic InformationNBS004JT
EMISSION-RELATED DIAGNOSTIC INFORMATION ITEMS
× :Applicable —: Not applicable
Engine operating condition in fail-safe mode Engine speed will not rise more than 2,500 rpm due to the fuel cut
Items
(CONSULT-II screen terms) DTC*
1
SRT code
Test value/
Te s t l i m i t
(GST only) Trip MIL
Reference
page
CONSULT-II
GST*
2ECM*3
CAN COMM CIRCUIT U1000 1000*4—— 1 ×EC-820
CAN COMM CIRCUIT U1001
1001*4— — 1 or 2 — EC-820
CONTROL UNIT(CAN) U1010 1010 — — 1 ×EC-823
NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED. P0000 0000
———
Flashing *8EC-724
INT/V TIM CONT-B1 P0011 0011 — — 2 ×EC-825
INT/V TIM CONT-B2 P0021 0021 — — 2 ×EC-825
A/F SEN1 HTR (B1) P0031 0031 — ×2 ×EC-837
A/F SEN1 HTR (B1) P0032 0032 — ×2 ×EC-837
HO2S2 HTR (B1) P0037 0037 — ×2 ×EC-844
HO2S2 HTR (B1) P0038 0038 — ×2 ×EC-844
A/F SEN1 HTR (B2) P0051 0051 — ×2 ×EC-837
A/F SEN1 HTR (B2) P0052 0052 — ×2 ×EC-837
HO2S2 HTR (B2) P0057 0057 — ×2 ×EC-844
HO2S2 HTR (B2) P0058 0058 — ×2 ×EC-844
INT/V TIM V/CIR-B1 P0075 0075 — — 2 ×EC-852
INT/V TIM V/CIR-B2 P0081 0081 — — 2 ×EC-852
MAF SEN/CIRCUIT P0101 0101 — — 2 ×EC-859
MAF SEN/CIRCUIT P0102 0102 — — 1 ×EC-868
MAF SEN/CIRCUIT P0103 0103 — — 1 ×EC-868
IAT SEN/CIRCUIT P0112 0112 — — 2 ×EC-875
IAT SEN/CIRCUIT P0113 0113 — — 2 ×EC-875
ECT SEN/CIRC P0117 0117 — — 1 ×EC-880
ECT SEN/CIRC P0118 0118 — — 1 ×EC-880
TP SEN 2/CIRC P0122 0122 — — 1 ×EC-886
TP SEN 2/CIRC P0123 0123 — — 1 ×EC-886
ECT SENSOR P0125 0125 — — 2 ×EC-893
IAT SENSOR P0127 0127 — — 2 ×EC-896
THERMSTAT FNCTN P0128 0128 — — 2 ×EC-899
A/F SENSOR1 (B1) P0130 0130 — ×2 ×EC-901
A/F SENSOR1 (B1) P0131 0131 — ×2 ×EC-911
A/F SENSOR1 (B1) P0132 0132 — ×2 ×EC-920
A/F SENSOR1 (B1) P0133 0133 ××2×EC-929
HO2S2 (B1) P0137 0137 ××2×EC-941

Page 2093 of 4366

INFINITI FX35 2007 Service Manual ON BOARD DIAGNOSTIC (OBD) SYSTEM EC-717
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 July 2007 FX35/FX45HO2S2 (B1) P0138 0138××2×EC-952
HO2S2 (B1) P0139 0139 ××2×EC-965
A/F SE

ON BOARD DIAGNOSTIC (OBD) SYSTEM EC-717
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 July 2007 FX35/FX45HO2S2 (B1) P0138 0138××2×EC-952
HO2S2 (B1) P0139 0139 ××2×EC-965
A/F SENSOR1 (B2) P0150 0150 — ×2 ×EC-901
A/F SENSOR1 (B2) P0151 0151 — ×2 ×EC-911
A/F SENSOR1 (B2) P0152 0152 — ×2 ×EC-920
A/F SENSOR1 (B2) P0153 0153 ××2×EC-929
HO2S2 (B2) P0157 0157 ××2×EC-941
HO2S2 (B2) P0158 0158 ××2×EC-952
HO2S2 (B2) P0159 0159 ××2×EC-965
FUEL SYS-LEAN-B1 P0171 0171 — — 2 ×EC-976
FUEL SYS-RICH-B1 P0172 0172 — — 2 ×EC-987
FUEL SYS-LEAN-B2 P0174 0174 — — 2 ×EC-976
FUEL SYS-RICH-B2 P0175 0175 — — 2 ×EC-987
FTT SENSOR P0181 0181 — — 2 ×EC-998
FTT SEN/CIRCUIT P0182 0182 — — 2 ×EC-1004
FTT SEN/CIRCUIT P0183 0183 — — 2 ×EC-1004
TP SEN 1/CIRC P0222 0222 — — 1 ×EC-1009
TP SEN 1/CIRC P0223 0223 — — 1 ×EC-1009
MULTI CYL MISFIRE P0300 0300 — — 2 ×EC-1016
CYL 1 MISFIRE P0301 0301 — — 2 ×EC-1016
CYL 2 MISFIRE P0302 0302 — — 2 ×EC-1016
CYL 3 MISFIRE P0303 0303 — — 2 ×EC-1016
CYL 4 MISFIRE P0304 0304 — — 2 ×EC-1016
CYL 5 MISFIRE P0305 0305 — — 2 ×EC-1016
CYL 6 MISFIRE P0306 0306 — — 2 ×EC-1016
CYL 7 MISFIRE P0307 0307 — — 2 ×EC-1016
CYL 8 MISFIRE P0308 0308 — — 2 ×EC-1016
KNOCK SEN/CIRC-B1 P0327 0327 — — 2 — EC-1026
KNOCK SEN/CIRC-B1 P0328 0328 — — 2 —EC-1026
KNOCK SEN/CIRC-B2 P0332 0332 — — 2 —EC-1026
KNOCK SEN/CIRC-B2 P0333 0333 — — 2 —EC-1026
CKP SEN/CIRCUIT P0335 0335 — — 2×EC-1031
CMP SEN/CIRC-B1 P0340 0340 — — 2 ×EC-1038
TW CATALYST SYS-B1 P0420 0420 ××2×EC-1045
TW CATALYST SYS-B2 P0430 0430 ××2×EC-1045
EVAP PURG FLOW/MON P0441 0441 ××2×EC-1051
EVAP SMALL LEAK P0442 0442 ××2×EC-1056
PURG VOLUME CONT/V P0443 0443 — — 2 ×EC-1065
PURG VOLUME CONT/V P0444 0444 — — 2 ×EC-1073
PURG VOLUME CONT/V P0445 0445 — — 2 ×EC-1073
VENT CONTROL VALVE P0447 0447 — — 2 ×EC-1080
VENT CONTROL VALVE P0448 0448 — — 2 ×EC-1087
Items
(CONSULT-II screen terms) DTC*
1
SRT code
Test value/
Test limit
(GST only) Trip MIL
Reference
page
CONSULT-II
GST*
2ECM*3

Page 2094 of 4366

INFINITI FX35 2007 Service Manual EC-718
[VK45DE]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Revision: 2006 July 2007 FX35/FX45
EVAP SYS PRES SEN P0451 0451 — — 2 ×EC-1093
EVAP SYS PRES SEN P0452 0452 — — 2 ×EC-1096
EVAP SYS PRES SEN

EC-718
[VK45DE]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Revision: 2006 July 2007 FX35/FX45
EVAP SYS PRES SEN P0451 0451 — — 2 ×EC-1093
EVAP SYS PRES SEN P0452 0452 — — 2 ×EC-1096
EVAP SYS PRES SEN P0453 0453 — — 2 ×EC-1102
EVAP GROSS LEAK P0455 0455 — — 2 ×E C - 111 0
EVAP VERY SML LEAK P0456 0456
× *7× 2 ×E C - 111 8
FUEL LEV SEN SLOSH P0460 0460 — — 2 ×EC-1127
FUEL LEVEL SENSOR P0461 0461 — — 2 ×EC-1129
FUEL LEVL SEN/CIRC P0462 0462 — — 2 ×EC-1131
FUEL LEVL SEN/CIRC P0463 0463 — — 2 ×EC-1131
VEH SPEED SEN/CIRC*5P0500 0500 — — 2 ×EC-1133
ISC SYSTEM P0506 0506 — — 2 ×EC-1135
ISC SYSTEM P0507 0507 — — 2 ×EC-1137
PW ST P SEN/CIRC P0550 0550 — — 2 — EC-1139
ECM BACK UP/CIRCUIT P0603 0603 — — 2×EC-1144
ECM P0605 0605 — — 1 or 2 × or — EC-1148
SENSOR POWER/CIRC P0643 0643 — — 1 ×EC-1151
TCM P0700 0700 — — 1 ×AT- 111
PNP SW/CIRC P0705 0705 — — 2 ×AT- 11 2
ATF TEMP SEN/CIRC P0710 0710 — — 2 ×AT- 1 3 4
TURBINE SENSOR P0717 0717 — — 2 ×AT- 11 6
VEH SPD SEN/CIR AT*5P0720 0720 — — 2 ×AT- 11 8
TCC SOLENOID/CIRC P0740 0740 — — 2 ×AT- 1 2 5
A/T TCC S/V FNCTN P0744 0744 — — 2 ×AT- 1 2 7
L/PRESS SOL/CIRC P0745 0745 — — 2 ×AT- 1 2 9
P-N POS SW/CIRCUIT P0850 0850 — — 2 ×EC-1156
INTK TIM S/CIRC-B1 P1140 1140 — — 2 ×EC-1161
INTK TIM S/CIRC-B2 P1145 1145 — — 2 ×EC-1161
CLOSED LOOP-B1 P1148 1148 — — 1 ×EC-1170
CLOSED LOOP-B2 P1168 1168 — — 1 ×EC-1170
TCS C/U FUNCTN P1211 1211 — — 2 — EC-1171
TCS/CIRC P1212 1212 — — 2 —EC-1172
ENG OVER TEMP P1217 1217 — — 1×EC-1173
CTP LEARNING P1225 1225 — — 2 — EC-1185
CTP LEARNING P1226 1226 — — 2 —EC-1187
COLD START CONTROL P1421 1421 — — 2×EC-1189
ASCD SW P1564 1564 — — 1 — EC-1191

(Models
with ICC) EC-1198

(Models
with ASCD)
ACC COMMAND VALUE*
6P1568 1568 — — 1 — EC-1205
Items
(CONSULT-II screen terms) DTC*
1
SRT code
Test value/
Te s t l i m i t
(GST only) Trip MIL
Reference
page
CONSULT-II
GST*
2ECM*3

Page 2095 of 4366

INFINITI FX35 2007 Service Manual ON BOARD DIAGNOSTIC (OBD) SYSTEM EC-719
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 July 2007 FX35/FX45
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed b

ON BOARD DIAGNOSTIC (OBD) SYSTEM EC-719
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 July 2007 FX35/FX45
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: The troubleshooting for this DTC needs CONSULT-II.
*5: When the fail-safe operations for both self-diagnoses occur, the MIL illuminates.
*6: Models with ICC.
*7: SRT code will not be set if the self-diagnostic result is NG. ASCD BRAKE SW P1572 1572 — — 1 —
EC-1206

(Models
with ICC) EC-1215

(Models
with ASCD)
ASCD VHL SPD SEN P1574 1574 — — 1 — EC-1223

(Models
with ICC) EC-1225

(Models
with ASCD)
NATS MALFUNCTION P1610 - P1615 1610 - 1615 — — 2 — EC-714
IN PULY SPEED P1715 1715 — — 2 —EC-1227
A/T INTERLOCK P1730 1730 — — 1×AT-141
I/C SOLENOID/CIRC P1752 1752 — — 1 ×AT-146
I/C SOLENOID FNCTN P1754 1754 — — 1 ×AT-148
FR/B SOLENOID/CIRC P1757 1757 — — 1 ×AT-150
FR/B SOLENOID FNCT P1759 1759 — — 1 ×AT-152
D/C SOLENOID/CIRC P1762 1762 — — 1 ×AT-154
D/C SOLENOID FNCTN P1764 1764 — — 1 ×AT-156
HLR/C SOL/CIRC P1767 1767 — — 1 ×AT-158
HLR/C SOL FNCTN P1769 1769 — — 1 ×AT-160
LC/B SOLENOID/CIRC P1772 1772 — — 1 ×AT-162
LC/B SOLENOID FNCT P1774 1774 — — 1 ×AT-164
VIAS S/V CIRC P1800 1800 — — 2 — EC-1228
BRAKE SW/CIRCUIT P1805 1805 — — 2 —EC-1233
ETC MOT PWR P2100 2100 — — 1×EC-1238
ETC FUNCTION/CIRC P2101 2101 — — 1 ×EC-1244
ETC MOT PWR P2103 2103 — — 1 ×EC-1238
ETC MOT P2118 2118 — — 1 ×EC-1251
ETC ACTR P2119 2119 — — 1 ×EC-1256
APP SEN 1/CIRC P2122 2122 — — 1 ×EC-1258
APP SEN 1/CIRC P2123 2123 — — 1 ×EC-1258
APP SEN 2/CIRC P2127 2127 — — 1 ×EC-1265
APP SEN 2/CIRC P2128 2128 — — 1 ×EC-1265
TP SENSOR P2135 2135 — — 1 ×EC-1272
APP SENSOR P2138 2138 — — 1 ×EC-1279
A/F SENSOR1 (B1) P2A00 2A00 — ×2 ×EC-1287
A/F SENSOR1 (B2) P2A03 2A03 — ×2 ×EC-1287
Items
(CONSULT-II screen terms) DTC*
1
SRT code
Test value/
Test limit
(GST only) Trip MIL
Reference
page
CONSULT-II
GST*
2ECM*3

Page 2096 of 4366

INFINITI FX35 2007 Service Manual EC-720
[VK45DE]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Revision: 2006 July 2007 FX35/FX45
*8: When the ECM is in the mode of displaying SRT status, MIL may flash. For the details, refer to EC-724, "How to

EC-720
[VK45DE]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Revision: 2006 July 2007 FX35/FX45
*8: When the ECM is in the mode of displaying SRT status, MIL may flash. For the details, refer to EC-724, "How to Display SRT Status"
.
DTC AND 1ST TRIP DTC
The 1st trip DTC (whose number is the same as the DTC number) is displayed for the latest self-diagnostic
result obtained. If the ECM memory was cleared previously, and the 1st trip DTC did not reoccur, the 1st trip
DTC will not be displayed.
If a malfunction is detected during the 1st trip, the 1st trip DTC is stored in the ECM memory. The MIL will not
light up (two trip detection logic). If the same malfunction is not detected in the 2nd trip (meeting the required
driving pattern), the 1st trip DTC is cleared from the ECM memory. If the same malfunction is detected in the
2nd trip, both the 1st trip DTC and DTC are stored in the ECM memory and the MIL lights up. In other words,
the DTC is stored in the ECM memory and the MIL lights up when the same malfunction occurs in two consec-
utive trips. If a 1st trip DTC is stored and a non-diagnostic operation is performed between the 1st and 2nd
trips, only the 1st trip DTC will continue to be stored. For malfunctions that blink or light up the MIL during the
1st trip, the DTC and 1st trip DTC are stored in the ECM memory.
Procedures for clearing the DTC and the 1st trip DTC from the ECM memory are described in EC-728, "
HOW
TO ERASE EMISSION-RELATED DIAGNOSTIC INFORMATION" .
For malfunctions in which 1st trip DTCs are displayed, refer to EC-716, "
EMISSION-RELATED DIAGNOSTIC
INFORMATION ITEMS" . These items are required by legal regulations to continuously monitor the system/
component. In addition, the items monitored non-continuously are also displayed on CONSULT-II.
1st trip DTC is specified in Service $07 of SAE J1979. 1st trip DTC detection occurs without lighting up the MIL
and therefore does not warn the driver of a malfunction. However, 1st trip DTC detection will not prevent the
vehicle from being tested, for example during Inspection/Maintenance (I/M) tests.
When a 1st trip DTC is detected, check, print out or write down and erase (1st trip) DTC and Freeze Frame
data as specified in Work Flow procedure Step 2, refer to EC-750, "
WORK FLOW" . Then perform DTC Con-
firmation Procedure or Overall Function Check to try to duplicate the malfunction. If the malfunction is dupli-
cated, the item requires repair.
How to Read DTC and 1st Trip DTC
DTC and 1st trip DTC can be read by the following methods.
With CONSULT-II
With GST
CONSULT-II or GST (Generic Scan Tool) Examples: P0340, P0850, P1148, etc.
These DTCs are prescribed by SAE J2012.
(CONSULT-II also displays the malfunctioning component or system.)
No Tools
The number of blinks of the MIL in the Diagnostic Test Mode II (Self-Diagnostic Results) indicates the DTC.
Example: 0340, 0850, 1148, etc.
These DTCs are controlled by NISSAN.
1st trip DTC No. is the same as DTC No.
Output of a DTC indicates a malfunction. However, GST or the Diagnostic Test Mode II do not indi-
cate whether the malfunction is still occurring or has occurred in the past and has returned to nor-
mal. CONSULT-II can identify malfunction status as shown below. Therefore, using CONSULT-II (if
available) is recommended.
A sample of CONSULT-II display for DTC and 1st trip DTC is shown below. DTC or 1st trip DTC of a malfunc-
tion is displayed in SELF-DIAGNOSTIC RESULTS mode of CONSULT-II. Time data indicates how many times
the vehicle was driven after the last detection of a DTC.
If the DTC is being detected currently, the time data will be [0].
If a 1st trip DTC is stored in the ECM, the time data will be [1t].
PBIB0911E

Load next 8 pages

Page: < prev 1-10 ... 2057-2064 2065-2072 2073-2080 2081-2088 2089-2096 2097-2104 2105-2112 2113-2120 2121-2128 ... 4368 next >

remove seats lumbar support low beam fuse box CD changer dimensions
