WITH THE IGNITION SW TURNED ON, THE CURRENT FLOWS TO TERMINAL (A)14 OF THE WIPER AND WASHER SW, TERMINAL 2 OF
THE WASHER MOTOR AND TERMINAL 6 OF THE WIPER MOTOR THROUGH THE WIPER FUSE.
1. LOW

203
WITH THE IGNITION SW TURNED ON, THE CURRENT FLOWS TO TERMINAL (A)14 OF THE WIPER AND WASHER SW, TERMINAL 2 OF
THE WASHER MOTOR AND TERMINAL 6 OF THE WIPER MOTOR THROUGH THE WIPER FUSE.
1. LOW SPEED POSITION
WITH WIPER SW TURNED TO LOW POSITION, THE CURRENT FLOWS FROM TERMINAL (A)14 OF THE WIPER AND WASHER SW "
TERMINAL (B)8 " TERMINAL 3 OF THE WIPER MOTOR " TERMINAL 1 " TO GROUND AND CAUSES TO THE WIPER MOTOR TO RUN
AT LOW SPEED.
2. HIGH SPEED POSITION
WITH WIPER SW TURNED TO HIGH POSITION, THE CURRENT FLOWS FROM TERMINAL (A)14 OF THE WIPER AND WASHER SW "
TERMINAL (A)7 " TERMINAL 2 OF THE WIPER MOTOR " TERMINAL 1 " TO GROUND AND CAUSES TO THE WIPER MOTOR TO RUN
AT HIGH SPEED.
3. INT POSITION
WITH WIPER SW TURNED TO INT POSITION, THE RELAY OPERATES AND THE CURRENT WHICH IS CONNECTED BY RELAY
FUNCTION FLOWS FROM TERMINAL (A)14 OF THE WIPER AND WASHER SW " TERMINAL (A)6 " TO GROUND . THIS FLOW OF
CURRENT OPERATES THE INTERMITTENT CIRCUIT AND THE CURRENT FLOWS FROM TERMINAL (A)14 OF THE WIPER AND
WASHER SW " TERMINAL (B)8 " TERMINAL 3 OF THE WIPER MOTOR " TERMINAL 1 " TO GROUND AND FUNCTIONS.
THE INTERMITTENT OPERATION IS CONTROLLED BY A CONDENSER'S CHARGED AND DISCHARGED FUNCTION INST\
ALLED IN
RELAY AND THE INTERMITTENT TIME IS CONTROLLED BY A TIME CONTROL SW TO CHARGE THE CHARGING TIME OF THE
CONDENSER.
4. MIST POSITION
WITH WIPER SW TURNED TO MIST POSITION, THE CURRENT FLOWS FROM TERMINAL (A)14 OF THE WIPER AND WASHER SW "
TERMINAL (B)8 " TERMINAL 3 OF THE WIPER MOTOR " TERMINAL 1 " TO GROUND AND CAUSES TO THE WIPER MOTOR TO RUN
AT LOW SPEED.
5. WASHER CONTINUOUS OPERATION
WITH WASHER SW TURNED TO ON, THE CURRENT FLOWS FROM TERMINAL 2 OF THE WASHER MOTOR " TERMINAL 1 "
TERMINAL (A)13 OF THE WIPER AND WASHER SW " TERMINAL (A)6 " TO GROUND AND CAUSES TO THE WASHER MOTOR TO
RUN. AND WINDOW WASHER IS JET. THIS CAUSES THE CURRENT TO FLOW WASHER CONTINUOUS OPERATION CIRCUIT IN
TERMINAL (A)14 OF THE WIPER AND WASHER SW " TERMINAL (B)8 " TERMINAL 3 OF THE WIPER MOTOR " TERMINAL 1 TO
GROUND AND FUNCTION.
C15(B), C16(A) WIPER AND WASHER SW [COMB. SW]
(A) 6±GROUND : ALWAYS CONTINUITY
(A) 14±GROUND : APPROX. 12 VOLTS WITH IGNITION SW AT ON POSITION
(B) 8±GROUND : APPROX. 12 VOLTS WITH WIPER AND WASHER SW AT LOW OR MIST POSITION
APPROX. 12 VOLTS EVERY APPROX. 1 TO 10 SECONDS INTERMITTENTLY WITH WIPER SW AT INT POSITION
(B) 17±GROUND : APPROX. 12 VOLTS WITH IGNITION SW ON UNLESS WIPER MOTOR AT STOP POSITION
(A) 7±GROUND : APPROX. 12 VOLTS WITH IGNITION SW ON AND AFTER WIPER SW OFF UNTIL WIPER MOTOR STOPS
W 5 WIPER MOTOR
6±5 : CLOSED UNLESS WIPER MOTOR AT STOP POSITION
SYSTEM OUTLINE
SERVICE HINTS
WhereEverybodyKnowsYourName

Page 3826 of 4087

LEXUS SC400 1991 Service Repair Manual
15
ABBREVIATIONS
DISCONNECTION AND CONNECTION OF BOLT
TYPE CONNECTORS
For engine and ECT ECU in this vehicle, connectors are used
which require a bolt built into the connector to be screwed down to
s

Page 3827 of 4087

LEXUS SC400 1991 Service Repair Manual
143
ABS (ANTI±LOCK BRAKE SYSTEM)
