BR±120
WIRING DIAGRAM
DIAGNOSTIC CHARTDIAGNOSTIC CHART
±
BRAKE SYSTEM TRACTION CONTROL SYSTEM (TRAC)BR±191
WhereEverybodyKnowsYourName
Page 938 of 4087
IN±33).
WIRING DIAGRAM
DTC41IG Power Source Circuit
CIRCUIT DESCRIPTION
This is the power source for the ECU and becomes power source for the CPU an\
d actuators.
DTC No.DTC Detecting ConditionTrouble Area
41
When either of the following (1) or (2) is detected:
(1) Voltage at ECU terminal IG is less than 9.5 V for more than 10 sec. while engine speed is 500 rpm
or higher.
(2) Voltage at ECU terminal IG is more than 17 V for more than 5 sec.
Battery
IC regulator
Open or short in power source circuit
ECU
Fail safe function: If trouble occurs in the power source circuit, the E\
CU prohibits TRAC control.
DIAGNOSTIC CHARTDIAGNOSTIC CHART
BR±192±
BRAKE SYSTEM TRACTION CONTROL SYSTEM (TRAC)
WhereEverybodyKnowsYourName
Page 939 of 4087
OKNG
NGOK
OKNG
INSPECTION PROCEDURE
1Check battery positive voltage.
Voltage: 10 ± 14 VCOK
Check and repair the charging system.
2Check voltage between terminals IG and GND of TRAC ECU connector.
C
OK
P1. Remove TRAC ECU with connectors still con-nected.
2. Turn ignition switch on.
Measure voltage between terminals IG and GND of
TRAC ECU connector.
Voltage: 10 ± 14 V
Check and replace TRAC ECU.
3Check continuity between terminals GND of TRAC ECU connector and body gr\
ound.
C
OK
Measure resistance between terminal GND or TRAC
ECU connector and body ground.
Resistance: 1 or less
Repair or replace harness or connector.
±
BRAKE SYSTEM TRACTION CONTROL SYSTEM (TRAC)BR±193
WhereEverybodyKnowsYourName
Page 940 of 4087
OKNG
4Check ECU±IG fuse.
C
OK
PRemove ECU±IG fuse from J/B No. 1.
Check continuity of ECU±IG fuse.
Continuity
Check for short in all the harness and components con-
nected to ECU±IG fuse (See attached wiring diagram).
Check for open in harness and connector between
TRAC ECU and battery (See page IN±33).
BR±194±
BRAKE SYSTEM TRACTION CONTROL SYSTEM (TRAC)
WhereEverybodyKnowsYourName
Page 941 of 4087
±MEMO±
±
BRAKE SYSTEM TRACTION CONTROL SYSTEM (TRAC)BR±195
WhereEverybodyKnowsYourName
Page 942 of 4087
WIRING DIAGRAM
DTC43ABS & TRAC ECU Malfunction
CIRCUIT DESCRIPTION
DTC No.DTC Detecting ConditionTrouble Area
43ABS control system or TRAC (BRAKE) control system
or communication circuit is abnormal.
ABS & TRAC ECU
Open or short in BRFA circuit
DIAGNOSTIC CHARTDIAGNOSTIC CHART
BR±196±
BRAKE SYSTEM TRACTION CONTROL SYSTEM (TRAC)
WhereEverybodyKnowsYourName
Page 943 of 4087
NGOK
NGOK
OKNG
INSPECTION PROCEDURE
1Check voltage between terminal BRFA of TRAC ECU and body ground.
C
OK
P1. Remove TRAC ECU with connectors still con-nected.
2. Turn ignition switch ON.
Measure voltage between terminal BRFA of TRAC ECU
and body ground.
Voltage: About 6 V (Pulse)
Check and replace TRAC ECU.
2Check voltage between terminal BRFA of TRAC ECU and body ground with TRAC ECU connec-
tor is disconnected.
C
OK
Hint
PDisconnect TRAC ECU connector.
Measure voltage between terminal BRFA of TRAC ECU
connector and body ground.
Measure voltage within 8 seconds from the time TRAC
ECU connector is disconnected.
Voltage: See step 1.
Check and replace TRAC ECU.
3Check for open and short in harness and connector between ABS & TRAC ECU and TRAC ECU
(See page IN±33).
Repair or replace harness or connector.
Check and replace ABS & TRAC ECU.
±
BRAKE SYSTEM TRACTION CONTROL SYSTEM (TRAC)BR±197
WhereEverybodyKnowsYourName
Page 944 of 4087
WIRING DIAGRAM
DTC44NE Signal Circuit
CIRCUIT DESCRIPTION
The TRAC ECU receives engine speed signals (NE signals) from the ECM.
DTC No.DTC Detecting ConditionTrouble Area
44No signal is input to terminal NEO 0.24 sec. after trac-
tion control is initiated.
Open or short in NEO circuit
ECM
TRAC ECU
DIAGNOSTIC CHARTDIAGNOSTIC CHART
BR±198±
