Page 1625 of 4087

LEXUS SC400 1991 Service Repair Manual (d) Retighten the connecting rod cap bolts 905 in thenumerical order shown. (e) Check that the painted mark is now at a 905 angle to the front. (f) Check that the crankshaft turns smoothly. (g) C

Page 1626 of 4087

LEXUS SC400 1991 Service Repair Manual POST ASSEMBLY (See Components on page EM±131) 1. INSTALL WATER SEAL PLATE (a) Remove any old packing (FIPG) material and be careful not to drop any oil on the contact surfaces of the seal plate an

Page 1627 of 4087

LEXUS SC400 1991 Service Repair Manual (c) Place a new O±ring in position on the cylinder block. (d) Engage the spline teeth of the oil pump drive gear withthe large teeth of the crankshaft, and slide the oil pump. (e) Install the oi

Page 1628 of 4087

LEXUS SC400 1991 Service Repair Manual (b) Apply seal packing to the sealing groove of the waterpump as shown in the illustration. Seal packing: Part No.08826±00100 or equivalent wInstall a nozzle that has been cut to a 2±3 mm (0.08±0

Page 1629 of 4087

LEXUS SC400 1991 Service Repair Manual 8. INSTALL KNOCK SENSORS(a) Using SST, install the two knock sensors. SST 09816±30010 Torque: 44 N Vm (450 kgf Vcm, 33 ft Vlbf) (b) Connect the two knock sensor connectors. 9. INSTALL STARTER (a)

Page 1630 of 4087

LEXUS SC400 1991 Service Repair Manual 12. INSTALL CYLINDER HEADS(See pages EM±92 to 115) 13. INSTALL TIMING PULLEYS AND BELT (See pages EM±48 to 57) 14. REMOVE ENGINE STAND FROM ENGINE 15. INSTALL DRIVE PLATE (a) Apply adhesive

Page 1631 of 4087

LEXUS SC400 1991 Service Repair Manual 3. INSTALL DIPSTICK GUIDE FOR TRANSMISSION(a) Install a new O±ring to the dipstick guide. (b) Apply soapy water to the O±ring. (c) Connect the dipstick guide end to the tube of the oil pan, a

Page 1632 of 4087

LEXUS SC400 1991 Service Repair Manual INSTALLATION OF ENGINE (See Components on pages EM±116 to 118) 1. INSTALL ENGINE AND TRANSMISSION ASSEMBLY IN VEHICLE (a) Attach the engine hoist chain to the engine hangers. (b) Lower the engine
