Page 465 of 4366

INFINITI FX35 2007 Service Manual PREPARATION ATC-19 C D E F G H I K L M A B AT C Revision: 2006 July 2007 FX35/FX45 (J-43926) Refrigerant dye leak detection kit Kit includes: (J-42220) UV lamp and UV safety goggles (

Page 466 of 4366

INFINITI FX35 2007 Service Manual ATC-20 PREPARATION Revision: 2006 July 2007 FX35/FX45 Commercial Service ToolsNJS000DG Service hoses High-pressure side hose (J-39501-72) Low-pressure side hose (J-39502-72) Utility hose (J-3947

Page 467 of 4366

INFINITI FX35 2007 Service Manual REFRIGERATION SYSTEM ATC-21 C D E F G H I K L M A B AT C Revision: 2006 July 2007 FX35/FX45 REFRIGERATION SYSTEMPFP:KA990 Refrigerant CycleNJS000DH REFRIGERANT FLOW The refrigerant flows

Page 468 of 4366

INFINITI FX35 2007 Service Manual ATC-22 REFRIGERATION SYSTEM Revision: 2006 July 2007 FX35/FX45 V-6 Variable Displacement CompressorNJS000DJ GENERAL INFORMATION 1. The V-6 variable compressor differs from previous units. The outlet a

Page 469 of 4366

INFINITI FX35 2007 Service Manual REFRIGERATION SYSTEM ATC-23 C D E F G H I K L M A B AT C Revision: 2006 July 2007 FX35/FX45 DESCRIPTION General The variable compressor is a swash plate type that changes piston stroke i

Page 470 of 4366

INFINITI FX35 2007 Service Manual ATC-24 REFRIGERATION SYSTEM Revision: 2006 July 2007 FX35/FX45 Operation 1. Control Valve –By changing high-pressure valve lift amount, built-in electronic control valve executes the following:  C

Page 471 of 4366

INFINITI FX35 2007 Service Manual REFRIGERATION SYSTEM ATC-25 C D E F G H I K L M A B AT C Revision: 2006 July 2007 FX35/FX45 increase triggers pressure difference between the piston and the crankcase. The pressure differ

Page 472 of 4366

INFINITI FX35 2007 Service Manual ATC-26 REFRIGERATION SYSTEM Revision: 2006 July 2007 FX35/FX45 Component LayoutNJS000DK PJIA0165E
