DTC11, 12ABS Solenoid Relay Circuit
CIRCUIT DESCRIPTION
This relay supplies power to each ABS solenoid. After the ignition switch is\
turned on, if the initial check is OK,
the relay goes on.
DTC No.DTC Detecting ConditionTrouble Area
11
Conditions (1) and (2) continue for 0.2 sec. or more:
(1) ABS solenoid relay (SR) terminal voltage: Battery
positive voltage
(2) Solenoid relay monitor (AST) terminal voltage: 0V
ABS solenoid relay
Open or short in ABS solenoid relay circuit
ECU
12
Conditions (1) and (2) continue for 0.2 sec. or more:
(1) ABS solenoid relay (SR) terminal voltage: 0V
(2) Solenoid relay monitor (AST) terminal voltage: Bat- tery positive voltage
ABS solenoid relay
B+ short in ABS solenoid relay circuit
ECU
Fail safe function: If trouble occurs in the solenoid relay circuit, th\
e ECU cuts off current to the solenoid
relay and prohibits ABS control.
DIAGNOSTIC CHARTDIAGNOSTIC CHART
BR±94±
BRAKE SYSTEM ANTI±LOCK BRAKE SYSTEM (ABS)
WhereEverybodyKnowsYourName
Page 1064 of 4087
WIRING DIAGRAM
±
