Page 449 of 4087

LEXUS SC400 1991 Service Repair Manual 2. INSTALL FENDER LINER(a) Install four clips so that the screw can be inserted in themanner shown in the drawing. (b) Install eight screws and the liner. 3. INSTALL FRONT FENDER WHEEL OPENING MO

Page 450 of 4087

LEXUS SC400 1991 Service Repair Manual EMBLEM COMPONENTS REMOVAL OF EMBLEM 1. REMOVE FRONT AND REAR BUMPER EMBLEM(a) Remove three nuts. (b) Using a scraper, pry out the plate. 2. REMOVE LUGGAGE COMPARTMENT DOOR NAME PLATE Using a scra

Page 451 of 4087

LEXUS SC400 1991 Service Repair Manual 3. REMOVE LUGGAGE COMPARTMENT DOOR EMBLEMUsing a scraper, pry out the plate. HINT: wTape the scraper tip before use. wTo avoid damaging the emblem, insert the scraper from various directions and gra

Page 452 of 4087

LEXUS SC400 1991 Service Repair Manual MOULDING Windshield Moulding COMPONENTS REMOVAL OF WINDSHIELD MOULDING Location of clips is as shown. Carefully apply adhesive tape to protect the body. 1. REMOVE FOLLOWING PARTS: (a) Wiper arm (b)

Page 453 of 4087

LEXUS SC400 1991 Service Repair Manual 3. REMOVE SIDE MOULDINGRemove four screws and the side moulding. 4. REMOVE UPPER MOULDING (a) I n s e r t t h e t o p o f s c r aper between the body and moulding. HINT: Tape the scraper tip befor

Page 454 of 4087

LEXUS SC400 1991 Service Repair Manual 3. INSTALL UPPER MOULDING(a) Place the moulding onto the body. (b) Tap the moulding with your hand to fasten the clips at the glass edge. At the same time, install the fastener by tapping the cli

Page 455 of 4087

LEXUS SC400 1991 Service Repair Manual Back Window Moulding COMPONENTS REMOVAL AND INSTALLATION OF BACK WINDOW LOWER MOULDING 1. REMOVE LOWER MOULDINGUsing the scraper, pry off the moulding from the six clips and remove the moulding. HIN

Page 456 of 4087

LEXUS SC400 1991 Service Repair Manual 3. INSTALL LOWER MOULDING(a) Place the moulding onto the body. (b) Tap the moulding by your hand to install the moulding. REMOVAL AND INSTALLATION OF BACK WINDOW OUTSIDE MOULDING 1. REMOVE BACK W
