Page 817 of 4087
2. INSPECT RELAY CIRCUITRemove the relay from the junction block and inspect the
connector on junction block side as shown.
RelayCheck forTester connectionConditionSpecified value
TAILVoltage(1)±GroundConstantBattery voltage
(4)±Ground
P/W MAIN(6)±Ground
If the circuit is not as specified, refer to BE±15 wiring diagram
and inspect the circuits connected to other parts.
INSPECTION OF RELAY BLOCK NO. 2
1. INSPECT FUSE CIRCUIT Remove the fuse from the relay block and inspect the con-
nector on relay block side as shown.
FuseCheck forTester ConnectionConditionSpecified value
ABS NO. 1Voltage2±GroundConstantBattery voltage
AM14±Ground
ALT5±Ground
MAIN7±Ground
AM29±Ground
ABS NO. 211±Ground
INT13±Ground
±
BODY ELECTRICAL SYSTEM Power SourceBE±21
WhereEverybodyKnowsYourName
Page 818 of 4087

FuseCheck forTester ConnectionConditionSpecified value
HTRVoltage(15)±GroundConstantBattery voltage
DEF(17)±Ground
DOME(24)±Ground
EFI(26)±Ground
HAZ±HORN(28)±Ground
RADIO NO. 1(30)±Ground
TEL(32)±Ground
ALT±S(34)±Ground
TRAC(36)±Ground
HEAD (RH±LWR)(38)±GroundLight control switch turned to TAIL or
HEAD (LH±LWR)(40)±GroundHEAD and *ENGINE running
HEAD (RH±UPR)(44)±GroundLight control switch turned to HEAD and
HEAD (LH±UPR)(46)±Grounddimmer switch turned to HI or FLASH
If the circuit is not as specified, refer to BE±15 wiring diagram
and inspect the circuits connected to other parts.
2. INSPECT RELAY CIRCUIT Remove the relay from the relay block and inspect the con-
nector on relay block side as shown.
RelayCheck forTester connectionConditionSpecified value
EFIVoltage(4)±GroundConstantBattery voltage
ST(10)±Ground
(11)±Ground
DIM(15)±GroundLight control switch turned to TAIL or HEAD
(16)±Groundand *Engine running
IG2(18)±GroundConstant
HTR(24)±Ground
(25)±Ground
H±LP(28)±Ground
(30)±Ground
DEF(34)±Ground
(35)±Ground
If the circuit is not as specified, refer to BE±15 wiring diagram
and inspect circuits connected to other parts.
BE±22
±
BODY ELECTRICAL SYSTEM Power Source
WhereEverybodyKnowsYourName
Page 819 of 4087
INSPECTION OF RELAY BLOCK NO. 4
AND NO. 5 RELAY BLOCK
1. INSPECT FUSE CIRCUITRemove the fuse from the relay block and inspect the con-
nector on relay block side as shown.
FuseCheck forTester connectionConditionSpecified value
STHTRVoltage2±GroundIgnition Switch Turn to ONBattery voltage
If the circuit is not as specified, refer to BE±15 wiring diagram
and inspect the circuits connected to other parts.
2. INSPECT RELAY CIRCUIT
Remove the relay from the relay block and inspect the con-
nector on junction block side as shown.
RelayCheck forTester connectionConditionSpecified value
HORNVoltage(8)±GroundConstantBattery voltage
IG MAIN(9)±Ground
(13)±GroundContinuity
CRNRNG LP(14)±GroundIgnition Switch Turned to ONBattery voltage
(15)±Ground
±
BODY ELECTRICAL SYSTEM Power SourceBE±23
WhereEverybodyKnowsYourName
Page 820 of 4087
If the circuit is not as specified, refer to BE±15 wiring diagram
and inspect the circuits connected to other parts.
INSPECTION OF RELAY BLOCK NO. 6
(ABS and TRAC Relay Block)
INSPECT RELAY CIRCUIT
Remove the relay from the relay block and inspect the con-
nector on junction block side as shown.
RelayCheck forTester connectionConditionSpecified value
TRAC SOLVoltage(1)±GroundConstantBattery voltage
TRAC MTR(7)±Ground
ABS SOL(11)±Ground
ABS MIR(17)±Ground
If the circuit is not as specified, refer to BE±15 wiring diagram
and inspect circuits connected to other parts.
BE±24
±
BODY ELECTRICAL SYSTEM Power Source
WhereEverybodyKnowsYourName
Page 821 of 4087
IGNITION SWITCH
Description
The ignition switch is supplied with power from the battery via a fusible l\
ink. Power is supplied to each fuse
and relay according to the position of the switch, whether ªCCº ``ONº or ªSTARTº. The key unlock warning
switch, which detects the set condition of the key, is built into this switch.
Parts Location
Wiring and Connector Diagrams
±
BODY ELECTRICAL SYSTEM Ignition SwitchBE±25
WhereEverybodyKnowsYourName
Page 822 of 4087

Parts Inspection
(Ignition Switch and Key Unlock
Warning Switch)
REMOVAL AND INSTALLATION OF
IGNITION SWITCH AND KEY UNLOCK
WARNING SWITCH
1. DISCONNECT BATTERY TERMINALSCAUTION: Work must be started after approx. 20 se-
conds or longer from the time the ignition switch is
turned to the ºLOCKº position and negative (±) terminal
cable is disconnected from the battery.
2. REMOVE FOLLOWING PARTS: (See page BO±112)
w No. 1 under cover
w No. 1 lower finish panel
w Console box assembly
w Instrument panel lower center
3. REMOVE IGNITION SWITCH (a) Disconnect connector.
(b) Remove three screws and the switch from the keycylinder and wire harness clamp.
4. INSTALL IGNITION SWITCH For installation, follow the removal procedure in reverse.
INSPECTION OF IGNITION SWITCH AND
KEY UNLOCK WARNING SWITCH
1. INSPECT IGNITION SWITCH(Switch continuity)
Inspect the switch continuity between terminals.
Terminal
Switch position LOCKACC
ON
START
If continuity is not as specified, replace the switch.
BE±26
±
BODY ELECTRICAL SYSTEM Ignition Switch
WhereEverybodyKnowsYourName
Page 823 of 4087

(Switch circuit)
Connect the switch connector and inspect the connector on
the wire harness side from the back side as shown.
Check forTester connectionConditionSpecified value
Voltage2±GroundIgnition switch turned to ONBattery voltage
3±GroundIgnition switch turned to ACC or ON
4±GroundConstant
5±GroundIgnition switch turned to START
6±GroundIgnition switch turned to ON
11±GroundConstant
If circuit is not as specified, inspect the switch or refer to
BE±25 wiring diagram and inspect the circuits connected to
other parts.
2. INSPECT KEY UNLOCK WARNING SWITCH
(Switch continuity)
Inspect the switch continuity between terminals.
Terminal
Switch position
ON
OFF
(Ignition Key removed)
(Ignition Key set)
If continuity is not as specified, replace the switch.
(Switch circuit)
Connect the switch connector and inspect the connector on
the wire harness side from the back side as shown.
Check forCheck connectionConditionSpecified value
Continuity10±GroundIgnition key removedNo continuity
Ignition key setContinuity
9±GroundConstantContinuity
If circuit is not as specified, inspect the switch or wire harness.
±
BODY ELECTRICAL SYSTEM Ignition SwitchBE±27
WhereEverybodyKnowsYourName
Page 824 of 4087
LIGHTING SYSTEM
BE±28±
