Page 4289 of 4366

INFINITI FX35 2007 Service Manual TROUBLE DIAGNOSES WT-25
C
D
F
G H
I
J
K L
M A
B
WT
Revision: 2006 July 2007 FX35/FX45
CONSULT-II Function (BCM)NES000KR
FUNCTION
CONSULT-II can display each self-diagnostic item using the

Page 4290 of 4366

INFINITI FX35 2007 Service Manual WT-26
TROUBLE DIAGNOSES
Revision: 2006 July 2007 FX35/FX45
SELF-DIAGNOSTIC RESULTS MODE
NOTE:
Before performing the self-diagnosis, be sure to register the ID, or else the actual malfunction location

WT-26
TROUBLE DIAGNOSES
Revision: 2006 July 2007 FX35/FX45
SELF-DIAGNOSTIC RESULTS MODE
NOTE:
Before performing the self-diagnosis, be sure to register the ID, or else the actual malfunction location may be different from that dis-
played on CONSULT-II.
How to Erase Self- diagnostic Results
1. Perform applicable inspection of malfunctioning item and then repair or replace.
2. Turn ignition switch “ON” and select “SELF-DIAG RESULTS” mode for “AIR PRESSURE MONITOR” with CONSULT-II.
3. Touch “ERASE” on CONSULT-II screen to erase DTC memory. CAUTION:
If memory cannot be erased, perform applicable diagnosis.
Diagnostic item Diagnostic item is detected when ···
[C1704]
[C1705]
[C1706]
[C1707] LOW PRESSURE FL
LOW PRESSURE FR
LOW PRESSURE RR
LOW PRESSURE RL Front-left tire pressure drops to 173 kPa (1.8 kg/cm
2 , 25 psi) or less.
Front-right tire pressure drops to 173 kPa (1.8 kg/cm2 , 25 psi) or less.
Rear-right tire pressure drops to 173 kPa (1.8 kg/cm2 , 25 psi) or less.
Rear-left tire pressure drops to 173 kPa (1.8 kg/cm2 , 25 psi) or less.
[C1708]
[C1709]
[C1710]
[C1711] [NO DATA] FL
[NO DATA] FR
[NO DATA] RR
[NO DATA] RL Data from front-left transmitter can not be received.
Data from front-right transmitter can not be received.
Data from rear-right transmitter can not be received.
Data from rear-left transmitter can not be received.
[C1712]
[C1713]
[C1714]
[C1715] [CHECKSUM ERR] FL
[CHECKSUM ERR] FR
[CHECKSUM ERR] RR
[CHECKSUM ERR] RL Checksum data from front-left transmitter is malfunctioning.
Checksum data from front-right transmitter is malfunctioning.
Checksum data from rear-right transmitter is malfunctioning.
Checksum data from rear-left transmitter is malfunctioning.
[C1716]
[C1717]
[C1718]
[C1719] [PRESS DATA ERR] FL
[PRESS DATA ERR] FR
[PRESS DATA ERR] RR
[PRESS DATA ERR] RL Air pressure data from front-left transmitter is malfunctioning.
Air pressure data from front-right transmitter is malfunctioning.
Air pressure data from rear-right transmitter is malfunctioning.
Air pressure data from rear-left transmitter is malfunctioning.
[C1720]
[C1721]
[C1722]
[C1723] [CODE ERR] FL
[CODE ERR] FR
[CODE ERR] RR
[CODE ERR] RL Function code data from front-left transmitter is malfunctioning.
Function code data from front-right transmitter is malfunctioning.
Function code data from rear-right transmitter is malfunctioning.
Function code data from rear-left transmitter is malfunctioning.
[C1724]
[C1725]
[C1726]
[C1727] [BATT VOLT LOW] FL
[BATT VOLT LOW] FR
[BATT VOLT LOW] RR
[BATT VOLT LOW] RL Battery voltage of front-left transmitter drops.
Battery voltage of front-right transmitter drops.
Battery voltage of rear-right transmitter drops.
Battery voltage of rear-left transmitter drops.
[C1729] VHCL SPEED SIG ERR Vehicle speed signal is error.
[C1730]
[C1731]
[C1732]
[C1733] FLAT TIRE FL
FLAT TIRE FR
FLAT TIRE RR
FLAT TIRE RL Front-left tire pressure drops to 86 kPa (0.88 kg/cm
2 , 12.5 psi) or less.
Front-right tire pressure drops to 86 kPa (0.88 kg/cm2 , 12.5 psi) or less.
Rear-right tire pressure drops to 86 kPa (0.88 kg/cm2 , 12.5 psi) or less.
Rear-left tire pressure drops to 86 kPa (0.88 kg/cm2 , 12.5 psi) or less.

Page 4291 of 4366

INFINITI FX35 2007 Service Manual TROUBLE DIAGNOSES WT-27
C
D
F
G H
I
J
K L
M A
B
WT
Revision: 2006 July 2007 FX35/FX45
DATA MONITOR MODE
Operation Procedure
1. Perform “CONSULT-II Start Procedure”. Refer to GI-38,

Page 4292 of 4366

INFINITI FX35 2007 Service Manual WT-28
TROUBLE DIAGNOSES
Revision: 2006 July 2007 FX35/FX45
Flasher
Touch “LH” and “RH” on the display, and then check to make sure
that each turn signal lamp turns on.
Horn
Touch “LH” and

Page 4293 of 4366

INFINITI FX35 2007 Service Manual TROUBLE DIAGNOSES WT-29
C
D
F
G H
I
J
K L
M A
B
WT
Revision: 2006 July 2007 FX35/FX45
Flat Tire Warning
Touch “LH” and “RH” on the display, and then check to make sure
that the b

Page 4294 of 4366

INFINITI FX35 2007 Service Manual WT-30
TROUBLE DIAGNOSES
Revision: 2006 July 2007 FX35/FX45
How to Perform Trouble Diagnosis for Quick and Accurate RepairNES000GY
INTRODUCTION
Before troubleshooting, verify customer complaints.
If

Page 4295 of 4366

INFINITI FX35 2007 Service Manual TROUBLE DIAGNOSES WT-31
C
D
F
G H
I
J
K L
M A
B
WT
Revision: 2006 July 2007 FX35/FX45
Preliminary CheckNES000GZ
BASIC INSPECTION
1. CHECK ALL TIRE PRESSURES
Check all tire pressures. Ref

Page 4296 of 4366

INFINITI FX35 2007 Service Manual WT-32
TROUBLE DIAGNOSES
Revision: 2006 July 2007 FX35/FX45
Malfunction Code/Symptom ChartNES000H0
Code/Symptom Malfunction part Reference
page
06
07
08
09 Front-left tire pressure drops to 86 k

WT-32
TROUBLE DIAGNOSES
Revision: 2006 July 2007 FX35/FX45
Malfunction Code/Symptom ChartNES000H0
Code/Symptom Malfunction part Reference
page
06
07
08
09 Front-left tire pressure drops to 86 kPa (0.88 kg/cm
2 , 12.5 psi) or less.
Front-right tire pressure drops to 86 kPa (0.88 kg/cm2 , 12.5 psi) or less.
Rear-right tire pressure drops to 86 kPa (0.88 kg/cm2 , 12.5 psi) or less.
Rear-left tire pressure drops to 86 kPa (0.88 kg/cm2 , 12.5 psi) or less. —
15
16
17
18 Front-left tire pressure drops to 173 kPa (1.8 kg/cm
2 , 25 psi) or less.
Front-right tire pressure drops to 173 kPa (1.8 kg/cm2 , 25 psi) or less.
Rear-right tire pressure drops to 173 kPa (1.8 kg/cm2 , 25 psi) or less.
Rear-left tire pressure drops to 173 kPa (1.8 kg/cm2 , 25 psi) or less. —
21
22
23
24 Transmitter no data (front - left)
Transmitter no data (front - right)
Transmitter no data (rear - right)
Transmitter no data (rear - left) WT-33
31
32
33
34 Transmitter checksum error (front - left)
Transmitter checksum error (front - right)
Transmitter checksum error (rear - right)
Transmitter checksum error (rear - left) WT-33
35
36
37
38 Transmitter pressure data error (front - left)
Transmitter pressure data error (front - right)
Transmitter pressure data error (rear - right)
Transmitter pressure data error (rear - left) WT-34
41
42
43
44 Transmitter function code error (front - left)
Transmitter function code error (front - right)
Transmitter function code error (rear - right)
Transmitter function code error (rear - left) WT-33
45
46
47
48 Transmitter battery voltage low (front - left)
Transmitter battery voltage low (front - right)
Transmitter battery voltage low (rear - right)
Transmitter battery voltage low (rear - left) WT-33
52 Vehicle speed signal
WT-35
Low tire pressure warning lamp does not
come on when ignition switch is turned
on. Fuse or combination meter
BCM connector or circuit
BCM WT-36
Low tire pressure warning lamp stays on
when ignition switch is turned on. Combination meter
BCM connector or circuit
BCM WT-36
Low tire pressure warning lamp blinks
when ignition switch is turned on. BCM connector or circuit
BCM
Transmitter's mode off
ID registration not yet WT-37
Run-flat tire warning lamp stays on when
ignition switch is turned on. Combination meter
Tire pressure DI-5
Turn signal lamp blinks when ignition
switch is turned on. BCM connector or circuit
BCM WT-38
ID registration can not be operated. Transmitter
Remote keyless entry receiver connector or circuit
Remote keyless entry receiver
BCM connector or circuit
BCM WT-38
