LEXUS SC400 1991 Service Repair Manual PREPARATION SST (SPECIAL SERVICE TOOLS) SA02Q±07 RECOMMENDED TOOLS SA06X±03 EQUIPMENT SA02S±02 \   \   \

Page 3290 of 4087

LEXUS SC400 1991 Service Repair Manual FRONT SHOCK ABSORBER COMPONENTS SA00A±0A ± SUSPENSION AND AXLE FRONT SUSPENSIONSA±27 WhereEverybodyKnowsYourName

Page 3291 of 4087

LEXUS SC400 1991 Service Repair Manual FRONT SHOCK ABSORBER REMOVAL SA0RN±04 1. JACK UP VEHICLE AND REMOVE FRONT WHEEL 2. REMOVE BRAKE CALIPER (a) Remove the 2 bolts and caliper from the steering knuckle. (b) Hang up the brake caliper

Page 3292 of 4087

LEXUS SC400 1991 Service Repair Manual (b) Remove the 3 bolts and disconnect the wire harness clampto prevent the wire harness being damaged when removing or installing the through bolt. 6. LOOSEN PISTON ROD LOCK NUT (a) Remove the pl

Page 3293 of 4087

LEXUS SC400 1991 Service Repair Manual (b) Remove 3 nuts and shock absorber from the body. FRONT SHOCK ABSORBER DISASSEMBLY SA0RP±04 1. REMOVE SUSPENSION SUPPORT AND COIL SPRING (a) Using SST, compress the coil spring.SST 09727±30020

Page 3294 of 4087

LEXUS SC400 1991 Service Repair Manual FRONT SHOCK ABSORBER INSPECTION SA0RQ±03 INSPECT SHOCK ABSORBER Compress and extend the shock absorber rod and check that there is no abnormal resistance or unusual operation sounds. If there is any

Page 3295 of 4087

LEXUS SC400 1991 Service Repair Manual (b) Install the coil spring to the shock absorber.HINT: Fit the lower end of the coil spring into the gap of the spring seat of the shock absorber. 4. INSTALL SUSPENSION SUPPORT (a) Install the su

Page 3296 of 4087

LEXUS SC400 1991 Service Repair Manual 2. CONNECT SHOCK ABSORBER TO LOWERSUSPENSION ARM (a) Connect the shock absorber to lower suspension arm. (b) Install the bolt from the rear vehicle and temporarily tighten the nut. 3. TEMPORA
