Page 1217 of 4087

LEXUS SC400 1991 Service Repair Manual mmin. 2.0 3.9 4.0 0.08 0.15 0.16 SILENCER SHEET INSTALLATION AREAS 4.0 mm 2.0 mm2.0 mm3.9 mm 3.9 mm 3.9 mm 3.9 mm 2.0 mm 2.0 mm 3.9 mm 2.0 mm 3.9 mm3.9 mm 2.0 mm 3.9 mm 2.0 mm The figures in the illu

Page 1218 of 4087

LEXUS SC400 1991 Service Repair Manual FOAMED MATERIAL APPLICATION AREAS The sections shown in the figure below are filled with foamed material to provide noise insullation. After repairing these sections or their periph- eries, refill wi

Page 1219 of 4087

LEXUS SC400 1991 Service Repair Manual 1. WELD-THROUGH PRIMER (SPOT SEALER)APPLICATION For anti-corrosion measures, always apply the weld-through primer (spot sealer) to welding sur- faces where the paint film has been removed. HINT: Appl

Page 1220 of 4087

LEXUS SC400 1991 Service Repair Manual Steel MetalUndercoat (ED Primer) Anti-Chipping Paint Second Coat Steel Metal Undercoat (ED Primer) Second Coat Top Coat REFERENCE: ANTI-RUST TREATMENT BY PAINTING ANTI-RUST TREATMENT AFTER PAINTING

Page 1221 of 4087

LEXUS SC400 1991 Service Repair Manual BODY PANEL SEALING AREAS HINT:1. Prior to applying body sealer, clean the area with a rag soaked in a grease, wax and silicone remover\ . 2. If weld-through primer was used, first wipe off any excess

Page 1222 of 4087

LEXUS SC400 1991 Service Repair Manual Flat Surfacing Flat Surfacing ANTI-RUST TREATMENTAR-5 WhereEverybodyKnowsYourName

Page 1223 of 4087

LEXUS SC400 1991 Service Repair Manual Flat SurfacingFlat Surfacing Flat Surfacing Flat Surfacing ANTI-RUST TREATMENTAR-6 WhereEverybodyKnowsYourName

Page 1224 of 4087

LEXUS SC400 1991 Service Repair Manual Flat Surfacing (All Around) Hood Luggage Compartment Door Front Door Flat Surfacing Flat Surfacing (All Around) Flat Surfacing Flat Surfacing ANTI-RUST TREATMENTAR-7 WhereEverybodyKnowsYourName
