INFINITI FX35 2007 Service Manual ENGINE MAINTENANCE (VQ35DE ENGINE) MA-21
C
D E
F
G H
I
J
K
M A
B
MA
Revision: 2006 July 2007 FX35/FX45
CAUTION:
Do not drop or shock spark plug.
Do not use a wire brush for cleaning.
I

Page 3714 of 4366

INFINITI FX35 2007 Service Manual MA-22
ENGINE MAINTENANCE (VK45DE ENGINE)
Revision: 2006 July 2007 FX35/FX45
ENGINE MAINTENANCE (VK45DE ENGINE)PFP:10001
Checking Drive BeltsNLS0006C
WARNING:
Be sure to perform when the engine is sto

Page 3715 of 4366

INFINITI FX35 2007 Service Manual ENGINE MAINTENANCE (VK45DE ENGINE) MA-23
C
D E
F
G H
I
J
K
M A
B
MA
Revision: 2006 July 2007 FX35/FX45
DRAINING ENGINE COOLANT
1. Remove front engine undercover with power tool.
2. Open

Page 3716 of 4366

INFINITI FX35 2007 Service Manual MA-24
ENGINE MAINTENANCE (VK45DE ENGINE)
Revision: 2006 July 2007 FX35/FX45
When engine coolant overflows air relief hole on heater hose,
install air relief plug.
5. Install radiator cap.
6. Warm

MA-24
ENGINE MAINTENANCE (VK45DE ENGINE)
Revision: 2006 July 2007 FX35/FX45
When engine coolant overflows air relief hole on heater hose,
install air relief plug.
5. Install radiator cap.
6. Warm up until opening thermostat. Standard for warming-up time is approximately 10 minutes at 3,000 rpm.
Make sure thermostat opening condition by touching radiator hose (lower) to see a flow of warm water.
CAUTION:
Watch water temperature gauge so as not to overheat engine.
7. Stop engine and cool down to less than approximately 50 °C (122 °F).
Cool down using a fan to reduce the time.
If necessary, refill engine coolant up to filler neck of thermostat housing.
8. Refill reservoir tank to “MAX” level line with engine coolant.
9. Repeat steps 4 through 7 two or more times with radiator cap installed until engine coolant level no longer drops.
10. Check cooling system for leaks with engine running.
11. Warm up engine, and check for sound of engine coolant flow while running engine from idle up to 3,000 rpm with heater temperature controller set at several position between “COOL” and “WARM”.
Sound may be noticeable at heater unit.
12. Repeat step 11 three times.
13. If sound is heard, bleed air from cooling system by repeating steps 4 through 7 until engine coolant level no longer drops.
FLUSHING COOLING SYSTEM
1. Install reservoir tank, and radiator drain plug.
CAUTION:
Be sure to clean drain plug and install with new O-ring.
If water drain plugs on cylinder block are removed, close and tighten them. Refer to EM-253,
"ASSEMBLY" .
2. Remove air relief plug on heater hose.
3. Fill thermostat housing with water until water spills from the air relief hole, then close air relief plug. Fill thermostat housing and reservoir tank with water and reinstall radiator cap.
4. Run engine and warm it up to normal operating temperature. Reservoir tank engine coolant capacity
(At “MAX” level):
0.8 (7/8 US qt, 3/4 lmp qt)
SMA412B
Radiator drain plug:
: 1.19 N·m (0.12 kg-m, 11 in-lb)
PBIC1530E

Page 3717 of 4366

INFINITI FX35 2007 Service Manual ENGINE MAINTENANCE (VK45DE ENGINE) MA-25
C
D E
F
G H
I
J
K
M A
B
MA
Revision: 2006 July 2007 FX35/FX45
5. Rev engine two or three times under no-load.
6. Stop engine and wait until it co

Page 3718 of 4366

INFINITI FX35 2007 Service Manual MA-26
ENGINE MAINTENANCE (VK45DE ENGINE)
Revision: 2006 July 2007 FX35/FX45
Engine oil capacity (Approximate):

Page 3719 of 4366

INFINITI FX35 2007 Service Manual ENGINE MAINTENANCE (VK45DE ENGINE) MA-27
C
D E
F
G H
I
J
K
M A
B
MA
Revision: 2006 July 2007 FX35/FX45
3. Screw oil filter manually until it touches the installation surface,
then tighte

Page 3720 of 4366

INFINITI FX35 2007 Service Manual MA-28
ENGINE MAINTENANCE (VK45DE ENGINE)
Revision: 2006 July 2007 FX35/FX45
Do not use wire brush for cleaning.
If plug tip is covered with carbon, spark plug cleaner may
be used.
Checking and adj
