Page 433 of 4087

LEXUS SC400 1991 Service Repair Manual (b) Remove the clip, loosen the bolt disconnect the doorsupport. (c) Remove the door support. 3. IF NECESSARY, REPLACE DOOR SUPPORT (See step 3 on page BO±23) INSTALLATION OF LUGGAGE COMPARTMENT

Page 434 of 4087

LEXUS SC400 1991 Service Repair Manual Trim and Weatherstrip COMPONENTS REMOVAL OF TRIM AND WEATHERSTRIP 1. REMOVE FLOOR MAT 2. REMOVE DOOR STRIKER COVERPull up the cover and remove it. BO±78 ± BODY Luggage Compartment (Trim and W eat

Page 435 of 4087

LEXUS SC400 1991 Service Repair Manual 3. REMOVE TRIM REAR COVER(a) Using a clip remover, remove six clips. (b) Pull up the cover to remove it. 4. REMOVE TRIM FRONT COVER Remove two screws and the cover. 5. REMOVE LH SIDE COVER Using

Page 436 of 4087

LEXUS SC400 1991 Service Repair Manual 8. REMOVE LUGGAGE COMPARTMENT DOOR(See step 2 on page BO±76) 9. REMOVE WEATHERSTRIP Pull out the weatherstrip by hand and remove it. INSTALLATION OF TRIM AND WEATHERSTRIP (See page BO±78) INSTAL

Page 437 of 4087

LEXUS SC400 1991 Service Repair Manual MOON ROOF Fitting Adjustments (See page BO±83) 1. INSPECT SLIDING ROOF GLASS ALIGNMENT (a) Start the engine and check the operation time of thesliding roof. Operation time: Approx. 5 secs. (b)

Page 438 of 4087

LEXUS SC400 1991 Service Repair Manual (b) When the front or rear alignment is not correct, removethe glass and adjust the drive rail. (c) Using a screwdriver, slide the link forward or backward to align the two marks as shown. (d) Sli

Page 439 of 4087

LEXUS SC400 1991 Service Repair Manual Sliding Roof COMPONENTS ± BODY Moon Roof (Sliding Roof)BO±83 WhereEverybodyKnowsYourName

Page 440 of 4087

LEXUS SC400 1991 Service Repair Manual COMPONENTS (Contd) BO±84± BODY Moon Roof (Sliding Roof) WhereEverybodyKnowsYourName
