Page 417 of 4087

LEXUS SC400 1991 Service Repair Manual BO6562 1. REMOVE SEAT GARNISH(a) Using a screwdriver, pull out the snap ring and removethe handle. (b) Using a screwdriver, remove two switch knobs. HINT: Tape the screwdriver tip before use. (c)

Page 418 of 4087

LEXUS SC400 1991 Service Repair Manual 4. REMOVE SEAT CUSHION ASSEMBLY(a) Remove four bolts. (b) Disconnect the connectors. (c) Remove the seat cushion assembly. 5. REMOVE FRONT SEAT INNER BELT 6. REMOVE SEAT BACK COVER (a) Remove

Page 419 of 4087

LEXUS SC400 1991 Service Repair Manual 9. REMOVE SEAT CUSHION COVERPeel the seat cushion cover away from around the edge of the seat cushion. DISASSEMBLY OF POWER SEAT REGULATOR 1. REMOVE FRONT AND REAR VERTICAL MOTORRemove eight screws

Page 420 of 4087

LEXUS SC400 1991 Service Repair Manual 2. REMOVE FRONT SEAT LINK WITH FRONT VERTICAL(a) Remove two screws and the screw support bushing. (b) Remove four nuts and the link. 3. REMOVE SLIDE MOTOR (a) Remove two screws and the motor. (b

Page 421 of 4087

LEXUS SC400 1991 Service Repair Manual ASSEMBLY OF FRONT SEAT (See page BO±63) ASSEMBLE FRONT SEAT PARTS BY FOLLOWING DIS- ASSEMBLY SEQUENCE IN REVERSE HINT: wUsing hog ring pliers, install the new hog ring. wBefore installing the reclin

Page 422 of 4087

LEXUS SC400 1991 Service Repair Manual Rear Seat REMOVAL OF REAR SEAT 1. REMOVE REAR SEAT CUSHIONPull up the seat cushion to remove it. 2. REMOVE REAR SEAT BACK (a) Remove three bolts. (b) Pull up the seat back to remove it. BO±66 ±

Page 423 of 4087

LEXUS SC400 1991 Service Repair Manual INSTALLATION OF REAR SEAT (See page BO±66) 1. INSTALL REAR SEAT BACK Push down the rear seat back and install three bolts. Torque: 18 N Vm (185 kgf Vcm, 13 ft Vlbf) 2. INSTALL REAR SEAT CUSHION (a

Page 424 of 4087

LEXUS SC400 1991 Service Repair Manual DISASSEMBLY OF REAR SEAT 1. REMOVE SEAT CUSHION COVERRemove hog rings and the cover. 2. REMOVE SEAT BACK COVER Remove hog rings and the cover. BO±68 ± BODY Seat (Rear Seat) WhereEverybodyKnowsYo
