Page 2865 of 4366

INFINITI FX35 2007 Service Manual TIMING CHAIN EM-73 [VQ35DE] C D E F G H I J K L M A EM Revision: 2006 July 2007 FX35/FX45 1. Install timing chain tensioners (secondary) to cylinder head as follows if removed. Refer to

Page 2866 of 4366

INFINITI FX35 2007 Service Manual EM-74 [VQ35DE] TIMING CHAIN Revision: 2006 July 2007 FX35/FX45 Apply liquid gasket on installation position of water pump and cylinder head very completely. d. Align rear timing chain case and water

Page 2867 of 4366

INFINITI FX35 2007 Service Manual TIMING CHAIN EM-75 [VQ35DE] C D E F G H I J K L M A EM Revision: 2006 July 2007 FX35/FX45 g. After installing rear timing chain case, check the surface height difference between the foll

Page 2868 of 4366

INFINITI FX35 2007 Service Manual EM-76 [VQ35DE] TIMING CHAIN Revision: 2006 July 2007 FX35/FX45 b. Install timing chains (secondary) and camshaft sprockets. Align the mating marks on timing chain (secondary) (gold link) with the on

Page 2869 of 4366

INFINITI FX35 2007 Service Manual TIMING CHAIN EM-77 [VQ35DE] C D E F G H I J K L M A EM Revision: 2006 July 2007 FX35/FX45 d. Pull stopper pins out from timing chain tensioners (secondary). 6. Install tension guide. 7.

Page 2870 of 4366

INFINITI FX35 2007 Service Manual EM-78 [VQ35DE] TIMING CHAIN Revision: 2006 July 2007 FX35/FX45 8. Install internal chain guide, slack guide and timing chain ten- sioner (primary). CAUTION: Do not overtighten slack guide mounting

Page 2871 of 4366

INFINITI FX35 2007 Service Manual TIMING CHAIN EM-79 [VQ35DE] C D E F G H I J K L M A EM Revision: 2006 July 2007 FX35/FX45 e. Install timing chain tensioner (primary). Remove any dirt and foreign materials completely fr

Page 2872 of 4366

INFINITI FX35 2007 Service Manual EM-80 [VQ35DE] TIMING CHAIN Revision: 2006 July 2007 FX35/FX45 Apply a continuous bead of liquid gasket with the tube presser [SST: WS39930000 ( — )] to front timing chain case as shown in the fig
