Page 545 of 4087

(Left Side Motor/Circuit Breaker Operation)
Driver 's Door
(a) Disconnect the connector from the master switch.
(b) Connect the positive (+) lead from the battery to terminal
9 and the negative (±) lead to terminal 10 on the wire
harness side connector and raise the window to full
closed position.
(c) Continue to apply voltage, check that there is a circuit breaker operation noise within approximately 4 to 40
seconds.
(d) Reverse the polarity, check that the window begins to descend within approximately 60 seconds.
If operation is not as specified, replace the motor.
Passenger 's Door
(a) Disc onnect the connector from the power window
switch.
(b) Connect the positive (+) lead from the battery to terminal
2 and the negative (±) lead to terminal 5 on the wire
harness side connector, and raise the window to full
closed position.
(c) Continue to apply voltage, check that there is a circuit
breaker operation noise within approximately 4 to 40
seconds.
(d) Reverse the polarity, check that the window begins to descend within approximately 60 seconds.
If operation is not as specified, replace the motor.
±
BODY ELECTRICAL SYSTEM Power Window Control SystemBE±153
WhereEverybodyKnowsYourName
Page 546 of 4087
(Right Side Door Motor/Motor Operation)
(a) Connect the positive (+) lead from the battery to terminal
1 and the negative (±) lead to terminal 2, check that the
motor turns clockwise.
(b) Re ve rse th e po la rity, ch e ck th a t th e mo to r tu rn s counterclockwise.
If operation is not as specified, replace the motor.
(Right Side Door Motor/Circuit Breaker Operation)
See Step of Left Side Motor on page BE±153.
BE±154
±
BODY ELECTRICAL SYSTEM Power Window Control System
WhereEverybodyKnowsYourName
Page 547 of 4087

(Circuit)
(a) Disconnect the connector from the motor.
(b) Connect the connector to the master switch and powerwindow switch.
(c) Inspect the c onnector on the wire harness side as
shown.
Check forTester connectionConditionSpecified value
Voltage1±GroundIgnition switch ON andDOWNBattery positive voltagegIgnition switch ON and
master switch positionUP or OFFNo voltage
*Ignition switch ON andDOWNBatterypositive voltage* Ignition switch ON and
power window switch
DOWNBattery ositive voltage
power window switch
iti
UP or OFFNo voltagepositionUP or OFFNo voltage
2±GroundIgnition switch ON andUPBattery positive voltageIgnition switch ON and
master switch positionDOWN or OFFNo voltage
*Ignition switch ON andUPBatterypositive voltage* Ignition switch ON and
power window switch
UPBattery ositive voltage
power window switch
iti
DOWN or OFFNo voltagepositionDOWN or OFFNo voltage
*: Set the window lock switch to the unlock position.
If the circuit is not as specified, refer to BE±148 wiring dia-
gram and inspect the circuits connected to other parts.
(Theft Deterrent and Door Lock Control
ECU)
REMOVAL AND INSTALLATION OF
THEFT DETERRENT AND DOOR LOCK
CONTROL ECU
1. REMOVE THEFT DETERRENT AND DOOR LOCK CONTROL ECU
(a) Remove following parts.(See page BO±112 and 113)
w Instrument No. 1 Under Cover.
w Instrument No. 1 lower finish panel.
(b) Disconnect the connector and remove the ECU
2. INSTALL THEFT DETERRENT AND DOOR LOCK CONTROL ECU
For installation, follow the removal procedure in reverse.
±
BODY ELECTRICAL SYSTEM Power Window Control SystemBE±155
WhereEverybodyKnowsYourName
Page 548 of 4087

INSPECTION OF THEFT DETERRENT
AND DOOR LOCK CONTROL ECU
INSPECT THEFT DETERRENT AND DOOR LOCK CONTROL
ECU(Circuit)
(a) Inspect ECU Power Source Circuit.(See page BE±376)
(b) Inspect Actuator Power Source Circuit.
(See page BE±378)
(c) Inspect Ignition Switch Circuit. (See page BE±25)
(d) Inspect Door Open Detection Switch Circuit.
(See page BE±392)
If circuit is as specified, inspect ECU operation.
(Operation)
(a) With the connectors connected, shut all doors.
(b) Check that there is 10 V ~ 14 V between terminal B8 and
ground when the ignition switch is turned on.
(c) After turning the ignition switch off, check within 60 seconds that there is battery voltage between terminal
B8 and ground.
(d) Turn the ignition switch on then off, and check that there
is 10 V ~ 14 V between terminal B8 and ground when the
ignition is switched off.
(e) Open the front door within 60 seconds of turning the
ignition off and check that there is no voltage between
terminal B8 and ground.
(f) Close all the doors and turn the ignition switch on.
(g) When a front door is opened, check that there is battery voltage between terminal B8 and ground.
(h) Check that there is no voltage between terminal B8 and ground when the ignition switch is turned to off.
If operation is not as specified, replace the ECU.
BE±156
±
BODY ELECTRICAL SYSTEM Power Window Control System
WhereEverybodyKnowsYourName
Page 549 of 4087

Troubleshooting
You will find the cause of trouble more easily by properly using the table \
shown below. In this table, the
numbers indicate the order of priority of the causes of trouble. Check each part in \
the order shown. If neces-
sary, replace the part.
See page
BE±4 ,21BE±4,21BE±4,20BE±4,20BE±156BE±152BE±149BE±151BE±152BE±26BE±392BE±4,20 ±±
Part
name
Trouble
AM1 FuseDOME FuseDOOR FusePOWER FuseTheft Deterrent and Door Lock Control ECUPower Window Main RelayPower Window Master SwitchPower Window SwitchPower Window MotorIgnition SwitchDoor Open Detection SwitchECU±IG FuseWire Harness
*1 Power window does not operate.1234
*2 Power window does not operate.35467218
ªOne Touch Power Window Systemº does
not operate.1
Only one window glass does not move.1234
ªWindow Lock Systemº does not operate1
ªWindow Lock Illuminationº does not light
up.1
Key±off power window does not operate124536
*1: Dook Lock does not operate.
*2: Dook Lock is normal.
±
BODY ELECTRICAL SYSTEM Power Window Control SystemBE±157
WhereEverybodyKnowsYourName
Page 550 of 4087
LIQUID CRYSTAL INNER MIRROR
SYSTEM
Description
The liquid crystal inner mirror replaces the previous mirror, which mechanically switched between the ªDayº and
ªNightº settings, with liquid crystal inside the mirror which changes the bright\
ness of the mirror surface. The com-
ponent parts of this system and their functions are shown in the table below.
Parts NameFunction
Liquid Crystal Inner
MirrorReceives current from the fuse DOME and changes the surface brightness o\
f the mirror
when switch is operated.
Key Unlock Warning
SwitchOpens the circuit so that the mirror can be operated only when the ignit\
ion key is set.
Parts Location
BE±164±
BODY ELECTRICAL SYSTEM Liquid Crystal Inner Mirror System
WhereEverybodyKnowsYourName
Page 551 of 4087
Wiring and Connector Diagrams
Parts Inspection
(Liquid Crystal Inner Mirror)
REMOVAL AND INSTALLATION OF
LIQUID CRYSTAL INNER MIRROR
(See page BO±44)
INSPECTION OF LIQUID CRYSTAL
INNER MIRROR
INSPECT LIQUID CRYSTAL INNER MIRROR
(a) Using a screw driver, pry out the cover.
(b) Remove two screws and center visor.
(Operation)
(a) Connect the positive (+) lead from the battery to terminal
1 and the negative (±) lead to terminal 2.
±
BODY ELECTRICAL SYSTEM Liquid Crystal Inner Mirror SystemBE±165
WhereEverybodyKnowsYourName
Page 552 of 4087

(b) Press the mirror switch and check if the mirrors surfacerepeatedly becomes ºbrightº and ºdarkº.
If operation is not as specified, replace the liquid crystal inner
mirror.
(Circuit)
Disconnect the inner mirror connector and inspect the con-
nector on the wire harness side as shown.
Check forTester connectionConditionSpecified value
Voltage2±GroundConstantBattery voltage
Continuity1 GroundIgnition key setContinuityContinuity1±GroundIgnition key removedNo continuity
If circuit is not as specified, refer to BE±165 wiring diagram
and inspect the circuits connected to other parts.
(Key Unlock Warning Switch)
(See page BE±26)
Troubleshooting
You will find the cause of trouble more easily by properly using the table \
shown below. In this table, the numbers
indicate the order of priority of the cruses of trouble. Check each part in the \
order shown. If necessary, replace
the part.
See pageBE±4,21BE±165BE±26 ±±
TroubleParts
name
DOME FuseLiquid Crystal Inner MirrorKey Unlock Warning SwitchWire Harness
Liquid Crystal Inner Mirror does not operate.1234
BE±166±
BODY ELECTRICAL SYSTEM Liquid Crystal Inner Mirror System
