INFINITI FX35 2007 Service Manual RECOMMENDED FLUIDS AND LUBRICANTS MA-13
C
D E
F
G H
I
J
K
M A
B
MA
Revision: 2006 July 2007 FX35/FX45
Engine Oil RecommendationNLS0008K
NISSAN recommends the use of an energy conserving o

Page 3706 of 4366

INFINITI FX35 2007 Service Manual MA-14
ENGINE MAINTENANCE (VQ35DE ENGINE)
Revision: 2006 July 2007 FX35/FX45
ENGINE MAINTENANCE (VQ35DE ENGINE)PFP:10001
Checking Drive BeltsNLS00063
WARNING:
Be sure to perform when engine is stopped

MA-14
ENGINE MAINTENANCE (VQ35DE ENGINE)
Revision: 2006 July 2007 FX35/FX45
ENGINE MAINTENANCE (VQ35DE ENGINE)PFP:10001
Checking Drive BeltsNLS00063
WARNING:
Be sure to perform when engine is stopped.
1. Inspect belts for cracks, fraying, wear and oil. If necessary, replace.
2. Inspect drive belt deflection or tension at a point on belt midway between pulleys.
Inspection should be done only when engine is cold, or over
30 minutes after engine is stopped.
Measure the belt tension with belt tension gauge (Commercial
service tool: BT3373-F or equivalent) at points marked
shown in the figure.
When measuring the deflection, apply 98 N (10 kg, 22 lb) at
the marked point.
Adjust if the belt deflection exceeds the limit or if the belt ten-
sion is not within specifications.
CAUTION:
When checking the belt deflection or the tension immediately after installation, first adjust it to
the specified value. Then, after turning crankshaft two turns or more, re-adjust to the specified
value to avoid variation in deflection between pulleys.
Tighten idler pulley lock nut by hand and measure the deflection or the tension without loose-
ness.
Belt Deflection and Tension
*: If belt tension gauge cannot be installed at check points shown, check drive belt tension at different location on belt.
Drive Belts Tension AdjustmentNLS00064
CAUTION:
When belt is replaced with a new one, adjust it to value for “New belt” to accommodate for insuffi-
cient adaptability with pulley grooves.
When deflection or tension of belt being used exceeds “Limit”, adjust it to value for “After adjust-
ment”.
When checking belt deflection or tension immediately after installation, first adjust it to the speci-
fied value. Then, after turning crankshaft two turns or more, re-adjust to the specified value to
avoid variation in deflection between pulleys.
When installing belt, make sure that it is correctly engaged with pulley grooves.
Keep engine oil, working fluid and engine coolant away from belt and pulley grooves.
Do not twist or bend belt excessively.
KBIA1731J
Items Deflection adjustment Unit: mm (in) Tension adjustment* Unit: N (kg, lb)
Used belt New belt Used belt
New belt
Limit After adjustment Limit After adjustment
Alternator and
power steering
oil pump belt 7 (0.28)
4 - 5
(0.16 - 0.20) 3.5 - 4.5
(0.138 - 0.177) 294 (30, 66) 730 - 818
(74.5 - 83.5, 164 - 184) 838 - 926
(85.5 - 94.5, 188 - 208)
A/C compressor
belt 12 (0.47) 9 - 10
(0.35 - 0.39) 8 - 9
(0.31 - 0.35) 196 (20, 44) 348 - 436
(35.5 - 44.5, 78 - 98) 470 - 559
(48 - 57,
106 - 126)
Applied pushing
force 98 N (10 kg, 22 lb) —
Portion
Belt tightening method for adjustment
Alternator and power steering oil pump belt Adjusting bolt on idler pulley
A/C compressor belt Adjusting bolt on idler pulley

Page 3707 of 4366

INFINITI FX35 2007 Service Manual ENGINE MAINTENANCE (VQ35DE ENGINE) MA-15
C
D E
F
G H
I
J
K
M A
B
MA
Revision: 2006 July 2007 FX35/FX45
ALTERNATOR AND POWER STEERING OIL PUMP BELT
1. Remove front engine undercover with p

Page 3708 of 4366

INFINITI FX35 2007 Service Manual MA-16
ENGINE MAINTENANCE (VQ35DE ENGINE)
Revision: 2006 July 2007 FX35/FX45
3. Remove reservoir tank as necessary, drain engine coolant and clean reservoir tank before installing.
4. Check drained en

Page 3709 of 4366

INFINITI FX35 2007 Service Manual ENGINE MAINTENANCE (VQ35DE ENGINE) MA-17
C
D E
F
G H
I
J
K
M A
B
MA
Revision: 2006 July 2007 FX35/FX45
Cool down using fan to reduce the time.
If necessary, refill radiator up to filler

Page 3710 of 4366

INFINITI FX35 2007 Service Manual MA-18
ENGINE MAINTENANCE (VQ35DE ENGINE)
Revision: 2006 July 2007 FX35/FX45
Changing Air Cleaner FilterNLS00067
VISCOUS PAPER TYPE
The viscous paper type filter does not need cleaning between
replace

Page 3711 of 4366

INFINITI FX35 2007 Service Manual ENGINE MAINTENANCE (VQ35DE ENGINE) MA-19
C
D E
F
G H
I
J
K
M A
B
MA
Revision: 2006 July 2007 FX35/FX45
10. Check the engine oil level.
Changing Oil FilterNLS00069
REMOVAL
WARNING:
Be car

Page 3712 of 4366

INFINITI FX35 2007 Service Manual MA-20
ENGINE MAINTENANCE (VQ35DE ENGINE)
Revision: 2006 July 2007 FX35/FX45
3. Screw oil filter manually until it touches the installation surface,
then tighten it by 2/3 turn. Or tighten to the spec
