2007 INFINITI FX35 Service Manual

oil additives seats cooling airbag off check transmission fluid technical data

Load previous 8 pages

Page 2921 of 4366

INFINITI FX35 2007 Service Manual CYLINDER BLOCK EM-129
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 July 2007 FX35/FX45
18. Remove main bearing beam.
19. Remove main bearing caps.
CAUTION:
Be careful not to drop

Page 2922 of 4366

INFINITI FX35 2007 Service Manual EM-130
[VQ35DE]
CYLINDER BLOCK
Revision: 2006 July 2007 FX35/FX45
Tighten each plug as specified below.
3. Install oil jet.
Insert oil jet dowel pin into cylinder block dowel pin hole, and
tighten

Page 2923 of 4366

INFINITI FX35 2007 Service Manual CYLINDER BLOCK EM-131
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 July 2007 FX35/FX45
Main bearing caps are identified by identification mark cast on
them. For installation, face

Page 2924 of 4366

INFINITI FX35 2007 Service Manual EM-132
[VQ35DE]
CYLINDER BLOCK
Revision: 2006 July 2007 FX35/FX45
Assemble so that the front mark on the piston head and the
cylinder number on connecting rod are positioned as shown in
the figure.

Page 2925 of 4366

INFINITI FX35 2007 Service Manual CYLINDER BLOCK EM-133
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 July 2007 FX35/FX45
When installing, align connecting rod bearing stopper protru-
sion with cutout of connecting

Page 2926 of 4366

INFINITI FX35 2007 Service Manual EM-134
[VQ35DE]
CYLINDER BLOCK
Revision: 2006 July 2007 FX35/FX45
d. Then tighten all connecting rod bolts 90 degrees clockwise
(Angle tightening).
CAUTION:
Always use the angle wrench [SST: KV1011

Page 2927 of 4366

INFINITI FX35 2007 Service Manual CYLINDER BLOCK EM-135
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2006 July 2007 FX35/FX45
18. Install knock sensor.
Install knock sensor so that connector faces front of the
engine.

Page 2928 of 4366

INFINITI FX35 2007 Service Manual EM-136
[VQ35DE]
CYLINDER BLOCK
Revision: 2006 July 2007 FX35/FX45
How to Select Piston and Bearing NBS003H7
DESCRIPTION
*: For the service parts, the grade for fitting cannot be selected between pist

EM-136
[VQ35DE]
CYLINDER BLOCK
Revision: 2006 July 2007 FX35/FX45
How to Select Piston and Bearing NBS003H7
DESCRIPTION
*: For the service parts, the grade for fitting cannot be selected between piston pin and connecting rod. (Only “0” grade is a vailable.) The
information at the shipment from the plant is described as a reference.
The identification grade stamped on each part is the grade for the dimension measured in new condition.
This grade cannot apply to reused parts.
For reused or repaired parts, measure the dimension accurately. Determine the grade by comparing the
measurement with the values of each selection table.
For details of the measurement method of each part, the reuse standards and the selection method of the
selective fitting parts, refer to the text.
HOW TO SELECT PISTON
When New Cylinder Block is Used
Check the cylinder bore grade (“1”, “2” or “3”) on rear side of cylinder
block, and select piston of the same grade.
NOTE:
Piston is available with piston pin as a set for the service part. (Only
“0” grade piston pin is available.)
When Cylinder Block is Reused
1. Measure the cylinder bore inner diameter. Refer to EM-145, "Cylinder Bore inner Diameter" .
2. Determine the bore grade by comparing the measurement with the values under the cylinder bore inner diameter of the “Piston
Selection Table”.
3. Select piston of the same grade.
Selection points Selection parts Selection items Selection methods
Between cylinder block and
crankshaft Main bearing
Main bearing grade
(bearing thickness) Determined by match of cylin-
der block bearing housing
grade (inner diameter of hous-
ing) and crankshaft journal
grade (outer diameter of jour-
nal)
Between crankshaft and con-
necting rod Connecting rod bearing
Connecting rod bearing grade
(bearing thickness) Combining service grades for
connecting rod big end diame-
ter and crankshaft pin outer
diameter determine connecting
rod bearing selection.
Between cylinder block and pis-
ton Piston and piston pin assembly
(Piston is available together
with piston pin as assembly.) Piston grade
(piston skirt diameter) Piston grade = cylinder bore
grade (inner diameter of bore)
Between piston and connecting
rod* ———
SEM756G
PBIC0812E
