ACS-8
[ICC]
DESCRIPTION
Revision: 2006 July 2007 FX35/FX45
ABS actuator
and electric
unit (control
unit) VHCL SPEED SE
[km/h] or [mph] × Indicates vehicle speed calculated from wheel sensor by ICC unit through CAN commu-
nication (ABS actuator and electric unit (control unit) transmits wheel speed sensor sig-
nal through CAN communication).
BCM WIPER SW
[OFF/LOW/HIGH] ×
Indicates wiper [OFF/LOW/HIGH] status (BCM transmits front wiper request signal
through CAN communication).
Brake pres-
sure sensor PRESS SENS
[bar] Indicates brake fluid pressure value calculated from signal voltage of pressure sensor.
Release
switch RELEASE SW NO
[ON/OFF] Indicates [ON/OFF] status as judged from release switch signal.
ON when brake is depressed.
OFF when brake is not depressed.
RELEASE SW NC
[ON/OFF] Indicates [ON/OFF] status as judged from release switch signal.
ON when brake is not depressed.
OFF when brake is depressed.
ICC brake
switch BRAKE SW
[ON/OFF] Indicates [ON/OFF] status as judged from ICC brake switch signal.
Stop lamp
switch STOP LAMP SW
[ON/OFF] Indicates [ON/OFF] status as judged from stop lamp switch signal.
Input
Data monitored
Item [unit] CAN Description
OutputData monitored
Item [unit] CAN Description
ICC warning
chime BUZZER O/P
[ON/OFF] ×
Indicates [ON/OFF] status of ICC warning chime output.
ICC brake hold
relay STP LMP DRIVE
[ON/OFF] Indicates [ON/OFF] status of brake hold relay drive output.
Output CONSULT-ll ICC
[ACTIVE TEST] Item CAN Description
Combination
meter ICC BUZZER 1
×Able to start ICC warning chime with a driving signal from ICC unit.
METER LAMP ×Able to turn ICC system display ON with a driving signal from ICC unit.
ICC brake hold
relay STOP LAMP Able to start ICC brake hold relay with a driving signal from ICC unit.
Booster sole-
noid BOOSTER SOL/V
3 Able to start booster solenoid with a driving signal from ICC unit.

ACS-28
[ICC]
TERMINALS AND REFERENCE VALUE
Revision: 2006 July 2007 FX35/FX45
TERMINALS AND REFERENCE VALUEPFP:00000
Terminals and Reference Value for ICC UnitNKS003EY
Terminals
(Wire color) Item Condition
Voltage (V)
+– Ignition
switch Operation
1 (R/W)
2 (R/W)
Ground Battery power supply OFF — Battery voltage
5 (P) CAN-L — — —
6 (GY/L) Release switch power supply ON — Approx. 10
7 (GY/R) NEUT-SW ON Selector lever in “N” or “P” posi-
tions Approx. 12
Selector lever in other positions Approx. 0
8 (G) 24 (R) Brake pressure sensor power
supply ON — Approx. 5
10 (B/R)
Ground Brake booster solenoid
(+) side ON — Approx. 12
12 (L/W) Brake booster solenoid
(–) side ON Solenoid operating
Solenoid not operating Approx. 12
14 (L) CAN-H — — —
15 (LG/B) Brake release switch
(normal closed) ON Depress the brake pedal Approx. 0
Release the brake pedal Approx. 10
17 (BR) 24 (R) Brake pressure sensor signal ON Release the brake pedal Approx. 0.5
Depress the brake pedal Approx. 0.5 - 3
(Note) Voltage becomes higher depending on effectiveness of
depressing brakes.
19 (B)
20 (B)
46 (B)
Ground Ground ON — Approx. 0
22 (G/Y) Brake release switch
(normally open) ON Depress the brake pedal Approx. 10
Release the brake pedal Approx. 0
29 (SB) ICC brake switch
(normal closed) ON Selector
lever: Not
in “N” or
“P” posi-
tion Depress the brake
pedal Approx. 0
Release the brake
pedal Approx. 12
30 (Y) DDL-TX — — —
33 (W)
42 (W) Ignition switch ON or START ON — Battery voltage
38 (P/B) Stop lamp switch
(normally open) ON Depress the brake pedal Approx. 12
Release the brake pedal Approx. 0
39
(G/OR) DDL-RX — — —
PKIA9673E

TROUBLE DIAGNOSIS — GENERAL DESCRIPTION ACS-33
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2006 July 2007 FX35/FX45
DATA MONITOR
Operation Procedure
1. Touch “DATA MONITOR” on “SELECT DIAG MODE” screen. Refer to GI-38, "
CONSULT-II Start Procedure" .
2. Touch any of “ECU INPUT SIGNALS”, “MAIN SIGNALS” and “SELECTION FROM MENU” on selection screen.
3. Touch “START”.
4. Display the data monitor.
5. If necessary, touch “COPY” in turn, and print data.
Monitored Item
× : Applicable
PKIB0112E
Monitored Item
[unit] ECU INPUT
SIGNALS MAIN
SIGNALS SELEC-
TION FROM MENU Description
VHCL SPEED SE
[km/h] or [mph] ××× Indicates vehicle speed calculated from ICC unit through CAN
communication [ABS actuator and electric unit (control unit)
transmits wheel speed sensor signal through CAN communica-
tion].
SET VHCL SPD
[km/h] or [mph] ××Indicates set vehicle speed memorized in ICC unit.
THRTL OPENING
[%] ××× Indicates throttle angle read from ICC unit through CAN commu-
nication (ECM transmits throttle angle through CAN communi-
cation).
ENGINE RPM
[rpm] ×× Indicates engine speed read from ICC unit through CAN com-
munication (ECM transmits engine speed through CAN commu-
nication).
DISTANCE ADJ
[SHOR/MID/LONG] ××× Indicates set distance memorized in ICC unit.
WIPER SW
[OFF/LOW/HIGH] ×× Indicates wiper [OFF/LOW/HIGH] status (BCM transmits front
wiper request signal through CAN communication).
MAIN SW
[ON/OFF] ××× Indicates [ON/OFF] status as judged from ICC steering switch
signal (ECM transmits ICC steering switch signal through CAN
communication).
SET/COAST SW
[ON/OFF] ××× Indicates [ON/OFF] status as judged from ICC steering switch
signal (ECM transmits ICC steering switch signal through CAN
communication).
CANCEL SW
[ON/OFF] ××× Indicates [ON/OFF] status as judged from ICC steering switch
signal (ECM transmits ICC steering switch signal through CAN
communication).
RESUME/ACC SW
[ON/OFF] ××× Indicates [ON/OFF] status as judged from ICC steering switch
signal (ECM transmits ICC steering switch signal through CAN
communication).
CRUISE OPE
[ON/OFF] ××
Indicates whether controlling or not (ON means “controlling”).
BRAKE SW
[ON/OFF] ××× Indicates [ON/OFF] status as judged from ICC brake switch sig-
nal.
STOP LAMP SW
[ON/OFF] ××× Indicates [ON/OFF] status as judged from stop lamp switch sig-
nal.
RELEASE SW NO
[ON/OFF] ×× Indicates [ON/OFF] status as judged from release switch signal.
ON when brake is depressed.
OFF when brake is not depressed.

TROUBLE DIAGNOSIS — GENERAL DESCRIPTION ACS-35
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2006 July 2007 FX35/FX45
ACTIVE TEST
CAUTION:

Never perform the active test while driving.

Active test cannot be started while ICC system warning indicator illuminates.
1. Touch “ACTIVE TEST” on “SELECT DIAG MODE” screen. Refer to GI-38, "
CONSULT-II Start Procedure"
.
2. Touch any of “ICC BUZZER 1”, “METER LAMP”, “STOP LAMP” and “BOOSTER SOL/V 3” on selection screen.
3. Touch necessary item and “START”.
4. Active test screen will be shown.
ICC BUZZER 1

Touch “ON” and “OFF” to check that ICC warning chime oper-
ates as in the following chart.
METER LAMP

Start engine.

Touch “ON” and “OFF” to check that ICC system display oper-
ates as in the following chart.
STOP LAMP

Touch “ON” and “OFF” to check that stop lamp operates as in
the following chart.
SKIA6195E
BUZZER O/P ON OFF
Buzzer sound Beep Not activated
SKIA1228E
METER LAMP ON OFF
ICC system display Full illumination OFF
SKIA1231E
STP LMP DRIVE ON OFF
Stop lamp Lamp ON Lamp OFF
SKIA1232E

TROUBLE DIAGNOSIS — GENERAL DESCRIPTION ACS-37
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2006 July 2007 FX35/FX45
Self-Diagnostic FunctionNKS003F2
WITH CONSULT-II
1. Go to operation check after asking the customer for symptom information. Refer to ACS-11, "ACTION
TEST" .
2. Stop vehicle, turn ignition switch OFF, then connect CONSULT-II and CONSULT-II CONVERTER to data link connector.
3. With engine started, touch “START (NISSAN BASED VHCL)”, “ICC”, “SELF-DIAG RESULTS” on CON- SULT-II screen in this order.
CAUTION:
If “ICC” cannot be shown after several attempts, the ICC unit may have had malfunction. Repair or
replace it. Refer to GI-39, "
CONSULT-II Data Link Connector (DLC) Circuit" .
4. Self-diagnostic result appears on screen. If “NO DTC ···” is shown, check ICC warning lamp. If any mal- function is indicated, GO TO step 5.
5. According to ACS-42, "
Diagnostic Trouble Code (DTC) Chart" , perform appropriate check, and repair or
replace malfunctioning part as necessary.
6. Turn ignition switch OFF.
7. Start the engine and touch “START (NISSAN BASED VHCL)”, “ICC”, “SELF-DIAG RESULTS”, and “ERASE” on CONSULT-II display in turn to erase the memory.
CAUTION:
If the memory does not erase, go to 5.
8. Perform ICC system running test (drive vehicle with ICC system ON), and make sure that ICC warning lamp does not illuminate.
WITHOUT CONSULT-II
1. Go to operation check after asking the customer for symptom information. Refer to ACS-11, "ACTION
TEST" .
2. Stop the vehicle to start the self-diagnosis.
3. Turn ignition switch OFF.
4. From 5 seconds through 15 seconds after turning ignition switch ON, press RESUME/ACCELERATE switch 5 times, and SET/
COAST switch 5 times.
CAUTION:

Never start engine.

Never turn the MAIN switch ON.

When operation above is not completed from 5 seconds
through 15 seconds, start again from above go to 3.

If self-diagnosis mode cannot be started after several
attempts, the ICC unit may have had malfunction. Repair
or replace it. Refer to ACS-39, "
SELF-DIAGNOSIS BY ICC
SYSTEM DISPLAY WILL NOT RUN" .
PKIA9675E

ACS-38
[ICC]
TROUBLE DIAGNOSIS — GENERAL DESCRIPTION
Revision: 2006 July 2007 FX35/FX45
5. When self-diagnosis mode is started, DTC are shown on set vehicle speed indicator.
CAUTION:

DTC will disappear after 5 minutes.

When more than one malfunction is detected, a maximum of 3 code numbers can be stored; the
latest malfunction will be displayed first.
6. Check ACS-42, "
Diagnostic Trouble Code (DTC) Chart" , and repair or replace if necessary.
7. After repair, erase DTC stored in the ICC unit.
8. DTC 55 will be shown.
9. Turn ignition switch OFF to exit the diagnosis.
10. Perform ICC system running test (drive vehicle with ICC system ON), and make sure that ICC warning lamp (Orange) does not illuminate.
Self-Diagnostic Erasing Method
1. Stop the vehicle and turn the ignition switch OFF.
2. Turn ignition switch ON and start self-diagnosis.
3. During self-diagnosis mode, press CANCEL switch 5 times, and DISTANCE switch 5 times in this order. CAUTION:

Press them within 10 seconds after pressing CANCEL switch at first.

When operation is not completed within 10 seconds, start again from step 2 above.
4. DTC 55 will be shown.
CAUTION:
DTC of an existing malfunction will not be erased.
5. Turn ignition switch OFF to exit the diagnosis.
6. Perform ICC system running test (drive vehicle with ICC system ON), and make sure that ICC system warning lamp (Orange) does not illuminate.
PKIA9820E

AT-32
A/T CONTROL SYSTEM
Revision: 2006 July 2007 FX35/FX45
TCM FunctionNCS001AZ
The function of the TCM is to:

Receive input signals sent from various switches and sensors.

Determine required line pressure, shifting point, lock-up operation, and engine brake operation.

Send required output signals to the respective solenoids.
CONTROL SYSTEM OUTLINE
The automatic transmission senses vehicle operating conditions through various sensors or signals. It always
controls the optimum shift position and reduces shifting and lock-up shocks.
CONTROL SYSTEM DIAGRAM
SENSORS (or SIGNALS)

TCM

ACTUATORS
PNP switch
Accelerator pedal position signal
Closed throttle position signal
Wide open throttle position signal
Engine speed signal
A/T fluid temperature sensor
Revolution sensor
Vehicle speed signal
Manual mode switch signal
Stop lamp switch signal
Turbine revolution sensor
ATF pressure switch Shift control
Line pressure control
Lock-up control
Engine brake control
Timing control
Fail-safe control
Self-diagnosis
CONSULT-II communication line
Duet-EA control
CAN system Input clutch solenoid valve
Direct clutch solenoid valve
Front brake solenoid valve
High and low reverse clutch
solenoid valve
Low coast brake solenoid valve
Torque converter clutch solenoid
valve
Line pressure solenoid valve
A/T CHECK indicator lamp
Starter relay
Back-up lamp relay
SCIA5325E

A/T CONTROL SYSTEM AT-33
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2006 July 2007 FX35/FX45
CAN CommunicationNCS001B0
SYSTEM DESCRIPTION
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only. For details, refer to LAN-49,
"CAN System Specification Chart" .
Input/Output Signal of TCMNCS001B1
*1: Spare for vehicle speed sensor·A/T (revolution sensor)
*2: Spare for accelerator pedal position signal
*3: If these input and output signals are different, the TCM triggers the fail-safe function.
*4: Used as a condition for starting self-diagnostics; if self-diagnostics are not started, it is judged that there is some kin d of error.
*5: Input by CAN communications
*6: Output by CAN communications Control item
Line
pressure control Vehicle
speed
control Shift
control Lock-up
control Engine
brake
control Fail-safe
function (*3) Self-diag-
nostics
function
Input Accelerator pedal position signal
(*5)XXXXXXX
Vehicle speed sensor A/T
(revolution sensor) XXXXXXX
Vehicle speed sensor MTR
(*1) (*5)X
Closed throttle position signal
(*5)X (*2) X X X X (*4)
Wide open throttle position signal
(*5)XX (*4)
Turbine revolution sensor 1 X X X X X
Turbine revolution sensor 2
(for 4th speed only) X XXXX
Engine speed signals
(*5)XXXXXXX
Stop lamp switch signal
(*5)XXX X (*4)
A/T fluid temperature sensors 1, 2XXXX XX
ASCD or
ICC Operation signal
(*5)XXX
Overdrive cancel
signal
(*5)X
Out-
put Direct clutch solenoid (ATF pres-
sure switch 5) XX XX
Input clutch solenoid (ATF pressure
switch 3) XX XX
High and low reverse clutch sole-
noid (ATF pressure switch 6) XX XX
Front brake solenoid (ATF pressure
switch 1) XX XX
Low coast brake solenoid (ATF
pressure switch 2) XX XXX
Line pressure solenoid XXXXXXX
TCC solenoid X X X
Self-diagnostics table
(*6)X
Sta rter rela y XX
