Page 641 of 4087

LEXUS SC400 1991 Service Repair Manual 26CD playerWOOFER DOES NOT WORK HINT: The part names and terminals indicated in brackets ( ) are for models\ with a Nakamichi system. Is radio operating normally? Is there battery voltage between th

Page 642 of 4087

LEXUS SC400 1991 Service Repair Manual 27CD playerWOOFER VOLUME FAINT HINT: The part names and terminals indicated in brackets ( ) are for models\ with a Nakamichi system. Is radio operating normally? Is there continuity between the foll

Page 643 of 4087

LEXUS SC400 1991 Service Repair Manual 28CD playerSOUND QUALITY POOR Is radio operating normally? Is speaker properly installed? Temporarily install another speaker Functions OK? Temporarily install another CD auto changer. Functions OK?

Page 644 of 4087

LEXUS SC400 1991 Service Repair Manual 30NoiseNOISE PRODUCED BY VIBRATION OR SHOCK WHILE DRIVING Is radio properly installed? Is radio receiver assembly properly installed? *1 Is radio power amplifier properly installed? *2 Is woofer ampl

Page 645 of 4087

LEXUS SC400 1991 Service Repair Manual 31NoiseNOISE PRODUCED WHEN ENGINE STARTS Whistling noise which becomes high±pitched when accelerator strongly depressed, disappears shortly after engine stops.Whining noise occurs when A/C is operat

Page 646 of 4087

LEXUS SC400 1991 Service Repair Manual 32AntennaANTENNA±RELATED Does antenna extend when radio switched ON?Wire harness faulty. Is there battery voltage between the following terminals with connector disconnected?  Motor antenna cont

Page 647 of 4087

LEXUS SC400 1991 Service Repair Manual Wire harness faulty. Is there continuity between the following terminals with connector disconnected?  Radio receiver assembly A9 (*A1) ± Motor anten- na control relay 4  Radio receiver assembly

Page 648 of 4087

LEXUS SC400 1991 Service Repair Manual HORN SYSTEM PARTS LOCATION WIRING AND CONNECTOR DIAGRAMS BE±262± BODY ELECTRICAL SYSTEM HORN SYSTEM WhereEverybodyKnowsYourName
