Page 1209 of 4087

LEXUS SC400 1991 Service Repair Manual REAR FLOOR PAN (ASSY) REMOVAL (With the rear floor No. 3 crossmember removed.) BODY PANEL REPLACEMENTRE-52 WhereEverybodyKnowsYourName

Page 1210 of 4087

LEXUS SC400 1991 Service Repair Manual INSTALLATION BODY PANEL REPLACEMENTRE-53 WhereEverybodyKnowsYourName

Page 1211 of 4087

LEXUS SC400 1991 Service Repair Manual REAR FLOOR REAR SIDE MEMBER (ASSY) REMOVAL (With the rear floor No. 3 crossmember removed.) 1. Replace the rear floor pan to quarter panelextension at the same time. BODY PANEL REPLACEMENTRE-54 Wher

Page 1212 of 4087

LEXUS SC400 1991 Service Repair Manual INSTALLATION Assembly Mark 1. When temporarily installing the new parts,determine the installation position by the assembly mark. Then, measure each part in accordance with the body dimension dia- gr

Page 1213 of 4087

LEXUS SC400 1991 Service Repair Manual REAR FLOOR NO. 1 CROSSMEMBER (ASSY), REAR FLOOR NO. 2 CROSSMEMBER (ASSY) REMOVAL (With the rear floor pan removed.) 1. After removing the rear floor No. 1 cross-member, disconnect the welding between

Page 1214 of 4087

LEXUS SC400 1991 Service Repair Manual INSTALLATION 2. After welding the rear floor No. 2 cross-member, install the rear floor No. 1 cross- member. 1. Temporarily install the new parts and mea- sure each part in accordance with the body d

Page 1215 of 4087

LEXUS SC400 1991 Service Repair Manual Manual NamePub. No.  SC400 Repair Manual  SC400 Electrical Wiring Diagrars Manual  Fundamental Painting Procedures  Fundamental Body Repair Procedures BRM019U BRM020U M/Y Version M/Y Version FOR

Page 1216 of 4087

LEXUS SC400 1991 Service Repair Manual mm in.1 1.5 3.5 4 4.8 5 5.5 6 0.04 0.06 0.14 0.16 0.19 0.20 0.22 0.24 FIT STANDARDS After doors and the engine hood are installed, be sure to perform flit a\ djustment to prevent abnormal wind noise
