SYMPTOM SIMULATION
ªIntermittent troubles or problemsº are the malfunctions about which the customer \
has a complaint, but which
do not occur and can not be confirmed in the workshop. The intermittent pr\
oblems also include complaints about
the SRS warning light going on and off erratically.
The self±diagnostic system stores the circuit of the intermittent pro\
blem in memory even if the ignition switch
is turned off.
And, for accurate diagnosis of the problems, ask the customer to obtain info\
rmation as much as possible follow-
ing the customer problem analysis check sheet (See page RS±58) and try to reproduce the intermittent problem.
The problem simulation methods described below are the effective ways for this nature of problem to produce
the problem conditions by applying vibration, heat, and humidity.
1VIBRATION METHOD: When vibration seems to be the major cause.
CONNECTORS
Slightly shake the connector vertically and horizontally.
(Inspection of connectors)
(a) Does the wire harness connecting with its corre-
sponding part have insufficient slack?
(b) Are the terminals dirty?
(c) Are the terminals making loose contact due to termi-
nals spread?
WIRE HARNESS
Slightly shake the wire harness vertically and horizontal-
ly. The connector joint, fulcrum of the vibration, and
body through portion are the major areas to be checked
thoroughly.
PARTS AND SENSORS
Apply vibration slightly by a finger to the part or sensor
considered to be the problem cause and check if the
malfunction will occur.
Caution: Do not apply vibration to the center
airbag sensor assembly.
±
SUPPLEMENTAL RESTRAINT SYSTEM TROUBLESHOOTINGRS±65
WhereEverybodyKnowsYourName
Page 3170 of 4087

2HEAT METHOD: When the problem seems to occur when the suspect area is heate\
d.
Heat the component that is likely the cause of the mal-
function with a hair dryer or similar object. Check to see
if the malfunction will occur.
Notice:
Do not heat to more than 60 C (140 F) (Tempera-
ture limit that the component can be touched with a
hand.)
Do not apply heat directly to any part in the ECU.
3WATER SPRINKLING METHOD: When the malfunction seems to occur on a rainy day or in
a high±humidity condition.
Sprinkle water onto the vehicle and check to see if the
malfunction will occur.
Notice: Never apply water directly onto the
electronic components.
HINT:
If the vehicle is subject to water leakage, the leaked
water may contaminate the ECU. When testing a ve-
hicle with a water leakage problem, special caution
must be paid.
4OTHER: When a malfunction seems to occur when electrical load is excessive.
Turn on all electrical loads including the heater blower,
headlights, rear window defogger, etc. and check to see
if the malfunction will occur.
RS±66±
SUPPLEMENTAL RESTRAINT SYSTEM TROUBLESHOOTING
WhereEverybodyKnowsYourName
Page 3171 of 4087

DIAGNOSTIC TROUBLE CODE MATRIX CHART
If a malfunction code is displayed during the diagnostic trouble code chec\
k, check the circuit listed for that
code in the table below (Proceed to the page given for that circuit).
DTC No.\
\
Diagnosis Page
(Normal)*1\
\
Source voltage drop RS±68
11\
\
Short in squib circuit or front airbag sensor circuit (to ground) RS±70
12\
\
Short in squib circuit or front airbag sensor circuit (to B+) RS±78
13\
\
Short in squib circuit (between D+ wire harness and D± wire harness\
) RS±85
14\
\
Open in squib circuit (between D+ wire harness and D± wire harness)\
RS±92
15\
\
Open in front airbag sensor circuit RS±97
22*2\
\
SRS warning light system malfunction RS±102
31\
\
Center airbag sensor assembly malfunction RS±108
53\
\
Short in squib circuit (between P+ wire harness and P± wire harness\
) RS±110
54\
\
Open in squib circuit (between P+ wire harness and P± wire harness)\
RS±115
HINT:
*
1 When the SRS warning light remains lit up and the diagnostic trouble co\
de is the normal code, this means
a source voltage drop.
*
2 Code 22 is recorded when a malfunction occurs in the SRS warning light \
system. If an open malfunction
occurs in the SRS warning light system, the SRS warning light does not light up, s\
o that until the malfunction
is repaired, the diagnostic trouble code (including 22) cannot be conf\
irmed.
PROBLEM SYMPTOM CHART
Proceed with troubleshooting of each circuit in the table below.
\
\
Problem Symptom Inspection Item Page
\
\
With the ignition switch at ACC or ON, the SRS warning light
sometimes lights up after approx. 6 seconds have elapsed SRS warning light system
(Always lit upwhen ignition switch isRS±119\
\
SRS warning light lights up even when ignition switch is in
the LOCK position (Always lit up when ignition switch is
LOCK position)RS±11 9
\
\
Diagnostic trouble code not displayed. Tc terminal circuitRS±121
\
\
Diagnostic trouble code continuously displayed. Tc terminal circuitRS±121
±
SUPPLEMENTAL RESTRAINT SYSTEM TROUBLESHOOTINGRS±67
WhereEverybodyKnowsYourName
Page 3172 of 4087

WIRING DIAGRAM
CIRCUIT INSPECTION
DTC(Normal)Source Voltage Drop
CIRCUIT DESCRIPTION
The supplemental restraint system is equipped with a voltage ± increase \
circuit (DC±DC converter) in the center
airbag sensor assembly in case the source voltage drops.
When the battery voltage drops, the voltage ± increase circuit (DC±DC\
converter) functions to increase the volt-
age of the supplemental restraint system to normal voltage.
The diagnosis system malfunction display for this circuit is different to other circuits ± when the SRS warning
light remains lit up and the diagnostic trouble code is a normal code, source\
voltage drop is indicated. Malfunc-
tion in this circuit is not recorded in the center airbag sensor assembly, and approx. 10 seconds after the source
voltage returns to normal, the SRS warning light automatically goes off.
DTC No.Diagnosis
(Normal)Source voltage drop.
DIAGNOSTIC CHARTDIAGNOSTIC CHART
(See page CH±1).
RS±68±
SUPPLEMENTAL RESTRAINT SYSTEM TROUBLESHOOTING
WhereEverybodyKnowsYourName
Page 3173 of 4087

YESNO
INSPECTION PROCEDURE
1Preparation.
P1. Turn ignition switch LOCK.
2. Disconnect battery negative (±) terminal cable, andwait at least 90 seconds.
3. Connect battery negative (±) terminal cable.
4. Disconnect center airbag sensor assembly con- nector.
5. Turn ignition switch ON. But do not start engine.
6. Measure voltage at IG
2 or ACC on connector wire
harness side of center airbag sensor assembly and
operate electric system (defogger, wiper, headlight,
heater blower, etc.)
Voltage: 6 V ± 11.5 V at IG
2 and ACC.
7. Turn electric system switch OFF.
8. Turn ignition switch LOCK.
9. Disconnect battery negative (±) terminal cable, and wait at least 90 seconds.
10. Remove voltmeter and connect center airbag sen- sor assembly connector.
11. Connect battery negative (±) terminal cable.
2Does SRS warning light turn off after approx. 10 seconds?
C
PTurn ignition switch ACC or ON and wait at least 20 sec-
onds.
Clear malfunction code. Turn ignition switch LOCK and
wait at least 20 seconds.
Operate electric system checked in (5) and check
that SRS warning light goes off after approx. 10 sec-
onds.
Check diagnostic trouble code, and if a malfunction code
is output, perform trouble shooting according to mal-
function code. If a normal code is output, replace center
airbag sensor assembly.
Check battery and charging system.
(See page CH±1)
±
SUPPLEMENTAL RESTRAINT SYSTEM TROUBLESHOOTINGRS±69
WhereEverybodyKnowsYourName
Page 3174 of 4087

DTC11Short in Squib Circuit or Front Airbag Sen-
sor Circuit (to Ground)
CIRCUIT DESCRIPTION
The squib circuit consists of the center airbag sensor assembly, spiral cable and the steering wheel pad (squib),
wire harness connector and front passenger airbag assembly (squib). It\
causes the SRS to operate when the
SRS operation conditions are satisfied.
The front airbag sensor detects the deceleration force in a frontal collisi\
on and is located in the front fender on
the left and right sides.
For details of the function of each component, see FUNCTION OF COMPONENTS o\
n page RS±10. Diagnostic
trouble code 11 is recorded when occurrence of ground short is detected in the squib ci\
rcuit or front airbag sen-
sor circuit.
DTC No.Diagnosis
11
Short circuit in squib wire harness (to ground)
Squib malfunction
Short circuit in front airbag sensor +S, D
+, D±, P+, P± wire harness (to ground).
Front airbag sensor malfunctions.
Short circuit between +S wire harness and ±S wire harness of front ai\
rbag sensor.
Spiral cable malfunction.
Center airbag sensor assembly malfunction.
RS±70±
SUPPLEMENTAL RESTRAINT SYSTEM TROUBLESHOOTING
WhereEverybodyKnowsYourName
Page 3175 of 4087
DIAGNOSTIC CHART
DIAGNOSTIC
CHART
(See page RS±49).
(See page RS±48).
±
SUPPLEMENTAL RESTRAINT SYSTEM TROUBLESHOOTINGRS±71
WhereEverybodyKnowsYourName
Page 3176 of 4087
WIRING DIAGRAM
DIAGNOSTIC CHART (Cont'd)DIAGNOSTIC CHART (Cont'd)
(See page RS±49).
RS±72±
