(b) Check the flow control valve for leakage.Close one of the holes and apply compressed air 392 ±490
kPa (4±5 kgf/ cm
2, 57±71 psi) into the opposite side, and con-
firm that air does not come out from the end holes.
If necessary, replace the valve with one having the same let-
ter as inscribed on the front housing.
Inscribed mark:
A, B, C, D, E or F
4. INSPECT FLOW CONTROL SPRINGUsing a calipers, measure the free length of the spring.
Minimum spring length:
36 mm (1.42 in.)
If not within specification, replace the spring.
5. IF NECESSARY, REPLACE OIL SEAL
(a) Using SST, tap out the oil seal. SST 09631±10030
(b) Using a 22 mm socket wrench and hammer, drive in a new oil seal.
NOTICE: Make sure you install the oil seal facing the correct
direction.
(c) Coat the oil seal lip with power steering fluid.
±
STEERING POWER STEERINGSR±125
WhereEverybodyKnowsYourName
Page 2986 of 4087
6. IF NECESSARY, REPLACE BEARING
(a) Using snap ring pliers, remove the snap ring.
(b) Using a press, press out the bearing.
(c) Using a press, press in a new bearing.
(d) Using snap ring pliers, install a new snap ring.
POWER STEERING PUMP ASSEMBLY
SR0G9±02
1. COAT WITH POWER STEERING FLUID BEFOREASSEMBLY
(See page SR±120)
2. INSTALL VANE PUMP SHAFT WITH BEARING
(a) Using SST and a press, press in the pump shaft. SST 09238±47012
(b) Using snap ring pliers, install a new snap ring.
3. INSTALL SIDE FRONT PLATE, CAM RING, ROTOR, VANE PLATES AND SIDE REAR PLATE
(a) Install the longer straight pin to the front housing.
SR±126
±
STEERING POWER STEERING
WhereEverybodyKnowsYourName
Page 2987 of 4087
(b) Coat new 2 O±rings with power steering fluid and install themto the side front plate.
(c) Coat a new O±rings with power steering fluid and install it to the side rear plate.
(d) Using SST and a press, press in the side front plate. SST 09238±47012
HINT: Match the wide hole on the side front plate with the
longer straight pin.
NOTICE: Be careful not to damage the O±rings.
(e) Install the shorter straight pin to the side front plate.
(f) Match the wide hole of the cam ring with the longer straightpin, and install the cam ring.
HINT: Install the cam ring with the inscribed mark facing the
rear.
(g) Install the rotor to the shaft with the inscribed mark facing the rear.
±
STEERING POWER STEERINGSR±127
WhereEverybodyKnowsYourName
Page 2988 of 4087
(h) Coat the 10 vane plates with power steering fluid.
(i) Install the 10 vane plates with the round end facing outward.
(j) Match the wide hole with the longer straight pin and press inthe side rear plate with a press.
NOTICE: Be careful not to damage the O±ring.
4. INSTALL WAVE WASHERInstall the wave washer so that its protrusions fit into the slots
in the side rear plate.
5. INSTALL REAR BRACKET
(a) Coat a new O±ring with power steering fluid and install it to the rear bracket.
(b) Install the rear bracket and tighten the 4 bolts.
Torque: 39 N Vm (400 kgf Vcm, 29 ft Vlbf)
SR±128±
STEERING POWER STEERING
WhereEverybodyKnowsYourName
Page 2989 of 4087
6. MEASURE PUMP SHAFT PRELOAD
(a) Check that the shaft rotates smoothly without abnormalnoise.
(b) Temporarily install the pulley nut and check the rotating
torque.
Rotating torque:
0.1 N Vm (1.0 kgf Vcm, 0.9 in. Vlbf) or less
7. INSTALL FLOW CONTROL VALVE, SPRING, SPRING
SEAT AND PRESSURE PORT UNION
(a) Coat new O±rings with power steering fluid and install them
to the spring seat and pressure port union.
HINT: Install a thick O±ring to the spring seat and a thin O±
ring to the pressure port union.
(b) Install the spring seat with the bolt hole facing out±ward.
(c) Using snap ring pliers, install a new snap ring.
(d) Install spring and valve to the front housing.
(e) Install and torque the pressure port union.
Torque: 69 N Vm (700 kgf Vcm, 51 ft Vlbf)
±
STEERING POWER STEERINGSR±129
WhereEverybodyKnowsYourName
Page 2990 of 4087
8. INSTALL SUCTION PORT UNION
(a) Coat a new O±ring with power steering fluid and install it tothe suction port union.
(b) Install the suction port union with the 2 bolts.
Torque: 13 N Vm (130 kgf Vcm, 9 ft Vlbf)
9. INSTALL PUMP PULLEY
(a) Install the pulley and nut to the shaft.
(b) Using SST, torque the set nut.
SST 09278±54012
Torque: 43 N Vm (440 kgf Vcm, 32 ft Vlbf)
SR±130±
STEERING POWER STEERING
WhereEverybodyKnowsYourName
Page 2991 of 4087
GEAR HOUSING
(SC400)
GEAR HOUSING REMOVAL AND
INSTALLATION
SR0GG±03
Remove and install the parts, as shown.
MAIN POINTS OF REMOVAL AND
INSTALLATION
NOTICE: When disconnecting the intermediate shaft
during removal of the gear housing, remove the steering
wheel and perform centering of the spiral cable.
(See page SR±11)
If the operation is performed without removing the steer-
ing wheel, use the procedure below to make sure the
steering w heel is firmly fixed in position and cannot turn.
SR±142
±
STEERING POWER STEERING
WhereEverybodyKnowsYourName
Page 2992 of 4087
1. DISCONNECT INTERMEDIATE SHAFT
(a) Position the front wheels facing straight ahead.
(b) Using the seat belt of the driver's seat, fix the steering wheelso that it does not turn.
(c) Place matchmarks on the intermediate shaft and control valve shaft.
(d) Loosen the bolt on the upper side of the intermediate shaft,
remove the bolt on the lower side and disconnect the
intermediate shaft.
2. DISCONNECT TIE ROD ENDS
(a) Remove the cotter pin and nut.
(b) Using SST, disconnect the tie rod end from the knuckle arm. SST 09628±62011
3. CONNECT INTERMEDIATE SHAFT
(a) Set the gear housing so that it matches the dimensions shown below, with the gear housing at the center point.
±
STEERING POWER STEERINGSR±143
