REAR DIFFERENTIAL
DESCRIPTION
SA091±07
The differential has an 8 inch ring gear to ensure accurate operation at high p\
ower output and high speed.
The differential is carried by a rear suspension member via rubber mounts to su\
ppress vibration and noise
being transmitted to the body.
SA±74±
SUSPENSION AND AXLE REAR DIFFERENTIAL
WhereEverybodyKnowsYourName
Page 3338 of 4087
PREPARATION
SST (SPECIAL SERVICE TOOLS)
SA092±02
±
SUSPENSION AND AXLE REAR DIFFERENTIALSA±75
WhereEverybodyKnowsYourName
Page 3339 of 4087
SA±76±
SUSPENSION AND AXLE REAR DIFFERENTIAL
WhereEverybodyKnowsYourName
Page 3340 of 4087
RECOMMENDED TOOLS
SA093±02
EQUIPMENT
SA094±01\
\
\
Dial indicator with magnetic base
\
\
\
Micrometer
\
\
\
Torque wrench
±
SUSPENSION AND AXLE REAR DIFFERENTIALSA±77
WhereEverybodyKnowsYourName
Page 3341 of 4087
SSM (SPECIAL SERVICE MATERIALS)
SA095±04\
\
\
\
\
08826±00110 Seal packing 1389,
THREE BOND 1389 or equivalent
Differential Carrier x Cover
\
\
\
\
08833±00100 THREE BOND 1360K or equivalentDifferential Case x Ring Gear
LUBRICANT
SA096±02
Item Capacity Classification
Differential oil
1.35 liters (1.43 US qts, 1.19 lmp. qts)
API GL±5 Hypoid Gear Oil
[Above±18
C (0 F)]
SAE 90
[Below±18 C (0 F)]
SAE 80W or 80W±90
SA±78±
SUSPENSION AND AXLE REAR DIFFERENTIAL
WhereEverybodyKnowsYourName
Page 3342 of 4087
ON±VEHICLE REPAIR
COMPONENTS
SA097±02
SIDE GEAR SHAFT OIL SEAL
REPLACEMENT
SA0V1±04
1. DRAIN DIFFERENTIAL OIL
2. REMOVE REAR DRIVE SHAFT(See page SA±65)
3. REMOVE SIDE GEAR SHAFT
(a) Using SST and 2 bolts, remove the side gear shaft. SST 09520±22010
(b) Remove the snap ring from the side gear shaft.
4. REMOVE SIDE GEAR SHAFT OIL SEAL Using SST, remove the oil seal.
SST 09308±00010
±
SUSPENSION AND AXLE REAR DIFFERENTIALSA±79
WhereEverybodyKnowsYourName
Page 3343 of 4087
5. INSTALL SIDE GEAR SHAFT OIL SEAL
(a) Using SST and a hammer, drive in a new oil seal.SST 09608±32010, 09608±35014 (09608±06020)
(b) Apply MP grease to the oil seal lip.
6. INSTALL SIDE GEAR SHAFT
(a) Install a new snap ring to the side gear shaft.
(b) Using a hammer and brass bar, tap in the side gear shaft to
the differential.
NOTICE: Be careful not damage the side gear shaft and oil
seal.
7. CHECK INSTALLATION OF SIDE GEAR SHAFT
(a) Check that there is 2±3 mm (0.08±0.12 in.) of play in axialdirection.
(b) Check that the side gear shaft will not come out by trying to pull it out by hand.
8. INSTALL REAR DRIVE SHAFT
(See page SA±65)
9. CHECK DIFFERENTIAL OIL LEVEL Fill with hypoid gear oil if necessary.
Oil grade:
API GL±5 Hypoid Gear Oil
Viscosity: Above±18 C (0 F) SAE 90
Below±18 C (0 F) SAE 80W±90 or 80W
Capacity: 1.35 liters (1.43 US qts, 1.19 lmp. qts)
SA±80±
SUSPENSION AND AXLE REAR DIFFERENTIAL
WhereEverybodyKnowsYourName
Page 3344 of 4087
ECU Power Source Circuit
CIRCUIT DESCRIPTION
When the ignition switch is turned on, battery voltage
is applied to the terminal IG SW of the ECU, and the
main relay control circuit in the ECU sends a signal to
the terminal M±REL of the ECU, switching on the
main relay. This signal causes current to flow to the
coil, closing the contacts of the main relay and supply-
ing power to the terminals +B and +B1 of the ECU.
If the ignition switch is turned off, the ECU continues
to switch on the main relay for a maximum of 2 se-
conds for the initial setting of the ISC valve.
DIAGNOSTIC CHARTDIAGNOSTIC CHART
See next page for the DIAGNOSTIC CHART.
WIRING DIAGRAM
TR±124±
ENGINE TROUBLESHOOTING Circuit Inspection
