Page 3225 of 4087
(b) Remove following parts from the differential case.wPinion shaft
w 2 differential pinions
w 2 pinion thrust washers
w 2 side gears
w 2 side gears thrust washers
DUST DEFLECTOR AND DUST COVER
REPLACEMENT
SA0V5±01
1. REPLACE COMPANION FLANGE DUST DEFLECTOR
(a) Using SST and a press, remove the dust deflector.
SST 09608±35014 (09608±06090), 09950±00020
(b) Using SST and a press, install a new dust deflector. SST 09316±60010 (09316±00010)
2. REPLACE SIDE GEAR SHAFT DUST COVER
(a) Using SST and a press, remove the dust cover. SST 09950±00020
(b) Using SST and a press, install a new dust cover. SST 09502±24010, 09608±35014 (09608±06020,09608±06120)
SA±92
±
SUSPENSION AND AXLE REAR DIFFERENTIAL
WhereEverybodyKnowsYourName
Page 3226 of 4087

HINT: If the dust cover does not fit tightly against the flange
of the side gear shaft, use a screwdriver to drive it down tight.
DIFFERENTIAL CARRIER ASSEMBLY
SA0V6±04
1. ADJUST DIFFERENTIAL PINION GEAR BACKLASH
(a) Install the proper thrust washers on the side gears.HINT: Using the table below, select thrust washers which will
ensure that the backlash is within specification.
Thrust washer thickness:
Thickness mm (in.) Thickness mm (in.)
1.6 (0.063)1.8 (0.071)
1.7 (0.067)±
(b) Install the side gears, pinion gears, pinion gear thrust
washers and pinion shaft in the differential case.
HINT: Align the holes of the dif ferential case and pinion shaft.
(c) Push the side gear shafts gently into the differential case by hand and install them.
(d) Measure the pinion gear backlash while holding one side gear toward the case.
Backlash:
0.05±0.20 mm (0.0020±0.0079 in.)
If the backlash is not within the specification, install the side
gear thrust washers with different thicknesses.
(e) Remove the side gear shaft.
2. INSTALL RING GEAR ON DIFFERENTIAL CASE
(a) Using a hammer and punch, install the straight pin through the differential case and hole of the pinion shaft.
±
SUSPENSION AND AXLE REAR DIFFERENTIALSA±93
WhereEverybodyKnowsYourName
Page 3227 of 4087

(b) Stake the differential case.
3. INSTALL RING GEAR ON DIFFERENTIAL CASE
(a) Clean the contact surfaces of the differential case and thethreads of the ring gear and differential case.
(b) Heat the ring gear in boiling water.
(c) A f t e r t h e m o i s t u r e o n t h e r i n g g e a r h a s c o m p l e t e l y evaporated, quickly install the ring gear to the differential
case.
HINT: Align the matchmarks on the ring gear and the dif feren-
tial case.
(d) Tighten 2 of the bolts temporarily so that the bolt holes in the ring gear and differential case are not misaligned.
NOTICE: The ring gear set bolts should not be tightened until
the ring gear has cooled sufficiently.
4. INSTALL RING GEAR SET BOLTS
(a) After the ring gear has cooled sufficiently, install 10 new ringgear set bolts to which thread lock has been applied.
Thread lock:
Part No. 08833±00100, THREE BOND 1360 K or
equivalent.
NOTICE: New ring gear set bolts should be used in every case.
(b) Torque the 10 set bolts uniformly and a little at a time.
Torque: 64 N Vm (650 kgf Vcm, 47 ft Vlbf)
(c) Tighten the bolts an additional 60±90 .
NOTICE: Tighten the bolts in diagonally opposite pairs.
SA±94±
SUSPENSION AND AXLE REAR DIFFERENTIAL
WhereEverybodyKnowsYourName
Page 3228 of 4087

5. INSTALL SIDE BEARINGSUsing SST and a press, install the side bearings.
SST 09550±10012 (09252±10010, 09558±10010)09710±30050
6. INSTALL DRIVE PINION BEARING OUTER RACES AND ADJUSTING WASHER
HINT: The adjusting washer is used for adjusting the tooth
contact pattern. 42 types of washer with differential thick-
nesses are available.
First fit a washer with the same thickness as the washer
which was removed, then after checking the tooth contact
pattern, replace the washer with one of a different thickness
if necessary.
When removing an adjusting washer, be sure to replace it
with a new one.
(a) Using SST and a press, install a new adjusting washer and the front bearing outer race.
SST 09250±10011 (09252±10010, 09255±10011)
(b) Using SST and a press, install the rear bearing outer race. SST 09608±30012 (09608±04020, 09608±04100)
7. INSTALL REAR BEARING TO DRIVE PINION Using SST and a press, install the rear bearing.
SST 09502±24010
±
SUSPENSION AND AXLE REAR DIFFERENTIALSA±95
WhereEverybodyKnowsYourName
Page 3229 of 4087

8. INSTALL DRIVE PINION AND FRONT BEARING
(a) Install the drive pinion in the differential carrier.
(b) Using SST and a press, install the front bearing on the drivepinion.
SST 09316±60010 (09316±00010), 09608±30012
(09608±04030)
HINT: Assemble the spacer and oil seal after adjusting the
tooth contact pattern.
9. INSTALL OIL SLINGER AND COMPANION FLANGE
(a) Install the oil slinger.
(b) Using SST and a press, install the companion flange. SST 09223±63010, 09325±40010
10. TEMPORARILY ADJUST DRIVE PINION PRELOAD
(a) Adjust the drive pinion preload by tightening the companion flange nut.
HINT: Using SST to hold the flange, tighten the nut.
SST 09229±55010, 09330±00021
NOTICE: As there is no spacer, tighten the nut a little at a time,
being careful not to overtighten it.
(b) Using SST and a torque wrench, measure the drive pinion preload.
SST 09229±55010
Preload (at start):
New bearing:
1.2±1.8 N Vm (12.4±18.4 kgf Vcm, 10.8±16.0 in. Vlbf)
Reused bearing
0.5±0.8 N Vm (5±8 kgf Vcm, 4.3±6.9 in. Vlbf)
SA±96±
SUSPENSION AND AXLE REAR DIFFERENTIAL
WhereEverybodyKnowsYourName
Page 3230 of 4087
HINT: For vehicle which have run 8,000 km (5,000 miles) or
less, if the preload value measured disassembly is greater
than the specification for a reused bearing, return the preload
to the same as before disassembly.
11. INSTALL SIDE BEARING OUTER RACE AND ADJUST WASHER
Using SST and a press, press the outer race and washer.
SST 09608±35014 (09608±06020, 09608±06210)
12. INSTALL DIFFERENTIAL CASE IN CARRIER Install the drive side bearing in the differential carrier first, as
shown in the illustration, then install the differential case.
13. INSTALL DIFFERENTIAL CARRIER RETAINERS
(a) Using SST and hammer, install the bearing retainer. SST 09608±35014 (09608±06020, 09608±06180)
±
SUSPENSION AND AXLE REAR DIFFERENTIALSA±97
WhereEverybodyKnowsYourName
Page 3231 of 4087

(b) Tighten the 8 bolts.
Torque: 22 NVm (225 kgf Vcm, 16 ft Vlbf)
14. CHECK RING GEAR BACKLASH
Using dial gauge, measure the backlash of the ring gear at
3 positions at least.
Backlash (average value):
0.08±0.13 mm (0.0031±0.0051 in.)
NOTICE: The difference between the maximum and minimum
measured values must be less than 0.05 mm (0.0020 in.)
HINT: The measured values should be used for reference
when selecting washers, so make a memo of the values.
If the backlash is not within the specification replace the
washer on the ring gear side with one of a different thickness
using the following procedure.
Adjusting washer thickness: mm (in.)
No. Thickness No. Thickness No. Thickness 02 2.02 (0.0795) 32 2.32 (0.0913) 62 2.62 (0.1031) 04 2.04 (0.0803) 34 2.34 (0.0921) 64 2.64 (0.1039)
06 2.06 (0.0811) 36 2.36 (0.0929) 66 2.66 (0.1047)
08 2.08 (0.0819) 38 2.38 (0.0937) 68 2.68 (0.1055)
10 2.10 (0.0827) 40 2.40 (0.0945) 70 2.70 (0.1063)
12 2.12 (0.0835) 42 2.42 (0.0953) 72 2.72 (0.1071)
14 2.14 (0.0843) 44 2.44 (0.0961) 74 2.74 (0.1079)
16 2.16 (0.0850) 46 2.46 (0.0969) 76 2.76 (0.1087)
182.18 (0.0858)482.48 (0.0976)782.78 (0.1094) 20 2.20 (0.0866) 50 2.50 (0.0984) 80 2.80 (0.1102) 22 2.22 (0.0974) 52 2.52 (0.0992) 82 2.82 (0.1110) 24 2.24 (0.0882) 54 2.54 (0.1000) 84 2.84 (0.1118) 26 2.26 (0.0890) 56 2.56 (0.1008) 86 2.86 (0.1126)
28 2.28 (0.0898) 58 2.58 (0.1016)
30 2.30 (0.0906) 60 2.60 (0.1024)
15. MEASURE TOTAL PRELOAD
Using SST and a torque wrench, measure the total preload.
SST 09229±55010
Total preload
In addition to drive pinion preload
0.5±0.8 N Vm (5±8 kgf Vcm, 4.3±6.9 in. Vlbf)
SA±98±
SUSPENSION AND AXLE REAR DIFFERENTIAL
WhereEverybodyKnowsYourName
Page 3232 of 4087

If the measure preload is less than specification, replace the
washer of the ring gear's tooth surface side with a thicker
one.
If the preload is greater than the specification, replace the
washer of the ring gear's tooth surface side with thinner one.
HINT: Changing the snap ring thickness by 0.02 mm (0.0008
in.) will change the total preload by approx. 0.1 N Vm (1 kgf Vcm,
0.9 in. Vlbf)
16. INSPECT TOOTH CONTACT PATTERN
(a) Coat 3 or 4 teeth at three different position on the ring gear with red lead.
(b) Hold the companion flange firmly and rotate the ring gear in both directions.
(c) Inspect the tooth contact pattern.
If tooth contact pattern is not correct, replace the adjusting
washer installed on the front of the drive pinion rear bearing
to adjust it.
NOTICE: Be sure to always use a new part when replacing ad-
justing washer.
HINT: Refer to the table below for selection of the adjusting
washer.
±
