1991 LEXUS SC400 set clock

When the negative (±) terminal cable is disconnected from
the battery, memory of the clock and audio systems will be
cancelled. So before starting work, make a record of the con-
tents memorized by each memory system. Then when work
is finished, reset the clock and audio systems as before.
When the vehicle has power tilt and power telescopic steer-
ing, power seat, power outside rear view mirror and power
shoulder belt anchorage, which are all equipped with
memory function, it is not possible to make a record of the
memory contents. So when the operation is finished, it will be
necessary to explain this fact to the customer, and ask the
customer to adjust the features and reset the memory.
To avoid erasing the memory of each memory system, never
use a back±up power supply from outside the vehicle.
3. Even in cases of a minor collision where the airbag does not deploy, the front airbag sensors and the steering wheel pad
should be inspected. (See page AB±9)
4. Never use airbag parts from another vehicle. When replacing parts, replace them with new parts.
5. Before repairs, remove the airbag sensors if shocks are likely
to be applied to the sensors during repairs.
6. The center airbag sensor assembly contains mercury. After
performing replacement, do not destroy the old part. When
scrapping the vehicle or replacing the center airbag sensor
assembly itself, remove the center airbag sensor assembly
and dispose of it as toxic waste.
7. Never disassemble and repair the front airbag sensors, center airbag sensor assembly or steering wheel pad in order
to reuse it.
8. If the front airbag sensors, center airbag sensor assembly or steering wheel pad have been dropped, or if there are cracks,
dents or other defects in the case, bracket or connector,
replace them with new ones.
9. Do not expose the front airbag sensors, center airbag sensor assembly or steering wheel pad directly to hot air or flames.
10. U s e a v o l t / o h m m e t e r w i t h h i g h i m pedance (10 kW/V
minimum) for troubleshooting of the electrical circuit.
11. Information labels are attached to the periphery of the airbag components. Follow the notices.
12. After work on the airbag system is completed, perform the
airbag warning light check (See page AB±30).
±
INTRODUCTION Precautions for Vehicles Equipped with SRS AirbagIN±9
WhereEverybodyKnowsYourName

GENERAL DESCRIPTION
The LEXUS SC400 is equipped with an SRS (Supplemental Restraint System) a\
irbag.
Failure to carry out service operations in the correct sequence could cause the\
airbag system to unex-
pectedly deploy during servicing, possibly leading to a serious accident.
Further, if a mistake is made in servicing the airbag system, it is possible the\
airbag may fail to operate
when required.
Before performing servicing (including removal or installation of parts, insp\
ection or replacement), be
sure to read the following items carefully, then follow the correct procedure described in the repair
manual.
1. Malfunction symptoms of the airbag system are difficult to confirm, so the diagnostic codes become themost important source of information when troubleshooting.
When troubleshooting the airbag system, always inspect the diagnostic co\
des before disconnecting the
battery (See page AB±25).
2. Work must be started after approx. 20 seconds or longer from the time the ig\
nition switch is turned to the LOCK position and the negative (±) terminal cable is disconnec\
ted from the battery. (The
airbag system is equipped with a back±up power source so that if work is sta\
rted within 20 seconds
of disconnecting the negative (±) terminal cable of the battery, the airbag may be deployed.)
When the negative (±) terminal cable is disconnected from the battery, memory of the clock and audio sys-
tems will be cancelled. So before starting work, make a record of the conten\
ts memorized by the audio
memory system. Then when work is finished, reset the audio systems as before a\
nd adjust the clock. When
the vehicle has power tilt and power telescopic steering, power seat, power \
outside rear view mirror and
power shoulder belt anchorage, which are all equipped with memory function, it\
is not possible to make
a record of the memory contents. So when the work is finished, it will be\
necessary to explain this fact to
the customer, and ask the customer to adjust the features and reset the memory. To avoid erasing the
memory of each memory system, never use a back±up power supply from outside\
the vehicle.
3. Even in cases of a minor collision where the airbag does not deploy, the front airbag sensors and
the steering wheel pad should be inspected (See page AB±9).
4. Never use airbag parts from another vehicle. When replacing parts, replace them with new parts.
5. Before repairs, remove the airbag sensors if shocks are likely to be applied to the sensors during repairs.
6. Never disassemble and repair the front airbag sensors, center airbag sensor a\
ssembly or steering
wheel pad in order to reuse it.
7. If the front airbag sensors, center airbag assembly or steering wheel pa\
d have been dropped, or if there are cracks, dents or other defects in the case, bracket or conn\
ector, replace them with new
ones.
8. Do not expose the front airbag sensors, center airbag sensor assembly or\
steering wheel pad directly to hot air or flames.
9. Use a volt/ohmmeter with high impedance (10 kW/V minimum) for troubleshoo\
ting of the electrical circuit.
10. Information labels are attached to the periphery of the airbag components. Follow t\
he instructions
on the notices.
11. After work on the airbag system is completed, perform the airbag warning\
light check (See page AB±30 ).
AB±2
SRS AIRBAG
± General Description
WhereEverybodyKnowsYourName

(e) Pull the wheel pad out from the steering wheel anddisconnect the airbag connector.
NOTICE: When removing the wheel pad, take care not to
pull the airbag wire harness.
CAUTION:
wWhen storing the wheel pad, keep the upper surface of
the pad facing upward (See pages AB±3, 4).
wNever disassemble the wheel pad.
2. REMOVE STEERING WHEEL
(a) Disconnect the connector.
(b) Remove the set nut.
(c) Place matchmarks on the steering wheel and mainshaft.
(d) Using SST, remove the steering wheel.
SST 09213±31021
3. REMOVE AND INSTALL SPIRAL CABLE FROM/TO COMBINATION SWITCH (See page BE±41)
NOTICE: Do not disassemble the spiral cable or apply oil
to it.
4. CENTER SPIRAL CABLE (a) Check that the front wheels are facing straight ahead.
(b) Turn the spiral cable counterclockwise by hand until it
becomes harder to turn the cable.
(c) Then rotate the spiral cable clockwise about 3 turns to align the red mark.
HINT: The spiral cable will rotate about 3 turns to either left
or right of the center.
5. INSTALL STEERING WHEEL (a) Align matchmarks on the steering wheel and main shaft,
and install the steering wheel to the main shaft.
(b) Install and torque the set nut.
Torque: 35 N Vm (360 kgf Vcm, 26 ft Vlbf)
(c) Connect the connector.
6. INSTALL STEERING WHEEL PAD (a) Connect the airbag connector.
(b) I n s t a l l t h e w heel pad after confirming that the
circumference groove of the torx screws is caught on the
screw case.
(c) Using a torx wrench, tighten the four screws.
Torque: 7.4 N Vm (75 kgf Vcm, 65 in. Vlbf)
NOTICE:
wMake sure the wheel pad is installed to the specified
torque.
wIf the wheel pad has been dropped, or there are cracks,
dents or other defects in the case or connector, replace
the wheel pad with a new one.
wWhen installing the wheel pad, take care that the wirings
do not interfere with other parts and are not pinched
between other parts.
7. CHECK STEERING WHEEL CENTER POINT AB±15
SRS AIRBAG
± Removal and Installation of Component Parts
WhereEverybodyKnowsYourName

TORQUE CONVERTER CLUTCH
CLEANING
AT079±04
If the transmission is contaminated, the torque converter
clutch and transmission cooler should be thoroughly flushed
with ATF.
TORQUE CONVERTER CLUTCH AND
DRIVE PLATE INSPECTION
AT00J±01
1. INSPECT ONE±WAY CLUTCH
(a) Install SST so that it fits in the notch of the converter hub and
outer race of the one±way clutch.
SST 09350±30020 (09350±32020)
(b) Press on the serrations of starter with a finger and rotate it. Check if it rotates smoothly when turned clockwise and locks
up when turned counterclockwise.
2. MEASURE DRIVE PLATE RUNOUT AND INSPECT RING GEAR
Set up a dial indicator and measure the drive plate runout.
If runout exceeds 0.20 mm (0.0079 in.) or if the ring gear is
damaged, replace the drive plate. If installing a new drive
plate, note the orientation of spacers and tighten the bolts.
Torque: 98 N Vm (1,000 kgf Vcm, 72 ft Vlbf)
±
A304E (1UZ±FE) AUTOMATIC TRANSMISSION ASSEMBLY REMOVAL AND INSTALLATIONAT±25
WhereEverybodyKnowsYourName

5. REMOVE COMBINATION SWITCH ASSEMBLY(a) Remove four screws.
(b) Disconnect connectors.
(See page BE±41)
HINT: Since the airbag connector has a 2±stage lock, remove
the 1st stage lock, and disconnect the connector.
(c) Remove combination switch assembly from steering column.
HINT: Pull the wire harness spool body to forward and re-
move wire harness spool body from steering column.
INSPECTION OF COMBINATION SWITCH
For installation, follow the removal procedure in reverse.
(MAIN POINT OF INSTALLATION)
1. ADJUSTMENT OF SPIRAL CABLE (a) Check that the front wheels are facing straight ahead.
(b) Turn the spiral cable counterclockwise by hand until itbecomes harder to turn the cable.
(c) Then rotate the spiral cable clockwise about 3 turns to align the red mark.
HINT:
w The spiral cable will rotate about 3 turns to either left or
right of the center.
w The connector should be straight up.
(d) Install the steering wheel so that the match marks will not be misaligned.
2. INSTALL STEERING SET NUT
Torque: 35 N Vm (360 kgf Vcm, 26 ft Vlbf)
3. INSTALL STEERING WHEEL CENTER PAD
Torque the torx screws.
Torque: 7.1 N Vm (75 kgf Vcm, 62 in.lbf) V
BE±40±
BODY ELECTRICAL SYSTEM Lighting System
WhereEverybodyKnowsYourName

MASTER CYLINDER ASSEMBLY
BR0EH±05
1. APPLY LITHIUM SOAP BASE GLYCOL GREASE TORUBBER PARTS INDICATED BY ARROWS
2. INSTALL PISTONS
NOTICE: Be careful not to damage the rubber lips on the pis-
tons.
(a) Insert the 2 pistons straight in, not at an angle.
NOTICE: If inserted at an angle, there is a possibility that the
cylinder bore could be damaged.
(b) Push in the piston with a screwdriver and install the snap ring
with snap ring pliers.
HINT: Tape the screwdriver tip before use.
3. w/ TRAC: INSTALL NO. 1 PISTON STOPPER BOLT
Using a screwdriver, push the piston in all the way and install
the No. 1 piston stopper bolt over a new gasket.
Torque: 10 N Vm (100 kgf Vcm, 7 ft Vlbf)
4. INSTALL NO. 2 PISTON STOPPER BOLT
Using a screwdriver, push the piston in all the way and install
the No. 2 piston stopper bolt over a new gasket.
Torque: 10 N Vm (100 kgf Vcm, 7 ft Vlbf)
5. INSTALL 2 GROMMETS
6. INSTALL RESERVOIR
(a) Install the strainer to the reservoir.
(b) Push the reservoir onto the cylinder.
(c) Install the set screw while pushing on the reservoir.
Torque: 1.7 N Vm (17.5 kgf Vcm, 15.2 in. Vlbf)
7. INSTALL RESERVOIR CAP
(a) Align the matchmark on the reservoir cap with the matchmark
on the ªopenº side of reservoir.
(b) Push down on the reservoir cap and turn it clockwise until it locks.
(c) Check that the matchmark on the reservoir cap is now aligned with the matchmark on the ªcloseº side of the
reservoir.
BR±16
±
BRAKE SYSTEM MASTER CYLINDER
WhereEverybodyKnowsYourName

Steering Wheel Pad (Airbag and Inflator)
Junction Block No. 1 Center Airbag
Front Airbag Sensor
Front Airbag Sensor
Warning Light Spiral Cable (in Combination Switch)
HANDLING PRECAUTIONS ON RELATED COMPONENTS
1. SRS AIRBAG
Locations of Airbag Components
This vehicle has an SRS AIRBAG (referred to as the airbag in the remain\
der of this manual).
When handling airbag components (removal, installation or inspection, e\
tc.), always follow the directions
given in the repair manual for the relevant model year to prevent the oc\
currence of accidents and airbag
malfunction.
Also take the following precautions when repairing the body:

Work must be started after 20 seconds or longer from the time the ignitio\
n switch is set to the LOCK
position and the negative (-) terminal cable is disconnected from the \
battery.
(The airbag system is equipped with a back-up power source so that if w\
ork is started within 20 seconds
of disconnecting the negative (-) terminal cable of the battery, the airbag may be deployed.)
When the negative (-) terminal cable is disconnected from the battery, memory of the clock and audio
systems will be cancelled. So before starting work, make a record of the\
contents memorized by each
memory system. Then when work is finished, reset the clock and audio sys\
tems as before.
When the vehicle has tilt and telescopic steering, power seat, and outsi\
de rear view mirror, which are all
equipped with memory function, it is not possible to make a record of th\
e memory contents.
So when the operation is finished, it will be necessary to explain this \
fact to the customer, and request
the customer to adjust the features and reset the memory.
To avoid erasing the memory of each memory system, never use back-up powe\
r supply from outside
the vehicle.

When using electric welding, first disconnect the airbag connector (yel\
low color and 2 pins) under the
steering column near the combination switch connector before starting wo\
rk.
Sensor Assembly
INTRODUCTIONIN-6
WhereEverybodyKnowsYourName

Fuel Pump ECUAuto Antenna Motor and Relay
Power Seat ECU
(For Passenger's Seat)
Power Seat ECU
(For Driver's Seat) CD Automatic Changer
Wireless Door Lock ECU
Moon Roof Control Relay
Locations of ECUs (Cont'd)
Many ECUs are mounted in this vehicle.
Take the following precautions during body repair to prevent damage to th\
e ECUs.


Before starting electric welding operations, disconnect the negative (-\
) terminal cable from the battery.
When the negative (-) terminal cable is disconnected from the battery, memory of the clock and audio
systems will be cancelled. So before starting work, make a record of the\
contents memorized by each
memory system. Then when work is finished, reset the clock and audio sys\
tems as before.
When the vehicle has tilt and telescopic steering, power seat and outsid\
e rear view mirror, which are all
equipped with memory function, it is not possible to make a record of th\
e memory contents.
So when the operation is finished, it will be necessary to explain this \
fact to the customer, and request
the customer to adjust the features and reset the memory.

Do not expose the ECUs to ambient temperatures above 80 °C (176 °F).
NOTICE: If it is possible the ambient temperature may reach 80°C (176°F) or, more, remove the ECUs
from the vehicle before starting work.

Be careful not to drop the ECUs and not to apply physical shocks to them\
.
5. COMPONENTS ADJACENT TO THE BODY PANELS
Various types of component parts are mounted directly on or adjacently to\
the body panels.
Strictly observe the following precautions to prevent damaging these com\
ponents and the body panels
during handling.

Before repairing the body panels, remove their adjacent components or ap\
ply protective covers over
the components.

Before prying components off using a screwdriver or a scraper, etc., attach protective tape to the tool
tip or blade to prevent damaging the components and the body paint.

Before removing components from the outer surface of the body, attach protective tape to the body to
ensure no damage to painted areas.
HINT: Apply touch-up paint to any damaged paint surfaces.

Before drilling or cutting sections, make sure that there are no wires, \
hoses, etc., on the reverse side.
INTRODUCTIONIN-9
WhereEverybodyKnowsYourName
