BCM (BODY CONTROL MODULE) BCS-7
C
D E
F
G H
I
J
L
M A
B
BCS
Revision: 2006 July 2007 FX35/FX45
SYSTEMS CONTROLLED BY BCM DIRECTLY
NOTE:
Power supply only. No system control.
SYSTEMS CONTROLLED BY BCM AND IPDM E/R
SYSTEMS CONTROLLED BY BCM AND COMBINATION METER
SYSTEMS CONTROLLED BY BCM AND INTELLIGENT KEY UNIT
SYSTEMS CONTROLLED BY BCM, COMBINATION METER AND IPDM E/R
System Reference
Power door lock system BL-21, "
POWER DOOR LOCK SYSTEM"
Remote keyless entry systemBL-54, "REMOTE KEYLESS ENTRY SYSTEM"
Power window system NOTEGW-15, "POWER WINDOW SYSTEM"
Sunroof NOTERF-10, "SUNROOF"
Room lamp timerLT-152, "INTERIOR ROOM LAMP"
Rear wiper and washer systemWW-39, "REAR WIPER AND WASHER SYSTEM"
System Reference
Panic alarm

BL-54, "REMOTE KEYLESS ENTRY SYSTEM"

BL-86, "INTELLIGENT KEY SYSTEM"
Theft warning system BL-180, "VEHICLE SECURITY (THEFT WARNING) SYSTEM"
IVIS (NATS)BL-205, "IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS)"
HeadlampLT- 6 , "HEADLAMP - XENON TYPE -"
Daytime light systemLT-38, "DAYTIME LIGHT SYSTEM"
Auto light systemLT-55, "AUTO LIGHT SYSTEM"
Front fog lampLT-78, "FRONT FOG LAMP"

Parking, license plate, side marker and tail lamps

Exterior lamp battery saver control LT-131, "PARKING, LICENSE PLATE AND TAIL LAMPS"
Front wiper and washer system
WW-4, "FRONT WIPER AND WASHER SYSTEM"
Rear window defoggerGW-67, "REAR WINDOW DEFOGGER"
System Reference
Warning chime DI-56, "
WARNING CHIME"
Turn signal and hazard warning lampsLT-90, "TURN SIGNAL AND HAZARD WARNING LAMPS"
Tire pressure monitoring systemWT-11, "TIRE PRESSURE MONITORING SYSTEM"
System Reference
Intelligent Key system BL-86, "
INTELLIGENT KEY SYSTEM"
System Reference
Oil pressure warning lamp DI-38, "
WARNING LAMPS"

BCM (BODY CONTROL MODULE) BCS-9
C
D E
F
G H
I
J
L
M A
B
BCS
Revision: 2006 July 2007 FX35/FX45
CAN Communication UnitNKS00340
Refer to LAN-49, "CAN System Specification Chart" .
Key warning chime
Key switch

Front door switch driver side Combination meter
(warning buzzer)
Light warning chime

Combination switch

Key switch

Front door switch driver side Combination meter
(warning buzzer)
Seat belt warning chime

Combination meter [Seat belt buckle
(driver side) switch]

Ignition switch Combination meter
(warning buzzer)
Front wiper and washer system

Combination switch

Combination meter

Ignition switch IPDM E/R
Rear wiper and washer system

Combination switch

Ignition switch Rear wiper motor
Rear window defogger

Rear window defogger switch

Ignition switch IPDM E/R
A/C switch signal Unified meter and A/C amp. ECM
Blower fan switch signal Unified meter and A/C amp. ECM
Low tire pressure warning system Remote keyless entry receiver Combination meter System Input Output

BCS-12
BCM (BODY CONTROL MODULE)
Revision: 2006 July 2007 FX35/FX45
CONSULT-II Function (BCM)NKS00342
CONSULT-II can display each diagnostic item using the diagnostic test mode shown following.
CONSULT–II INSPECTION PROCEDURE
Refer to GI-38, "CONSULT-II Start Procedure" .
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
ITEMS OF EACH PART
NOTE:
CONSULT-II displays systems equipped in the vehicle.
× :Applicable
BCM Diagnostic test item Check item, diagnostic test mode Content
Inspection by part WORK SUPPORT Changes setting of each function.
SELF-DIAG RESULTS BCM performs self-diagnosis of CAN communication.
DATA MONITOR Displays the input data of BCM in real time.
CAN DIAG SUPPORT MNTR The transmit/receive diagnosis result of CAN communication can be
read.
ACTIVE TEST Gives a drive signal to a load to check the operation.
ECU PART NUMBER ECM part number can be read.
CONFIGURATION (Not be used)
System and item CONSULT-II display Diagnostic test mode (Inspection by part)
WORK SUP-
PORT SELF
−
DIAG
RESULTS DATA
MONI- TOR CAN
DIAG SUP-
PORT
MNTR ACTIVE
TEST ECU
PA R T
NUM- BER CONFIG-
URATION
BCM BCM ×× × ×
×
NOTE 1
Power door lock system DOOR LOCK ×××
Rear window defogger REAR DEFOGGER ××
Warning chime BUZZER ××
Room lamp timer INT LAMP ×××
Remote keyless entry sys-
tem
NOTE 2MULTI REMOTE
ENT ×××
Headlamp HEAD LAMP ×××
Wiper WIPER ×××
Turn signal lamp
Hazard lamp FLASHER
××
Blower fan switch signal
A/C switch signal AIR CONDITONER
×
Intelligent Key system
NOTE 3INTELLIGENT KEY ×
Combination switch COMB SW ×
NVIS IMMU ××
Room lamp battery saver BATTERY SAVER ×× ×
Trunk lid TRUNK
NOTE 4××
Vehicle security system THEFT ALM ×××
Retained power control RETAINED PWR ×××
Oil pressure switch SIGNAL BUFFER ××

BCM (BODY CONTROL MODULE) BCS-13
C
D E
F
G H
I
J
L
M A
B
BCS
Revision: 2006 July 2007 FX35/FX45
NOTE:

1: This item is displayed, but should not be used.

2: Vehicle with remote keyless entry system display this item.

3: Vehicle with Intelligent Key system display this item.

4: This item is displayed, but does not function.
WORK SUPPORT
Operation Procedure
1. Touch “BCM” on “SELECT TEST ITEM” screen.
2. Touch “WORK SUPPORT” on “SELECT DIAG MODE” screen.
3. Touch item on “SELECT WORK ITEM” screen.
4. Touch “START”.
5. Touch “CHANGE SET”.
6. The setting will be changed and “RESETTING COMPLETED” will be displayed.
7. Touch “END”.
Display Item List
CAN Communication Inspection Using CONSULT-II (Self-Diagnosis)NKS00343
1. CHECK SELF-DIAGNOSTIC RESULT
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
1. Connect to CONSULT-II, and select “BCM” on “SELECT SYSTEM” screen.
2. Select “BCM control unit ” on “SELECT WORK ITEM” screen, and select “SELF-DIAG RESULTS”.
3. Check display content in self-diagnostic results.
Contents displayed
No malfunction>> INSPECTION END
Malfunction in CAN communication system>> After printing the monitor items, go to “CAN System”. Refer to
LAN-49, "
CAN System Specification Chart" .
Low tire pressure warning
system AIR PRESSURE
MONITOR ××× ×
Panic system PANIC ALARM ×
System and item CONSULT-II display
Diagnostic test mode (Inspection by part)
WORK SUP-
PORT SELF
−
DIAG
RESULTS DATA
MONI- TOR CAN
DIAG SUP-
PORT
MNTR ACTIVE
TEST ECU
PA RT
NUM- BER CONFIG-
URATION
Item Description
RESET SETTING VALUE Return a value set with WORK SUPPORT of each system to a default value in factory shipment.
CONSULT-II display code Diagnosis item
U1000 INITIAL DIAG
TRANSMIT DIAG ECM
IPDM E/R
METER/M&A I-KEY

BL-2Revision: 2006 July 2007 FX35/FX45
