WIRING DIAGRAM
SRS Warning Light System (Always Lit Up, when ignition switch in
LOCK position)
CIRCUIT DESCRIPTION
The SRS warning light is located on the combination meter.
When the supplemental restraint system is normal, the SRS warning light ligh\
ts up for approx. 6 seconds after
the ignition switch is turned from LOCK position to ACC or ON position, and\
then turns off automatically.
If there is a malfunction in the supplemental restraint system, the SRS wa\
rning light lights up to inform the driver
of the abnormality.
When terminals Tc and E
1 of the DLC2 are connected, the diagnostic trouble code is displayed by \
the blinking
of the SRS warning light.
DIAGNOSTIC CHARTDIAGNOSTIC CHART
HINT: If the SRS warning light is always lit up by a DTC check procedure, per\
form Tc T erminal circuit check proce-
dure (See page RS±121).
±
SUPPLEMENTAL RESTRAINT SYSTEM TROUBLESHOOTINGRS±119
WhereEverybodyKnowsYourName
Page 3098 of 4087
YESNO
INSPECTION PROCEDURE
1Does SRS warning light turn off?
C
Hint
P1. Turn ignition switch LOCK.
2. Disconnect negative (±) terminal cable from battery
and wait at least 90 seconds.
3. Remove steering wheel pad (See page RS±19).
4. Disconnect connectors of front passenger airbag assembly (See page RS±32).
5. Disconnect center airbag sensor assembly con- nector.
6. Connect negative (±) terminal cable to battery.
Check operation of SRS warning light.
Ignition Switch is LOCK position.
Check SRS warning light circuit or terminal AB circuit of
DCL1 or DLC2.
Replace center airbag sensor assembly.
RS±120±
SUPPLEMENTAL RESTRAINT SYSTEM TROUBLESHOOTING
WhereEverybodyKnowsYourName
Page 3099 of 4087
Tc Terminal Circuit
CIRCUIT DESCRIPTION
By connecting terminal Tc and E1 of the DLC1 or DLC2, the center airbag sensor assembly is set in the di\
agnos-
tic trouble code output mode. The diagnostic trouble codes are displayed\
by the blinking of the SRS warning
light.
DIAGNOSTIC CHARTDIAGNOSTIC CHART
Troubleshooting for this system is different depending on whether the diagnostic trouble code is not displayed\
SRS warning light is always lit up with a DTC check procedure, or is displa\
yed without a DTC check procedure.
Confirm the problem symptoms first before selecting the appropriate troubleshoo\
ting procedure.
HINT: If the diagnostic trouble code is not displayed or SRS warning light is\
always lit up with a DTC check proce-
dure perform the following troubleshooting:
±
SUPPLEMENTAL RESTRAINT SYSTEM TROUBLESHOOTINGRS±121
WhereEverybodyKnowsYourName
Page 3100 of 4087
WIRING DIAGRAM
DIAGNOSTIC CHARTDIAGNOSTIC CHART
RS±122±
SUPPLEMENTAL RESTRAINT SYSTEM TROUBLESHOOTING
WhereEverybodyKnowsYourName
Page 3101 of 4087
NGOK
NGOK
INSPECTION PROCEDURE
HINT: If the diagnostic trouble code is not displayed, perform the following \
troubleshooting:
1Check voltage between terminals Tc and E1 of DLC1 or DLC2.
C
OK
PTurn ignition switch ACC or ON.
Measure voltage between terminals Tc and E
1 of DLC1
or DLC2.
Voltage: Battery positive voltage
Go to step .
2Check voltage between terminal Tc of DLC1 or DLC2 and body ground.
C
OK
Measure voltage between terminal Tc of DLC1 or DLC2
and body ground.
Voltage: Battery positive voltage
Check harness between terminal E1 of DLC1 or DLC2
and body ground.
±
SUPPLEMENTAL RESTRAINT SYSTEM TROUBLESHOOTINGRS±123
WhereEverybodyKnowsYourName
Page 3102 of 4087
NGOK
3Check center airbag sensor assembly.
C
OK
P1. Turn ignition switch LOCK.
2. Disconnect battery negative (±) terminal cable, andwait at least 90 seconds.
3. Remove steering wheel pad (See page RS±19).
4. Disconnect connectors of front passenger airbag assembly (See page RS±32).
Check operation of SRS warning light.
SRS warning light comes on.
Check harness between center airbag sensor assembly
and DLC1 or DLC2.
Replace center airbag sensor assembly.
RS±124±
SUPPLEMENTAL RESTRAINT SYSTEM TROUBLESHOOTING
WhereEverybodyKnowsYourName
Page 3103 of 4087
NGOK
HINT: If the diagnostic trouble code is continuously displayed, perform the f\
ollowing troubleshooting.
1Check resistance between terminal Tc of center airbag sensor assembly and body ground.
C
OK
P1. Turn ignition switch LOCK.
2. Disconnect center airbag sensor assembly con-nector.
3. Disconnect battery negative (±) terminal cable, and wait at least 90 seconds.
4. Remove steering wheel pad (See page RS±19).
5. Disconnect connectors of front passenger airbag assembly (See page RS±32).
Check resistance between terminal Tc of center airbag
sensor assembly and body ground.
Resistance: 1 M or higher
Replace center airbag sensor assembly.
Repair or replace harness or connector.
±
SUPPLEMENTAL RESTRAINT SYSTEM TROUBLESHOOTINGRS±125
WhereEverybodyKnowsYourName
Page 3104 of 4087
SERVICE SPECIFICATIONS
SERVICE DATA
RS02S±01
\
\
FRONT AIRBAG SENSOR\
\
\
\
S ± A\
\
755±855
\
\
S ± S\
\
1 M or Higher
\
\
S ± A\
\
Less than 1
TORQUE SPECIFICATIONS
RS02T±07
\
\
Part tightened NVm kgf Vcm ft Vlbf
\
\
Steering wheel 35 360 26
\
\
Steering wheel pad 7.4 75 65 in. Vlbf
\
\
Front passenger airbag assembly 21 210 15
\
\
Front airbag sensor 25 260 19
\
\
Center airbag sensor assembly 15 150 11
RS±126±
SUPPLEMENTAL RESTRAINT SYSTEM SERVICE SPECIFICATIONS
