Page 3857 of 4366

INFINITI FX35 2007 Service Manual STEERING COLUMN PS-17 C D E F H I J K L M A B PS Revision: 2006 July 2007 FX35/FX45 DISASSEMBLY Disassemble the parts from jacket tube. The parts to be disassembled are shown in the figur

Page 3858 of 4366

INFINITI FX35 2007 Service Manual PS-18 POWER STEERING GEAR AND LINKAGE Revision: 2006 July 2007 FX35/FX45 POWER STEERING GEAR AND LINKAGEPFP:49001 Removal and InstallationNGS000C3 COMPONENTS CAUTION: Spiral cable may snap due to ste

Page 3859 of 4366

INFINITI FX35 2007 Service Manual POWER STEERING GEAR AND LINKAGE PS-19 C D E F H I J K L M A B PS Revision: 2006 July 2007 FX35/FX45 7. Remove oil pipings (high pressure side and low pressure side) from steering gear as

Page 3860 of 4366

INFINITI FX35 2007 Service Manual PS-20 POWER STEERING GEAR AND LINKAGE Revision: 2006 July 2007 FX35/FX45 INSTALLATION Refer to PS-18, "Removal and Installation" for tightening torque. Install in the reverse order of removal. NOTE

Page 3861 of 4366

INFINITI FX35 2007 Service Manual POWER STEERING GEAR AND LINKAGE PS-21 C D E F H I J K L M A B PS Revision: 2006 July 2007 FX35/FX45 Disassembly and AssemblyNGS000C4 COMPONENTS 1. Outer socket 2. Boot clamp 3. Boot 4. I

Page 3862 of 4366

INFINITI FX35 2007 Service Manual PS-22 POWER STEERING GEAR AND LINKAGE Revision: 2006 July 2007 FX35/FX45 CAUTION: Secure steering gear assembly with a vise, using copper plates or something similar to prevent it from being dam- ag

Page 3863 of 4366

INFINITI FX35 2007 Service Manual POWER STEERING GEAR AND LINKAGE PS-23 C D E F H I J K L M A B PS Revision: 2006 July 2007 FX35/FX45 9. Drill out the clinching part of cylinder outer rim with a 3 mm (0.12 in) drill in 1

Page 3864 of 4366

INFINITI FX35 2007 Service Manual PS-24 POWER STEERING GEAR AND LINKAGE Revision: 2006 July 2007 FX35/FX45 INSPECTION AFTER DISASSEMBLY Boot Check boot for cracks and deformation. Replace it, if necessary. Rack Check rack for damage
