15. DISCONNECT HOSESDisconnect the following hoses:(1) Water by±pass hose (from water inlet housing) from ISC valve
(2) Vacuum hose (from PS air control valve) from air in-
take chamber
(3) Vacuum sensing hose (from fuel pressure regula- tor) from vacuum pipe
(4) Two vacuum hoses (from VSV for EVAP system) from vacuum pipe
(5) Vacuum hose (from charcoal canister) from vacu- um pipe.
(6) Water by±pass hose (from EGR valve) from water by±pass pipe
(7) Vacuum hose (from brake booster) from air intake chamber
(8) Vacuum hose (from VSV for heater water valve)
from air intake chamber
(9) PCV hose from LH cylinder head cover
16. REMOVE AIR INTAKE CHAMBER (a) Remove the bolt, stud bolt and accelerator bracket.
ST±10
±
STARTING SYSTEM Starter
WhereEverybodyKnowsYourName
Page 2586 of 4087
(b) Remove the union bolt and two gaskets, and disconnectthe cold start injector tube from the RH delivery pipe.
(c) Remove the two bolts and gasket, and disconnect the EGR pipe from the air intake chamber.
(d) Remove the four bolts, eight nuts and A/T throttle cable bracket.
(e) (USA Spec.)
Disconnect the check (ºDIAGNOSISº) connector brack-
et from the air intake chamber.
(f) (Exc. USA Spec.) Remove the connector bracket from the check
(ºDIAGNOSISº) connector.
(g) Remove the air intake chamber assembly and four gaskets.
17. DISCONNECT FUEL INLET HOSE FROM LH DELIVERY PIPE
Remove the pulsation damper and two gaskets, and discon-
nect the inlet hose.
18. D I S C O N N E C T F U E L R E T U R N H O S E F R O M F U E L RETURN PIPE
±
STARTING SYSTEM StarterST±11
WhereEverybodyKnowsYourName
Page 2587 of 4087
19. DISCONNECT EGR PIPE FROM RH CYLINDER HEADRemove the bolt holding the EGR pipe to the cylinder head,
and disconnect the EGR pipe.
20. DISCONNECT ENGINE WIRE FROM INTAKE MANIFOLD Remove the two bolts, and disconnect the engine wire.
21. DISCONNECT ENGINE WIRE FROM DELIVERY PIPES, REAR WATER BY±PASS JOINT AND RH CYLINDER
HEAD
(a) Remove the four bolts holding the engine wire to thedelivery pipes, and disconnect the engine wire from the
delivery pipe.
(b) Remove the two bolts holding the engine wire to the rear
water by±pass joint, and disconnect the engine wire
from the rear water by±pass joint.
(c) Remove the two bolts holding the engine wire to the rear
side of the RH cylinder head, and disconnect the engine
wire from the RH cylinder head.
(d) Disconnect the two engine wire connectors from the connector bracket on the front side of the LH delivery
pipe.
(e) Disconnect the eight injector connectors.
ST±12
±
STARTING SYSTEM Starter
WhereEverybodyKnowsYourName
Page 2588 of 4087
22. REMOVE FUEL RETURN PIPE(a) Remove the bolt holding the return pipe to the LHcylinder head.
(b) Remove the union bolt, two gaskets and return pipe.
23. REMOVE DELIVERY PIPES AND INTAKE MANIFOLD ASSEMBLY
(a) Remove the six bolts and four nuts holding the intakemanifold to the cylinder heads.
(b) Remove the two delivery pipe and intake manifold assembly.
(c) Remove the two intake manifold gaskets.
24. DISCONNECT HEATER WATER HOSES FROM WATER BY±PASS PIPE AND REAR WATER BY±PASS JOINT
25. REMOVE WATER BY±PASS PIPE (a) Remove the two mounting bolts.
(b) Pull out the water by±pass pipe from the water pump.
(c) Remove the O±ring from the water by±pass pipe.
26. REMOVE REAR WATER BY±PASS JOINT Remove the four nuts, water by±pass joint and two gaskets.
±
STARTING SYSTEM StarterST±13
WhereEverybodyKnowsYourName
Page 2589 of 4087
27. REMOVE STARTER(a) Remove the two bolts holding the starter to the cylinderblock.
(b) Disconnect the starter connector.
(c) Remove the nut, and disconnect the starter wire.
(d) Disconnect the wire clamp from the wire bracket, and remove the starter.
ST±14
±
STARTING SYSTEM Starter
WhereEverybodyKnowsYourName
Page 2590 of 4087
COMPONENTS FOR DISASSEMBLY AND
ASSEMBLY
DISASSEMBLY OF STARTER
1. REMOVE FIELD FRAME AND ARMATURE(a) Remove the nut, and disconnect the lead wire from themagnetic switch terminal.
(b) Remove the two through bolts, spring washer, wire bracket and two O±rings.
(c) Pull out the field frame together with the armature.
(d) Remove the O±ring from the field frame.
±
STARTING SYSTEM StarterST±15
WhereEverybodyKnowsYourName
Page 2591 of 4087
2. REMOVE STARTER HOUSING, CLUTCH ASSEMBLYAND GEARS
(a) Remove the two mounting screws.
(b) Remove the following parts from the magnetic switch:(1) Starter housing
(2) Return spring
(3) Pinion gear
(4) Bearing
(5) Idler gear
(6) Clutch assembly
3. REMOVE STEEL BALL Using a magnetic finger, remove the steel ball from the clutch
shaft hole.
4. REMOVE BRUSH HOLDER Using a screwdriver, hold the spring back and disconnect the
brush from the brush holder. Disconnect the four brushes,
and remove the brush holder.
5. REMOVE ARMATURE FROM FIELD FRAME
ST±16
±
STARTING SYSTEM Starter
WhereEverybodyKnowsYourName
Page 2592 of 4087

INSPECTION AND REPAIR OF STARTER
Armature Coil
1. INSPECT COMMUTATOR FOR OPEN CIRCUITUsing an ohmmeter, check that there is continuity between
the segments of the commutator.
If there is no continuity, replace the armature.
2. INSPECT COMMUTATOR FOR GROUND Using an ohmmeter, check that there is no continuity be-
tween the commutator and armature coil core.
If there is continuity, replace the armature.
Commutator
1. INSPECT COMMUTATOR FOR DIRTY AND BURNTSURFACE
If the surface is dirty or burnt, correct with sandpaper
(No.400) or on a lathe.
2. INSPECT COMMUTATOR FOR RUNOUT (a) Place the commutator on V±blocks.
(b) Using a dial indicator, measure the circle runout.
Maximum circle runout: 0.05 mm (0.0020 in.)
If the circle runout is greater than maximum, correct it on a
lathe.
3. INSPECT COMMUTATOR DIAMETER Using a vernier caliper, measure the diameter.
Standard diameter: 35.0 mm (1.378 in.)
Minimum diameter: 34.0 mm (1.339 in.)
If the diameter is less than minimum, replace the armature.
±
STARTING SYSTEM StarterST±17
