Page 3865 of 4366

INFINITI FX35 2007 Service Manual POWER STEERING GEAR AND LINKAGE PS-25
C
D E
F
H I
J
K L
M A
B
PS
Revision: 2006 July 2007 FX35/FX45
Axial End Play
Apply load of 490 N (50 kg, 110 lb) to ball stud axially. Use a dial
g

Page 3866 of 4366

INFINITI FX35 2007 Service Manual PS-26
POWER STEERING GEAR AND LINKAGE
Revision: 2006 July 2007 FX35/FX45
a. To avoid damaging inner rack oil seal, wrap an OHP sheet
[approximately. 70 mm (2.76 in) × 100 mm (3.94 in) around rack

Page 3867 of 4366

INFINITI FX35 2007 Service Manual POWER STEERING GEAR AND LINKAGE PS-27
C
D E
F
H I
J
K L
M A
B
PS
Revision: 2006 July 2007 FX35/FX45
10. Confirm projection on rear cover cap nearly fit with marking position on gear housi

POWER STEERING GEAR AND LINKAGE PS-27
C
D E
F
H I
J
K L
M A
B
PS
Revision: 2006 July 2007 FX35/FX45
10. Confirm projection on rear cover cap nearly fit with marking position on gear housing assembly.
11. Apply recommended thread locking sealant to the thread (2 turns thread), and then screw in the adjusting screw until it
reaches height “H” from gear housing assembly measured
before disassembling.
12. Rotate pinion ten times whole range of rack so that parts get to fit with each other.
13. Measure pinion rotating torque within from –180 ° to +180 °,
make preload gauge (SST) and torque adapter (SST) in rack
neutral position, then hold preload gauge (SST) at maximum
torque.
14. After loosening adjusting screw once, tighten it again with torque of 5.4 N·m (0.55 kg-m, 48 in-lb). After that loosen it within 20 ° to
40 °.
15. Measure pinion rotating torque with torque adapter (SST) and preload gauge (SST), then confirm whether it's reading is within
the specified value. If the reading is not within the specified
value, readjust screw angle with adjusting screw. Change gear
assembly to new one, if the reading is still not within the speci-
fied value or the rotating torque of adjusting screw is less than 5
N·m (0.51 kg-m, 44 in-lb).
16. Turn pinion fully to the end of the left with inner socket to gear housing assembly.
17. Set dial gauge to rack as shown in the figure. Measure vertical movement of rack when pinion is turned counterclockwise with
torque of 19.6 N·m (2.0 kg-m, 14 ft-lb). Check reading is within
the specified value. If reading is outside of the specification,
readjust screw angle with adjusting screw. If reading is still out-
side of specification, or if the rotating torque of adjusting screw is
less than 5 N·m (0.51 kg-m, 44 in-lb), replace steering gear
assembly.
SGIA0568E
SGIA0483E
Pinion rotating torque:
Around neutral position (within ±100 °)
Average “A”:
0.8 − 2.0 N·m (0.08 − 0.20 kg-m, 7 − 18 in-lb)
Other than above (more than ±100 °)
Maximum variation “B”:
2.3 N·m (0.23 kg-m, 20 in-lb)
SGIA0160E
SGIA0484E
Amount of vertical movement with rack Less than 0.265 mm (0.01 in)

Page 3868 of 4366

INFINITI FX35 2007 Service Manual PS-28
POWER STEERING GEAR AND LINKAGE
Revision: 2006 July 2007 FX35/FX45
18. Install large-diameter side of boot to gear housing assembly.
19. Install small-diameter side of boot to the mounting groo

Page 3869 of 4366

INFINITI FX35 2007 Service Manual POWER STEERING GEAR AND LINKAGE PS-29
C
D E
F
H I
J
K L
M A
B
PS
Revision: 2006 July 2007 FX35/FX45
24. Tighten lightly inner socket in specified length “L”, then tighten
lock nut at

Page 3870 of 4366

INFINITI FX35 2007 Service Manual PS-30
POWER STEERING OIL PUMP
Revision: 2006 July 2007 FX35/FX45
POWER STEERING OIL PUMPPFP:49110
On-Vehicle Inspection and ServiceNGS000C5
CHECKING RELIEF OIL PRESSURE (VQ35DE MODELS)
CAUTION:
Befor

Page 3871 of 4366

INFINITI FX35 2007 Service Manual POWER STEERING OIL PUMP PS-31
C
D E
F
H I
J
K L
M A
B
PS
Revision: 2006 July 2007 FX35/FX45
CHECKING RELIEF OIL PRESSURE (VK45DE MODELS)
CAUTION:
Before starting work, confirm belt tensi

Page 3872 of 4366

INFINITI FX35 2007 Service Manual PS-32
POWER STEERING OIL PUMP
Revision: 2006 July 2007 FX35/FX45
Removal and Installation (VQ35DE Models)NGS000C6
REMOVAL
1. Remove undercover from vehicle with power tool.
2. Loosen belt tensioner a
