Page 1977 of 4087
Preparation
SST (SPECIAL SERVICE TOOLS)
IllustrationPart No.Part NameNote
09268±41045Injection Measuring
Tool Set
(90268±41070)No. 4 Union
Injector
(09268±41080)No. 6 Union
Cold start Injector
(09268±52010)Injection Measuring
Attachment
Injector
09268±45012EFI Fuel Pressure
Gauge
09612±24014
Steering Gear
Housing Overhaul
Tool Set
(09617±24011)Steering Rack Wrench
Fuel pressure pulsation damper
09631±22020
Power Steering
Hose Nut 14 X 17 mm
Wrench SetFuel line flare nut
09816±30010Oil Pressure
Switch SocketKnock sensor
09842±30055Wire ªGº
EFI Inspection
Cold start Injector
09842±30070Wire ªFº
EFI Inspection
Injector
09843±18020Diagnosis Check
Wire
0990±01000
Engine Control
Computer
Check Harness ªAº
FI±10 ± PreparationEFI SYSTEM
WhereEverybodyKnowsYourName
Page 1978 of 4087
RECOMMENDED TOOLS
IllustrationPart No.Part NameNote
09082±0015TOYOTA
Electrical Tester
09200±00010Engine Adjust
Kit
09258±00030Hose Plug Set
Plug for the Vacuum hose, fuel hose ect.
EQUIPMENT
Part NameNote
Graduated cylinderInjector
Tachometer
Torque wrench
SSM (SERVICE SPECIAL MATERIALS)
Part NamePart No.Use etc.
Seal packing 1282B,08826±00100Water inlet housing
Three bond 1282B or equivalent
FI±11EFI SYSTEM ± Preparation
WhereEverybodyKnowsYourName
Page 1979 of 4087
Fuel pump ECU
COMPONENTS FOR REMOVAL AND
INSTALLATION
FI±122 ± Electronic Contro\
l System (Fuel Pump ECU)EFI SYSTEM
WhereEverybodyKnowsYourName
Page 1980 of 4087
INSPECTION OF FUEL PUMP ECU
1. DISCONNECT CABLE FROM NEGATIVE TERMINAL OFBATTERY
CAUTION: Work must be started after approx. 20 se-
conds or longer from the time the ignition switch is
turned to the ºLOCKº position and the negative (±) termi-
nal cable is disconnected from the battery.
2. REMOVE SEAT CUSHION AND BACK
3. REMOVE QUARTER TRIM
(a) Disconnect the rear side of the scuff plate by pulling it.
(b) Remove clip A.
(c) Remove the belt hole cover by pulling it.
(d) Remove clip B.
(e) Remove the quarter trim by pulling it.
4. DISCONNECT FUEL PUMP ECU CONNECTOR FI±123
EFI SYSTEM
± Electronic Control System (Fuel Pump ECU)
WhereEverybodyKnowsYourName
Page 1981 of 4087
5. INSPECT FUEL PUMP ECU(a) Connect the cable to the negative (±) terminal of thebattery.
(b) Check the connector on the wiring harness side as shown in the chart.
Check forTester connectionConditionSpecified value
ContinuityE ± Ground±Continuity
ContinuityDI ± Ground±Continuity
VoltageFP GroundSudden racing12 ± 14 VVoltageFP ± GroundIdling8 ± 10 V
Voltage+ B ± GroundIG SW ON10 ± 14 V
VoltageFPC ± Ground
Sudden racing
(1,600 rpm or more)4 ± 6 VVoltageFPC Ground
Idling2.5 V
If circuit is as specified, replace the fuel pump ECU.
(c) Disconnect the cable from the negative (±) terminal of the battery.
6. RECONNECT FUEL PUMP ECU CONNECTOR
7. INSTALL QUARTER TRIM (a) Attach the upper side of the quarter trim to the quarterpanel.
(b) Install the quarter trim with the four clips.
FI±124
EFI SYSTEM
± Electronic Control System (Fuel Pump ECU)
WhereEverybodyKnowsYourName
Page 1982 of 4087
(c) Install the belt hole cover with the two clips.
(d) Install the rear side of the scuff.
8. REINSTALL SEAT BACK AND CUSHION
9. RECONNECT CABLE FROM NEGATIVE TERMINAL OF BATTERY FI±125
EFI SYSTEM
± Electronic Control System (Fuel Pump ECU)
WhereEverybodyKnowsYourName
Page 1983 of 4087

Engine & ECT ECU
TERMINALS OF ENGINE & ECT ECU
TerminalNo.SymbolConnectionTerminalNo.SymbolConnection
E9 ± 1IGSWIgnition SwitchE9 ± 31+ BEFI Main Relay
2SPDNo. 1 Speed Sensor32+ B1EFI Main Relay
3KDKick±Down Switch33BATTBattery
4STPStop light Switch34A/CA/C Control Assembly
5±35±
6WªCHECKº Engine Warning Light36±
7RNeutral Start Switch37TRTRAC ECU
8±38NEOTRAC ECU
92Neutral Start Switch39VTO2TRAC ECU
10LNeutral Start Switch40VTO1TRAC ECU
11ADCC ECUE10 ± 1NCO T/M Input Speed Sensor
12OD1CC ECU2±
13±3SP2No. 2 Speed Sensor for ECT
14±4E11ECU Ground
15±5G2Cam position Sensor
16±6G1Cam position Sensor
17TTTDCL7NFEngine Speed Sensor
18PECT Pattern Select Switch8±
19TE2Check Connector9S2ECT Solenoid Value
20TE1Check Connector10S1ECT Solenoid Value
21D1Fuel Pump ECU11±
22FPCFuel Pump ECU12±
23ACMGA/C Magnet Clutch Relay13SLN No.3 ECT Solenoid Valve
24M±RELEFI Main Relay14SLUNo.4 ECT Solenoid Valve
25±15±
26±16±
27±17#10No.3 and No.5 Injectors
28OD2O/D Main Relay18#20No.4 and No.6 Injectors
29±19#20No.2 and No.8 Injectors
30±20#40No.1 and No.7 Injectors
Engine & ECT ECU Terminals
FI±126 ± Electronic Control \
System (Engine & ECT ECU)EFI SYSTEM
WhereEverybodyKnowsYourName
Page 1984 of 4087

TERMINALS OF ENGINE & ECT ECU (Cont'd)
TerminalNo.SymbolConnectionTerminalNo.SymbolConnection
E10± 21NCOT/M Input Speed SensorE10 ± 51±
22±52HTL2LH Sub±Oxygen Sensor Heater
23SP2No.2 Speed Sensor for ECT53HTR2RH Sub±Oxygen Sensor Heater
24±54±
25G2LH (No.2) Cam Position Sensor55±
26G1RH (No.1) Cam Position Sensor56IGT2No.2 Igniter for RH Bank
27NEEngine Speed Sensor57IGT1No.1 Igniter for LH Bank
28VF2Check Connector58IGF1No.1 Igniter for LH Bank
29VF1Check Connector59IGF2No.2 Igniter for RH Bank
30±60±
31±61±
32ISC4ISC Valve62±
33ISC3ISC Valve63IDL2Sub±Throttle Position Sensor
34ISC2ISC Valve64IDL1Throttle Position Sensor
35ISC1ISC Valve65E2Sensor Ground
36* EGR4EGR Valve66KSAir Flow Meter
37* EGR3EGR Valve67OXR2
38* EGR2EGR Valve68OXL2LH Sub±Oxygen Sensor
39* EGR1EGR Valve69E1ECU Ground39* EGRVSV for EGR69E1ECU Ground
40±70±
41VCThrottle Position Sensor
Air Flow Meter71HTL1LH Main Oxygen Sensor
42VTA2Fuel Pump ECU72HTR1RH Main Oxygen Sensor
43VTA1A/C Magnet Clutch Relay73FPUVSV for Fuel Pressure Control
Value
44THWWater Temp. Sensor74* PA GVSV for EVAP
45THAIntake Air Temp. Sensor75±
46THGEGR Gas Temp. Sensor76NSWNeutral Start Switch
47OXR1RH Main Oxygen Sensor77STAStarter Relay
48OXL1LH Main Oxygen Sensor78STJCold Start Injector
49KNK2RH (No.2) Knock Sensor79E02Power Ground
50KNK1LH (No.1) Knock Sensor80E01Power Ground
Engine & ECT ECU Terminals
* USA spec. only
* A/T only
FI±127EFI SYSTEM ± Electronic Control System (Engine & ECT ECU)
