Page 209 of 4087

LEXUS SC400 1991 Service Repair Manual
5. DISPOSAL OF STEERING WHEEL PAD (WITH AIRBAG)CAUTION:
w The steering wheel pad is very hot when the airbag is
deployed, so leave it alone for at least 30 minutes after
deployment.
w Use gloves an

Page 210 of 4087

LEXUS SC400 1991 Service Repair Manual
3.14 X (Diameter)2
4
3. FIX STEERING WHEEL PAD TO DISC WHEEL WITH TIRE(a) Install bolts with washers in the four bolt holes in thesteering wheel pad.
Bolt: L 35.0 mm (1.4 in.) M 6.0 mm
Pitch 1.0

Page 211 of 4087

LEXUS SC400 1991 Service Repair Manual
wAlways tie down the steering wheel pad with the pad
side facing upward. It is very dangerous if the steer-
ing wheel pad is tied down with the metal surface
facing upward as the wire harness will be

Page 212 of 4087

LEXUS SC400 1991 Service Repair Manual
(Covering Method Using Tires)
Place at least three tires without disc wheel on top of the disc
wheel with tire to which the steering wheel pad is tied.
Tire size: Must exceed the following dimensions

Page 213 of 4087

LEXUS SC400 1991 Service Repair Manual
CONFIRM FUNCTIONING OF SST
When deploying the airbag, always use the specified SST:
SRS AIRBAG DEPLOYMENT TOOL.
SST 09082±00700
1. CONNECT SST TO BATTERY Connect the red clip of the SST to the ba

Page 214 of 4087

LEXUS SC400 1991 Service Repair Manual
SERVICE SPECIFICATIONS
SERVICE DATA
TerminalFront airbag sensor resistance
S ± A755±885 S A
S ± S
755 885

S ± ALess than 1
TORQUE SPECIFICATIONS
Part tightenedNVmkgf Vcmft

Page 215 of 4087

LEXUS SC400 1991 Service Repair Manual
SRS AIRBAG
AB±1INTRODUCTION
WhereEverybodyKnowsYourName

Page 216 of 4087

$LEXUS SC400 1991 Service Repair Manual GENERAL DESCRIPTION The LEXUS SC400 is equipped with an SRS (Supplemental Restraint System) a\ irbag. Failure to carry out service operations in the correct sequence could cause the\ airbag system t$

GENERAL DESCRIPTION
The LEXUS SC400 is equipped with an SRS (Supplemental Restraint System) a\
irbag.
Failure to carry out service operations in the correct sequence could cause the\
airbag system to unex-
pectedly deploy during servicing, possibly leading to a serious accident.
Further, if a mistake is made in servicing the airbag system, it is possible the\
airbag may fail to operate
when required.
Before performing servicing (including removal or installation of parts, insp\
ection or replacement), be
sure to read the following items carefully, then follow the correct procedure described in the repair
manual.
1. Malfunction symptoms of the airbag system are difficult to confirm, so the diagnostic codes become themost important source of information when troubleshooting.
When troubleshooting the airbag system, always inspect the diagnostic co\
des before disconnecting the
battery (See page AB±25).
2. Work must be started after approx. 20 seconds or longer from the time the ig\
nition switch is turned to the LOCK position and the negative (±) terminal cable is disconnec\
ted from the battery. (The
airbag system is equipped with a back±up power source so that if work is sta\
rted within 20 seconds
of disconnecting the negative (±) terminal cable of the battery, the airbag may be deployed.)
When the negative (±) terminal cable is disconnected from the battery, memory of the clock and audio sys-
tems will be cancelled. So before starting work, make a record of the conten\
ts memorized by the audio
memory system. Then when work is finished, reset the audio systems as before a\
nd adjust the clock. When
the vehicle has power tilt and power telescopic steering, power seat, power \
outside rear view mirror and
power shoulder belt anchorage, which are all equipped with memory function, it\
is not possible to make
a record of the memory contents. So when the work is finished, it will be\
necessary to explain this fact to
the customer, and ask the customer to adjust the features and reset the memory. To avoid erasing the
memory of each memory system, never use a back±up power supply from outside\
the vehicle.
3. Even in cases of a minor collision where the airbag does not deploy, the front airbag sensors and
the steering wheel pad should be inspected (See page AB±9).
4. Never use airbag parts from another vehicle. When replacing parts, replace them with new parts.
5. Before repairs, remove the airbag sensors if shocks are likely to be applied to the sensors during repairs.
6. Never disassemble and repair the front airbag sensors, center airbag sensor a\
ssembly or steering
wheel pad in order to reuse it.
7. If the front airbag sensors, center airbag assembly or steering wheel pa\
d have been dropped, or if there are cracks, dents or other defects in the case, bracket or conn\
ector, replace them with new
ones.
8. Do not expose the front airbag sensors, center airbag sensor assembly or\
steering wheel pad directly to hot air or flames.
9. Use a volt/ohmmeter with high impedance (10 kW/V minimum) for troubleshoo\
ting of the electrical circuit.
10. Information labels are attached to the periphery of the airbag components. Follow t\
he instructions
on the notices.
11. After work on the airbag system is completed, perform the airbag warning\
light check (See page AB±30 ).
AB±2
SRS AIRBAG
± General Description
