HOW TO PROCEED WITH TROUBLESHOOTING
Perform troubleshooting in accordance with the procedure on the following page.\
CUSTOMER PROBLEM ANALYSIS
Using the customer problem analysis check sheet for reference, obtain as much detail as possible about
the problem.
PROBLEM SYMPTOM CONFIRMATION, SYMPTOM SIMULATION
Confirm the problem symptoms. If the problem does not reappear, be sure to simulate the problem, using
the ªProblem Simulation Methodsº.
MATRIX CHART OF PROBLEM SYMPTOMS
Confirm the order of inspection for each applicable problem symptom on t\
he matrix chart after first fully
confirming the scope of the problem symptoms. For example, if the tilt operation i\
s not working, check
whether the tilt is not working in manual, auto and return, and also check if the telescopic, seat or mirror
operation is not working in addition to the tilt operation.
CIRCUIT INSPECTION
Proceed with diagnosis of each circuit in accordance with the inspection order \
confirmed in . Judge
whether the cause of the problem is in the sensor, actuators, wire harness and connectors, or the ECU.
6 REPAIR
After the cause of the problem is located, perform repairs by following the i\
nspection and replacement pro-
cedures in this manual.
7 CONFIRMATION TEST After completing repairs, confirm not only that the malfunction is eliminated,\
but also seat and mirror opera-
tions are normal.
SR±45
SR±52
SR±62 ~ SR±101 IN±26
SR±44
±
STEERING STEERING COLUMN
WhereEverybodyKnowsYourName
Page 3067 of 4087
CUSTOMER PROBLEM ANALYSIS
±
STEERING STEERING COLUMNSR±45
WhereEverybodyKnowsYourName
Page 3068 of 4087
WIRING DIAGRAM
TILT & TELESCOPIC ECU
SR±46±
STEERING STEERING COLUMN
WhereEverybodyKnowsYourName
Page 3069 of 4087
SC300 (M/T)
±
STEERING STEERING COLUMNSR±47
WhereEverybodyKnowsYourName
Page 3070 of 4087
TERMINAL OF ECU
TILT & TELESCOPIC ECU
Terminal
No.
Symbol
Terminal Name
Terminal
No.
Symbol
Terminal Name
T9±1 Si Serial In T9±16 MSW Manual Switch
2 DSW Door Courtesy Switch 17 Vc Sensor Power Source
3 M1 Return Switch 1 18 ECU±B Power Source
4
ASW
Auto Switch
T10± 1
IG
Ignition Switch
5 E1 Sensor Ground 2 Te M+ Telescopic Contracted
6 Te S Telescopic Sensor 3 TiM± Tilt Down
7
TiS
Tilt Sensor
4
+B
Power Source
8
ECU±E
Ground
6
P
Park/Neutral Position Switch
9 So Serial Out 6 P Parking Brake Switch*
10 UWSW Unlock Warning Switch 7 GND Ground
11
MRY
Memory Switch
10
TiM+
Tilt Up
12 M2 Return Switch 2 11 TiM± Telescopic Extended
*
SC300 (M/T) Models
SR±48
±
STEERING STEERING COLUMN
WhereEverybodyKnowsYourName
Page 3071 of 4087

STANDARD VALUE OF ECU TERMINAL
Terminals
Symbols
Wiring
Color
Condition
Standard
Value
T9±1
Si
B
Tilt & telescopic ECU & power seat ECU
communication
0 V
e12 V
T9±2 e DSW e R±Be Driver's door open Below 1 V
T9 2 e
Body Ground
DSW e
Body Ground
RBe
Body GroundDriver's door closed1014 V
T9±3 eT9±8 M1 eECU±E Pe BR±B Driving position memory & return switch ON Below 1 V
T9±3eT9±8 M1eECU±E PeBR±B Driving position memory & return switch OFF 10
~ 14 V
T9±4
eT9±5 ASW eE1 V±W eBR Unlock warning switch ON, auto switch ON 10 ~ 14 V
T9±4eT9±5 ASWeE1 V±WeBR Unlock warning switch ON, auto switch OFF Below 1 V
T9±5 E1 BR Always Below 1 V
T9±6
eT9±5
Te S
eE1
Y±R
eBR
Unlock warning switch ON, telescopic fully
forward
Below 2 V
T9±6eT9±5
TeSeE1
Y±ReBR
Unlock warning switch ON, telescopic fully
backward 4±6 V
T9±7
eT9±5
TiS eE1
P±L eBR
Unlock warning switch ON, tilt fully raised Below 2 V T9±7eT9±5 TiSeE1 P±LeBR Unlock warning switch ON, tilt fully lowered 4±6 V T9±8 ECU±E BR±B Always Below 1 V
T9±9
So
W
Tilt & telescopic ECU & power seat ECU
communication
0 V
e12 V
T9±10 e UWSW e Ye Ignition key inserted in the key cylinder Below 1 V
T9 10 e
Body Ground UWSW e
Body Ground Ye
Body Ground Ignition key pulled out from the key cylinder 10
~ 14 V
T9±11 eT9±8
MRY eECU±E
R±Y eBR±B
Auto set switch ON Below 1 V
T9±11eT9±8 MRYeECU±E R±YeBR±B Auto set switch OFF 10 ~ 14 V
T9±12 eT9±8
M2 eECU±E
P±B eBR±B
Driving position memory & return switch ON Below 1 V
T9±12eT9±8 M2eECU±E P±BeBR±B Driving position memory & return switch OFF 10 ~ 14 V
Unlock warning switch ON
Telescopic extend by manual switch
2.6 V
Unlock warning switch ON
Tilt up by manual switch
3.5 V
T9±16
eT9±17 MSW eVC V±Y eR±W Unlock warning switch ON
Telescopic contracted by manual switch 4.2 V
Unlock warning switch ON
Tilt down by manual switch
4.6 V
Unlock warning switch ON, manual switch
OFF
4±6 V
±
STEERING STEERING COLUMNSR±49
WhereEverybodyKnowsYourName
Page 3072 of 4087

STANDARD VALUE OF ECU TERMINAL
Terminals
Symbols
Wiring
Color
Condition
Standard
Value
T9±17 eT9±5 Vc eE1 R±W eBR Unlock warning switch ON 4±6 V
T9±17eT9±5 VceE1 R±WeBR Unlock warning switch OFF Below 1 V
T9±18 ECU±B R Always 10 ~ 14 V
T10±1 e IGe B±R e Ignition switch ON 10 ~ 14 V
T10 1 e
Body Ground
IGe
Body Ground
BR e
Body Ground Ignition switch OFF Below 1 V
T10±2
e
Body Ground
Te M+e
Body Ground
L±B
e
Body Ground
Unlock warning switch ON, telescopic
forward
10 ~ 14 V
Body Ground Body Ground Body Ground Except above mention Below 1 V
T10±3
e TiM±e R±Le Unlock warning switch ON, tilt down 10 ~ 14 V
T10 3 e
Body Ground
TiMe
Body Ground
RLe
Body Ground Except above mention Below 1 V
T10±4 +B L±W Always 10 ~ 14 V
T10±6 e Pe GR e Ignition switch ON, shift lever ªPº position 10 ~ 14 V
T10 6 e
Body Ground
Pe
Body Ground
GR e
Body Ground Ignition switch ON, except above mention Below 1 V
T10±6 e Pe GR e Ignition switch ON, PKB lever pulled Below 1 V
T10 6 e
Body Ground
Pe
Body Ground
GR e
Body Ground Ignition switch ON, PKB lever released 10 ~ 14 V
T10±7 GND W±B Always Below 1 V
T10±10 e TiM+e R±Be Unlock warning switch ON, tilt up 10 ~ 14 V
T10 10 e
Body Ground
TiMe
Body Ground
RBe
Body Ground Except above mention Below 1 V
T10±11 e
Body Ground
Te M±e
Body Ground
L±Ye
Body Ground
Unlock warning switch ON, telescopic
backward 10 ~ 14 V
Body Ground Body Ground Body Ground Except above mention Below 1 V
TILT & TELESCOPIC ECU
