Page 2145 of 4087

DISASSEMBLY OF OIL PUMP
(See Components on page LU±12)
1. REMOVE RELIEF VALVE (a) Slighty mount the pump body in a vise.
(b) Remove the plug, gasket, compression spring and reliefvalve.
NOTICE: Be careful not to damage the pump body.
2. REMOVE DRIVE AND DRIVEN ROTORS Remove the ten screws, pump body cover, the drive and
driven rotors.
INSPECTION OF OIL PUMP
1. INSPECT RELIEF VALVECoat the valve with engine oil and check that it falls smoothly
into the valve hole on its own weight.
If it doesn't, replace the relief valve. If necessary, replace the
oil pump assembly.
2. INSPECT DRIVE AND DRIVEN ROTORS
A. Place drive and driven rotors into oil pump body The marks on the rotors must face up.
B. Inspect rotor tip clearance Using a feeler gauge, measure the clearance between the
drive and driven rotors.
Standard tip clearance: 0.310±0.490 mm
(0.0122±0.0193 in.)
Maximum tip clearance: 0.53 mm (0.0209 in.)
If the tip clearance is greater than maximum, replace the ro-
tors as a set.
±
LUBRICATION SYSTEM Oil PumpLU±13
WhereEverybodyKnowsYourName
Page 2146 of 4087

C. Inspect rotor body clearanceUsing a feeler gauge, measure the clearance between the
driven rotor and pump body.
Standard body clearance: 0.100±0.175 mm
(0.0039±0.0069 in.)
Maximum body clearance: 0.20 mm (0.0079 in.)
If the body clearance is greater than maximum, replace the
rotors as a set. If necessary, replace the oil pump assembly.
D. Inspect rotor side clearance Using a feeler gauge and precision straight edge, measure
the clearance between the rotors and precision straight
edge.
Standard side clearance: 0.030±0.090 mm
(0.0012±0.0035 in.)
Maximum side clearance: 0.12 mm (0.0047 in.)
If the side clearance is greater than maximum, replace the ro-
tors as a set. If necessary, replace the oil pump assembly.
E. Remove drive and driven rotors
REPLACEMENT OF CRANKSHAFT
FRONT OIL SEAL
(See page EM±92)
ASSEMBLY OF OIL PUMP
(See Components on page LU±12)
1. INSTALL DRIVE AND DRIVEN ROTORS (a) Place the drive and driven rotors into oil pump body with
the mark facing upward.
(b) Install the pump body cover with the ten screws.
Torque: 10 N Vm (105 kgf Vcm, 8 ft Vlbf)
LU±14±
LUBRICATION SYSTEM Oil Pump
WhereEverybodyKnowsYourName
Page 2147 of 4087

2. INSTALL RELIEF VALVE(a) Slighty mount the pump body in a vise.
NOTICE: Be careful not to damage the pump body.
(b) Insert the relief valve and compression spring into the oil
pump body hole.
(c) Install the plug with a new gasket.
Torque: 49 N Vm (500 kgf Vcm, 36 ft Vlbf)
INSTALLATION OF OIL PUMP
(See Components on page LU±9)
1. INSTALL OIL PUMP (a) Place two new O±rings in position on the cylinder block.
(b) Remove any old packing (FIPG) material and be careful
not to drop any oil on the contact surfaces of the oil
pump cylinder block.
w Using a razor blade gasket scraper, remove all the
old packing (FIPG) material from the gasket
surfaces and sealing groove.
w Thoroughly clean all components to remove all the
debris.
w Using a non±residue solvent, clean both sealing
surfaces.
NOTICE: Do not use a solvent which will affect the
painted surfaces.
(c) Apply seal packing to the oil pump as shown in the illustration.
Seal packing: Part No. 08826±00080 or equivalent
w Install a nozzle that has been cut to a 2±3 mm
(0.08±0.12 in.) opening.
HINT: Avoid applying an excessive amount to the surface. Be
particularly careful near oil passages. w Parts must be assembled within 5 minutes of
application. Otherwise the material must be
removed and reapplied.
w Immediately remove nozzle from the tube and
reinstall cap.
±
LUBRICATION SYSTEM Oil PumpLU±15
WhereEverybodyKnowsYourName
Page 2148 of 4087

(d) Install the oil pump with the seven bolts (A) and two bolts
(B).
Torque: 21 N Vm (210 kgf Vcm, 15 ft Vlbf)
HINT: Hand tighten the (A) bolts first.
2. INSTALL NO.1 OIL PAN (a) Place a new O±ring in the position on the cylinder block.
(b) Remove any old packing (FIPG) material and be careful not to drop any oil on the contact surfaces of the No.1
oil pan and cylinder block.
w Using a razor blade and gasket scraper, remove all
the old packing (FIPG) material from the gasket
surfaces and sealing groove.
w thoroughly clean all components to remove all the
debris.
w Using a non±residue solvent, clean both sealing
surfaces.
NOTICE: Do not use a solvent which will affect the
painted surfaces.
(c) Apply seal packing to the No.1 oil pan as shown in the illustration.
Seal packing: Parts No. 08826±00080 or equivalent
w Install a nozzle that has been cut to a 3±4 mm
(0.12±0.16 in.) opening.
HINT: Avoid applying an excessive amount to the surface. w Parts must be assembled within 5 minutes of
application. Otherwise the material must be
removed and reapplied.
w Immediately remove nozzle from the tube and
reinstall cap.
(d) Install the No.1 oil pan with the 22 bolts.
Torque: 12 mm head bolt 21 N Vm (210 kgf Vcm, 15 ft Vlbf)
14 mm head bolt 39 N Vm (400 kgf Vcm, 29 ft Vlbf)
LU±16±
LUBRICATION SYSTEM Oil Pump
WhereEverybodyKnowsYourName
Page 2149 of 4087

3. INSTALL OIL PAN BAFFLE PLATEInstall the baffle plate with the five bolts and two nuts.
Torque: 8.8 N Vm (90 kgf Vcm, 78 in. Vlbf)
4. INSTALL OIL STRAINER
Install a new gasket and the oil strainer with the bolt and two
nuts.
Torque: 8.8 N Vm (90 kgf Vcm, 78 in. Vlbf)
5. INSTALL NO.2 OIL PAN
(a) Remove any old packing (FIPG) material and be carefulnot to drop any oil on the contact surfaces of the No.1
and No.2 oil pans.
w Using a razor blade and gasket scraper, remove all
the old packing (FIPG) material from the gasket
surfaces and sealing groove.
w Thoroughly clean all components ro remove all the
debris.
w Using a non±residue solvent, clean both sealing
surfaces.
NOTICE: Do not use a solvent which will affect the
painted surfaces.
(b) Apply seal packing to the No.2 oil pan as shown in the
illustration.
Seal packing: Part No. 08826±00080 or equivalent
w Install a nozzle that has been cut to a 3±4 mm
(0.12±0.16 in.) opening.
HINT: Avoid applying an excessive amount to the surface.
w Parts must be assembled within 5 minutes of
application. Otherwise the material must be
removed and reapplied.
w Immediately remove nozzle from the tube and
reinstall cap.
(c) Install the No.2 oil pan with the 14 bolts and two nuts.
Torque: 8.8 N Vm (90 kgf Vcm, 78 in. Vlbf)
±
LUBRICATION SYSTEM Oil PumpLU±17
WhereEverybodyKnowsYourName
Page 2150 of 4087
6. INSTALL OIL LEVEL SENSOR(a) Install a new gasket to the level sensor.
(b) Install the level sensor with the four bolts.
Torque: 5.4 N Vm (55 kgf Vcm, 48 in. Vlbf)
(c) Connect the level sensor connector.
7. INSTALL OIL DIPSTICK GUIDE AND DIPSTICK (a) Install a new O±ring on the dipstick guide.
(b) Apply soapy water on the O±ring.
(c) Push in the dipstick guide into the guide hole of the No.1
oil pan.
(d) Install the guide with the mounting bolt.
8. INSTALL CRANKSHAFT TIMING PULLEY AND IDLER PULLEY
(See steps 1 and 2 on page EM±29)
9. INSTALL TIMING BELT (See steps 3 to 14 on pages EM±29 to 33)
10. REMOVE ENGINE STAND FROM ENGINE
11. ASSEMBLE ENGINE AND TRANSMISSION (See page EM±103)
12. INSTALL ENGINE WITH TRANSMISSION (See pages EM±104 to 112)
LU±18
±
LUBRICATION SYSTEM Oil Pump
WhereEverybodyKnowsYourName
Page 2151 of 4087

SERVICE SPECIFICATIONS
SERVICE DATA
MA002±0B
Engine
Spark plug
Recommended spark plug
Correct electrode gap
Firing order
Valve clearance
ND
NGK
Intake
Exhaust
\
\
PK20R11
BKR6EP11
1.1 mm (0.043 in.)
1 ± 8 ± 4 ± 3 ± 6 ± 5 ± 7 ± 2
0.15 ± 0.25 mm (0.006 ± 0.010 in.)
0.25 ± 0.35 mm (0.010 ± 0.014 in.)
BrakeFront and rear brakes
Pad thickness
Disc thickness
Limit
Limit (Front) (Rear)1.0 mm (0.039 in.)
30.0 mm (1.181 in.)
15.0 mm (0.591 in.)
Disc runout
Parking brake
Lining thickness
Drum inside diameter
()
Limit
Limit
Limit
()
0.05 mm (0.0020 in.)
1.0 mm (0.039 in.)
191 mm (7.520 in.)
ChassisSteering linkage
Steering wheel freeplay
Limit30 mm (1.18 in.)
gy
Ball joint
Vertical play
Limit
()
0.3 mm (0.012 in.)
MA002±0B
TORQUE SPECIFICATIONS
\
\
Part tightened N
Vm kgf Vcm ft Vlbf
Spark plug x Cylinder head1818013
Front seat x Body3737527
Front suspension crossmember x Body for nut1271,30094
for bolt 201
,
2,050148
Rear suspension member x Body1761,800130
Rear suspension member rear cushion x Body3839028
±
MAINTENANCE (1UZ ± FE)MA±21
WhereEverybodyKnowsYourName
Page 2152 of 4087
MAINTENANCE
GENERAL NOTES:
wThere are 2 separate maintenance schedules,
namely A and B, which apply to different driving
conditions. Find out how the vehicle is driven,
select the appropriate schedule and service the
vehicle accordingly.
w Every service item in the periodic maintenance list
must be performed.
w Next to the columns of periods in the schedule,
reference pages have been added for easy access
to service data and procedures necessary for each
operation.
w The service interval for scheduled maintenance is
determined by the odometer reading or time
interval, whichever comes first, shown in the
schedule.
w Maintenance services after the last period should
be performed at the same interval as before unless
otherwise noted.
w Skipping even 1 item in the list can cause the
engine to run poorly and increase exhaust
emissions.
MA±1
