Page 1593 of 4366

INFINITI FX35 2007 Service Manual DTC P0122, P0123 TP SENSOR EC-217 [VQ35DE] C D E F G H I J K L M A EC Revision: 2006 July 2007 FX35/FX45 Specification data are reference values and are measured between each terminal and

Page 1594 of 4366

INFINITI FX35 2007 Service Manual EC-218 [VQ35DE] DTC P0122, P0123 TP SENSOR Revision: 2006 July 2007 FX35/FX45 2. CHECK THROTTLE POSITION SENSOR 2 POWER SUPPLY CIRCUIT-I 1. Disconnect electric throttle control actuator harness conne

Page 1595 of 4366

INFINITI FX35 2007 Service Manual DTC P0122, P0123 TP SENSOR EC-219 [VQ35DE] C D E F G H I J K L M A EC Revision: 2006 July 2007 FX35/FX45 6. REPLACE ACCELERATOR PEDAL ASSEMBLY 1. Replace accelerator pedal assembly. 2.

Page 1596 of 4366

INFINITI FX35 2007 Service Manual EC-220 [VQ35DE] DTC P0122, P0123 TP SENSOR Revision: 2006 July 2007 FX35/FX45 Component InspectionNBS003O4 THROTTLE POSITION SENSOR 1. Reconnect all harness connectors disconnected. 2. Perform EC-8

Page 1597 of 4366

INFINITI FX35 2007 Service Manual DTC P0125 ECT SENSOR EC-221 [VQ35DE] C D E F G H I J K L M A EC Revision: 2006 July 2007 FX35/FX45 DTC P0125 ECT SENSORPFP:22630 Component DescriptionNBS003O6 NOTE: If DTC P0125 is displ

Page 1598 of 4366

INFINITI FX35 2007 Service Manual EC-222 [VQ35DE] DTC P0125 ECT SENSOR Revision: 2006 July 2007 FX35/FX45 DTC Confirmation ProcedureNBS003O8 CAUTION: Be careful not to overheat engine. NOTE: If DTC Confirmation Procedure has been p

Page 1599 of 4366

INFINITI FX35 2007 Service Manual DTC P0125 ECT SENSOR EC-223 [VQ35DE] C D E F G H I J K L M A EC Revision: 2006 July 2007 FX35/FX45 3. CHECK THERMOSTAT OPERATION When the engine is cold [lower than 70 °C (158 °F)] co

Page 1600 of 4366

INFINITI FX35 2007 Service Manual EC-224 [VQ35DE] DTC P0127 IAT SENSOR Revision: 2006 July 2007 FX35/FX45 DTC P0127 IAT SENSORPFP:22630 Component DescriptionNBS003OC The intake air temperature sensor is built into mass air flow sensor
