Page 593 of 4087

LEXUS SC400 1991 Service Repair Manual (Circuit) Disconnect the control panel connector and inspect the con- nector on wire harness side as shown. Check forTester connectionConditionSpecified value Voltage2±GroundLight control switch po

Page 594 of 4087

LEXUS SC400 1991 Service Repair Manual (With CD player) Check forTester connectionConditionSpecified value VoltageA4±GroundConstantBattery voltage A3±GroundIgnition switch positionACC or ONBattery voltageg LOCKNo voltage A2±GroundLight

Page 595 of 4087

LEXUS SC400 1991 Service Repair Manual (Woofer) REMOVAL AND INSTALLATION OF WOOFER 1. REMOVE WOOFER(a) Remove woofer cover together with high mount stoplight. (b) Remove four bolts. (c) Disconnect connector and remove woofer. 2. INSTAL

Page 596 of 4087

LEXUS SC400 1991 Service Repair Manual (c) Disconnect the connector and remove the wooferamplifier. 2. INSTALL WOOFER AMPLIFIER For installation, follow the removal procedure in reverse. INSPECTION OF WOOFER AMPLIFIER INSPECT WOOFER AMP

Page 597 of 4087

LEXUS SC400 1991 Service Repair Manual (Nakamichi) 1. REMOVE POWER AMPLIFIER (a) Remove the RH side cover. (b) Remove the CD auto changer (See page BE±212). (c) Disconnect three connectors and remove three nuts and the power amplifi

Page 598 of 4087

LEXUS SC400 1991 Service Repair Manual (Produced by NAKAMICHI)  Check for Tester connection Condition Specified value   Continuity

Page 599 of 4087

LEXUS SC400 1991 Service Repair Manual   Check for Tester connection Condition Specified value  Voltage A4±Ground

Page 600 of 4087

LEXUS SC400 1991 Service Repair Manual MOTOR ANTENNA MOTOR ANTENNA REMOVAL AND INSTALLATION 1. REMOVE MOTOR ANTENNA (a) Remove the antenna nut. (b) Remove the LH side cover. (c) Disconnect the motor antenna connector and the antennaco
