Page 3921 of 4366

INFINITI FX35 2007 Service Manual SUNROOF RF-19 C D E F G H J K L M A B RF Revision: 2006 July 2007 FX35/FX45 2. CHECK SUNROOF SWITCH CIRCUIT 1. Turn ignition switch OFF. 2. Disconnect sunroof motor assembly and sunroo

Page 3922 of 4366

INFINITI FX35 2007 Service Manual RF-20 SUNROOF Revision: 2006 July 2007 FX35/FX45 Check Door Switch NIS001TA 1. CHECK DOOR SWITCH INPUT SIGNAL With CONSULT-II Check (“DOOR SW-DR” and “DOOR SW-AS”) in “DATA MONITOR” m

Page 3923 of 4366

INFINITI FX35 2007 Service Manual SUNROOF RF-21 C D E F G H J K L M A B RF Revision: 2006 July 2007 FX35/FX45 2. CHECK DOOR SWITCH CIRCUIT 1. Turn ignition switch OFF. 2. Disconnect door switch and BCM connector. 3. Che

Page 3924 of 4366

INFINITI FX35 2007 Service Manual RF-22 SUNROOF Revision: 2006 July 2007 FX35/FX45 Wind Deflector InspectionNIS001TB 1. Make sure the wind deflector is properly raised by manual. If a malfunction is detected, remove and visually chec

Page 3925 of 4366

INFINITI FX35 2007 Service Manual SUNROOF RF-23 C D E F G H J K L M A B RF Revision: 2006 July 2007 FX35/FX45 LID WEATHERSTRIP OVERLAP ADJUSTMENT AND SURFACE MISMATCH ADJUSTMENT 1. Tilt up glass lid. 2. After loosening g

Page 3926 of 4366

INFINITI FX35 2007 Service Manual RF-24 SUNROOF Revision: 2006 July 2007 FX35/FX45 PIIA6190E

Page 3927 of 4366

INFINITI FX35 2007 Service Manual SUNROOF RF-25 C D E F G H J K L M A B RF Revision: 2006 July 2007 FX35/FX45 SUNROOF UNIT ASSEMBLY Removal CAUTION: Always work with a helper. When taking sunroof unit out, use clothes

Page 3928 of 4366

INFINITI FX35 2007 Service Manual RF-26 SUNROOF Revision: 2006 July 2007 FX35/FX45 Installation 1. Temporarily tighten the mounting bolts on the front/rear sunroof brackets (RH/LH). 2. Bring sunroof unit assembly into passenger room
