12. Observe the following precautions to avoid damage to theparts:
(a) Do not open the cover or case of the ECU unless
absolutely necessary (If the IC terminals are touched, the
IC may be destroyed by static electricity.).
(b) To pull apart electrical connectors, pull on the connectoritself, not the wires (See page BE±2).
(c) Be careful not to drop electrical components, such as sensors or relays. It they are dropped on a hard floor,
they should be replaced and not reused.
(d) When checking continuity at the wire connector, insert the tester probe carefully to prevent terminals from
bending.
(e) To disconnect vacuum hoses, pull on the end, not the middle of the hose.
(f) When steam cleaning an engine, protect the distributor,
coil and air filter from water.
(g) Ne ve r use an imp a ct wre n ch to re mo ve or in sta ll temperature switches or temperature sensors.
(h) When using a vacuum gauge, never force the hose onto
a connector that is too large. Use a step±down adapter
instead. Once the hose has been stretched, it may leak.
13. Tag hoses before disconnecting them: (a) When disconnecting vacuum hoses, use tags to identify
how they should be reconnected.
(b) After completing a job, double check that the vacuum hoses are properly connected. A label under the hood
shows the proper layout.
14. Installation of wheels The wheel assemblies are of the uni±directional type and
must be rotated only between the front and rear as illustrated.
Wheels are marked with turning direction indicators.
When installing the wheels, check the marks carefully and
install the wheel correctly.
15. Bleeding of traction control system When repairing the brake master cylinder or TRAC system,
bleed the air out of the TRAC system (See page BR±7).
CAUTION: Since the fluid is under high pressure, it could
spray out with great force, so be careful.
IN±6
±
INTRODUCTION General Repair Instructions
WhereEverybodyKnowsYourName

When the negative (±) terminal cable is disconnected from
the battery, memory of the clock and audio systems will be
cancelled. So before starting work, make a record of the con-
tents memorized by each memory system. Then when work
is finished, reset the clock and audio systems as before.
When the vehicle has power tilt and power telescopic steer-
ing, power seat, power outside rear view mirror and power
shoulder belt anchorage, which are all equipped with
memory function, it is not possible to make a record of the
memory contents. So when the operation is finished, it will be
necessary to explain this fact to the customer, and ask the
customer to adjust the features and reset the memory.
To avoid erasing the memory of each memory system, never
use a back±up power supply from outside the vehicle.
3. Even in cases of a minor collision where the airbag does not deploy, the front airbag sensors and the steering wheel pad
should be inspected. (See page AB±9)
4. Never use airbag parts from another vehicle. When replacing parts, replace them with new parts.
5. Before repairs, remove the airbag sensors if shocks are likely
to be applied to the sensors during repairs.
6. The center airbag sensor assembly contains mercury. After
performing replacement, do not destroy the old part. When
scrapping the vehicle or replacing the center airbag sensor
assembly itself, remove the center airbag sensor assembly
and dispose of it as toxic waste.
7. Never disassemble and repair the front airbag sensors, center airbag sensor assembly or steering wheel pad in order
to reuse it.
8. If the front airbag sensors, center airbag sensor assembly or steering wheel pad have been dropped, or if there are cracks,
dents or other defects in the case, bracket or connector,
replace them with new ones.
9. Do not expose the front airbag sensors, center airbag sensor assembly or steering wheel pad directly to hot air or flames.
10. U s e a v o l t / o h m m e t e r w i t h h i g h i m pedance (10 kW/V
minimum) for troubleshooting of the electrical circuit.
11. Information labels are attached to the periphery of the airbag components. Follow the notices.
12. After work on the airbag system is completed, perform the
airbag warning light check (See page AB±30).
±
INTRODUCTION Precautions for Vehicles Equipped with SRS AirbagIN±9
WhereEverybodyKnowsYourName

FRONT AIRBAG SENSOR
1. Never reuse the front airbag sensors involved in a collisionwhen the airbag has deployed. (Replace both the left and
right airbag sensors.)
2. Install the front airbag sensor with the arrow on the sensor facing toward the front of the vehicle.
3. The front airbag sensor set bolts have been anti±rust treated. When the sensor is removed, always replace the set bolts
with new ones.
4. The front airbag sensor is equipped with an electrical connection check mechanism. Be sure to lock this
mechanism securely when connecting the connector. If the
connector is not securely locked, a malfunction code will be
detected by the diagnosis system (See page AB±10).
SPIRAL CABLE (IN COMBINATION
SWITCH)
The steering wheel must be fitted correctly to the steering column
with the spiral cable at the neutral position; otherwise cable dis-
connection and other troubles may result. Refer to page AB±15
of this manual concerning correct steering wheel installation.
STEERING WHEEL PAD (WITH AIRBAG)
1. When removing the steering wheel pad or handling a new steering wheel pad, it should be placed with the pad top
surface facing up.
In this case, the twin±lock type connector lock lever should
be in the locked state and care should be taken to place it so
the connector will not be damaged. And do not store a steer-
ing wheel pad on top of another one. (Storing the pad with its
metallic surface up may lead to a serious accident if the air-
bag inflates for some reason.)
2. Never measure the resistance of the airbag squib. (This
may cause the airbag to deploy, which is very
dangerous.)
IN±10±
INTRODUCTION Precautions for Vehicles Equipped with SRS Airbag
WhereEverybodyKnowsYourName

3. Grease should not be applied to the steering wheel pad andthe pad should not be cleaned with detergents of any kind.
4. Store the steering wheel pad where the ambient temperature remains below 93
C (200
F), without high humidity and
away from electrical noise.
5. When using electric welding, first disconnect the airbag connector (yellow color and 2 pins) under the steering
column near the combination switch connector before
starting work.
6. When disposing of a vehicle or the steering wheel pad alone, the airbag should be deployed using an SST
before disposal (See page AB±91). Perform the
operation in a place away from electrical noise.
CENTER AIRBAG SENSOR ASSEMBLY
The connector to the center airbag sensor assembly should be
connected or disconnected with the sensor mounted on the floor.
If the connector is connected or disconnected while the center air-
bag sensor assembly is not mounted to the floor, it could cause un-
desired ignition of the airbag system.
WIRE HARNESS AND CONNECTOR
The airbag system's wire harness is integrated with the cowl wire
harness assembly. The wires for the airbag wire harness are en-
cased in a yellow corrugated tube. All the connectors for the sys-
tem are also a standard yellow color. If the airbag system wire har-
ness becomes disconnected or the connector becomes broken
due to an accident, etc., repair or replace it as shown on page
AB±22 .
±
INTRODUCTION Precautions for Vehicles Equipped with SRS AirbagIN±11
WhereEverybodyKnowsYourName

[2] SYMPTOM CONFIRMATION AND DIAGNOSTIC CODE CHECK
The diagnostic system in the LEXUS SC400 fulfills various functions. The fi\
rst function is the Diagnostic Code
Check in which a malfunction in the signal circuits to the ECU is stored\
in code in the ECU memory at the time
of occurrence, to be output by the technician during troubleshooting. Anot\
her function is the Input Signal Check
which checks if the signals from various switches are sent to the ECU correct\
ly.
The air conditioner system has an Actuator Check function whereby the ECU a\
utomatically operates the actua-
tors of the damper and blowermotor, etc. to check the operation. The cruise control system has a Cancel Si\
gnal
Check function which memorizes and displays what sort of signal it was that l\
ast cancelled the cruise control.
By using these check functions, the problem areas can be narrowed down qui\
ckly and troubleshooting can be
performed effectively. Diagnostic functions are incorporated in the following systems in the \
LEXUS SC400.
SystemDiagnostic CodeCheckInput Signal Check(Sensor Check)Other Diagnosis Function
Engine (with Test Mode)
Automatic Transmission (with Test Mode)
Anti±Lock Brake
Traction Control (Option)
SRS Airbag
Power Seat (only vehicles with memory function)
Wireless Door Lock Control
Cruise Control Cancel Signal
Check
Air Conditioner Actuator Check
In diagnostic code check, it is very important to determine whether the pr\
oblem indicated by the diagnostic code
is still occurring or occurred in the past but returned to normal at pre\
sent. In addition, it must be checked in the
problem sym ptom check whether the malfunction indicated by the diagnostic code is d\
irectly related to the prob-
lem symptom or not. For this reason, the diagnostic codes should be chec\
ked before and after the symptom
confirmation to determine the current conditions, as shown in the table below. If this is not done, it may, depend-
ing on the case, result in unnecessary troubleshooting for normally oper\
ating systems, thus making it more diffi-
cult to locate the problem, or in repairs not pertinent to the problem. Ther\
efore, always follow the procedure in
correct order and perform the diagnostic code check.
DIAGNOSTIC CODE CHECK PROCEDURE
IN±18±
INTRODUCTION How to Troubleshoot ECU Controlled Systems
WhereEverybodyKnowsYourName

[3] SYMPTOM SIMULATION
The most difficult case in troubleshooting is when there are no problem symptoms occurring. In s\
uch cases, a
thorough customer problem analysis must be carried out, then simulate the same or similar conditions and envi-
ronment in which the problem occurred in the customer's vehicle. No matter now much experience a technician
has, or how skilled he may be, if he proceeds to troubleshoot without confir\
ming the problem symptoms he will
tend to overlook something important in the repair operation and make a wron\
g guess somewhere, which will
only lead to a standstill. For example, for a problem which only occurs when\
the engine is cold, or for a problem
which occurs due to vibration caused by the road during driving, etc., the pr\
oblem can never be determined so
long as the symptoms are confirmed with the engine hot condition or the \
vehicle at a standstill. Since vibration,
heat or water penetration (moisture) are likely causes for problems which are \
difficult to reproduce, the symptom
simulation tests introduced here are effective measures in that the external causes are applied to the vehicle
in a stopped condition.
Important Points in the Symptom Simulation Test
In the symptom simulation test, the problem symptoms should of course be co\
nfirmed, but the problem area
or parts must also be found out. To do this, narrow down the possible problem circuits according to the sym\
ptoms
before starting this test and connect a tester beforehand. After that, carry out the symptom simulation test, judg-
ing whether the circuit being tested is defective or normal and also confir\
ming the problem symptoms at the
same time. Refer to the matrix chart of problem symptoms for each system to \
narrow down the possible causes
of the symptom.
[1] VIBRATION METHOD: When vibration seems to be the major cause.
CONNECTORS
Slightly shake the connector vertically and horizon-
tally.
WIRE HARNESS
Slightly shake the wire harness vertically and horizontally.
The connector joint, fulcrum of the vibration, and body
through portion are the major areas to be checked thor-
oughly.
PARTS AND SENSORS
Apply slight vibration with a finger to the part of the
sensor considered to be the problem cause and
check if the malfunction occurs.
HINT: Applying strong vibration to relays may result
in open relays. IN±20
±
INTRODUCTION How to Troubleshoot ECU Controlled Systems
WhereEverybodyKnowsYourName

Location of Connectors in Engine Compartment
wLocation of connectors
This diagram shows the wire harnesses and connectors used in one system.\
The connector shows the harness side connector, so when checking the part side connector (sensor, ac-
tuator, etc.), be careful not to mistake the terminal positions.
±
INTRODUCTION How to Troubleshoot ECU Controlled SystemsIN±25
WhereEverybodyKnowsYourName

HOW TO USE THE DIAGNOSTIC CHART AND INSPECTION
PROCEDURE
1. For troubleshooting, diagnostic code charts or problem symptom charts are p\
rovided for each circuit withdetailed inspection procedures on the following pages.
2. When all the component parts, wire harnesses and connectors of each circuit \
except the ECU are found to be normal in troubleshooting, then it is determined that the problem \
is in the ECU.
Accordingly, if diagnosis is performed without the problem symptoms occurring, the \
instruction will be to
check and replace the ECU, even if the problem is not in the ECU. So, al\
ways confirm that the problem
symptoms are occurring, or proceed with inspection while using the sympt\
om simulation method.
3. The instructions ºCheck wire harness and connectorº and ºCheck and\
replace ECUº which appear in the inspection procedure, are common and applicable to all diagnostic codes.\
Follow the procedure outlined
below whenever these instructions appear.
Check Wire Harness and Connector
The problem in the wire harness or connector is an open circuit or a short \
circuit.
OPEN CIRCUIT:
This could be due to a disconnected wire harness, faulty contact in the conn\
ector, a connector terminal pulled
out, etc.
HINT:
1. It is rarely the case that a wire is broken in the middle of it. Most cases occur at the connector. Inparticular, carefully check the connectors of sensors and actuators.
2. Faulty contact could be due to rusting of the connector terminals, to foreign materials entering terminals or a drop in the contact pressure between the male and female terminals of th\
e connector.
Simply disconnecting and reconnecting the connectors once changes the conditio\
n of the
connection and may result in a return to normal operation.
Therefore, in troubleshooting, if no abnormality is found in the wire harness and \
connector check, but the prob-
lem disappears after the check, then the cause is considered to be in th\
e wire harness or connectors.
SHORT CIRCUIT:
This could be due to a short circuit between the wire harness and the body ground or t\
o a short inside the switch,
etc.
HINT:
w When there is a short between the wire harness and body ground, check thorou\
ghly whether the wire
harness is caught in the body or is clamped properly.
±
INTRODUCTION How to Troubleshoot ECU Controlled SystemsIN±27
WhereEverybodyKnowsYourName
