Page 641 of 2898

NISSAN ALMERA 2001 Service Manual Rear Door Lock=NJBT0011 SBT982 +For removal of rear door finisher, refer to ªDOOR TRIMº, BT-39. +Remove sealing screen. SBT978 OUTSIDE HANDLE ROD ADJUSTMENTNJBT0011S01Rotate rod holder so that rod-t

Page 642 of 2898

NISSAN ALMERA 2001 Service Manual SBT983 REMOVAL=NJBT0011S02+For removal of rear door finisher, refer to ªDOOR TRIMº, BT-39. +Remove sealing screen. +Set the door glass in the full-close position. 1. Remove inside handle escutcheon

Page 643 of 2898

NISSAN ALMERA 2001 Service Manual Removal and InstallationNJBT0012CAUTION: +Disconnect ground terminal from battery in advance. +Disconnect air bag system line in advance. +Never tamper with or force air bag lid open, as this may adve

Page 644 of 2898

NISSAN ALMERA 2001 Service Manual SBT985-A *1 RS-29 *2 BT-31 *3 RS-35 INSTRUMENT PANEL ASSEMBLY Removal and Installation (Contd) BT-26

Page 645 of 2898

NISSAN ALMERA 2001 Service Manual SBT986 *2 BT-31 INSTRUMENT PANEL ASSEMBLY Removal and Installation (Contd) BT-27

Page 646 of 2898

NISSAN ALMERA 2001 Service Manual NBT186 INSTRUMENT PANEL ASSEMBLY Removal and Installation (Contd) BT-28

Page 647 of 2898

NISSAN ALMERA 2001 Service Manual NBT187 INSTRUMENT PANEL ASSEMBLY Removal and Installation (Contd) BT-29

Page 648 of 2898

NISSAN ALMERA 2001 Service Manual NBT188 INSTRUMENT PANEL ASSEMBLY Removal and Installation (Contd) BT-30
